Gigabyte GA-H270M-Gaming 3 Manual

Gigabyte Bundkort GA-H270M-Gaming 3

Læs gratis den danske manual til Gigabyte GA-H270M-Gaming 3 (18 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 17 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 9 anmeldelser. Har du et spørgsmål om Gigabyte GA-H270M-Gaming 3, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/18

- 1 -

Table of Contents

Conguring a RAID Set (Intel

Z270/H270 Series) .........................................................2

1-1 Conguring SATA Controllers ............................................................................. 2

1-2 Installing the SATA RAID/AHCI Driver and Operating System.......................... 16

- 2 -

Conguring a RAID Set (Intel

Z270/H270 Series)

To create a RAID set, follow the steps below:

A. Install SATA hard drive(s) in your computer.

B. Congure SATA controller mode in BIOS Setup.

C. Congure a RAID array in RAID BIOS.

(Note 1)

D. Install the SATA RAID/AHCI driver and operating system.

Before you begin, please prepare the following items:

• At least two SATA hard drives or SSDs

(Note 2)

(to ensure optimal performance, it is recommended that you

use two hard drives with identical model and capacity).

(Note 3)

• A Windows setup disk.

• Motherboard driver disk.

• A USB thumb drive.

RAID Levels

1-1 Conguring SATA Controllers

A. Installing hard drives

Install the hard drives/SSDs in the Intel

Chipset controlled connectors on the motherboard. Then connect

the power connectors from your power supply to the hard drives.

RAID 0 RAID 1 RAID 5 RAID 10

Minimum

Number of Hard

Drives

≥2 2 ≥3 4

Array Capacity Number of hard

drives * Size of the

smallest drive

Size of the smallest

drive

(Number of hard

drives -1) * Size of

the smallest drive

(Number of hard

drives/2) * Size of the

smallest drive

Fault Tolerance No Yes Yes Yes

(Note 1) Skip this step if you do not want to create RAID array on the SATA controller.

(Note 2) An M.2 PCIe SSD or an U.2 SSD cannot be used to set up a RAID set either with an M.2 SATA SSD

or a SATA hard drive.

(Note 3) Refer to Chapter 1, "Internal Connectors," for the installation notices for the U.2, M.2, and SATA

connectors.
