Side 1/104

GA-MA785GPM-UD2H/

GA-MA785GM-UD2H/

GA-MA785GM-US2H

AM2+/AM2 socket motherboard for

AMD Phenom™ II processor/ AMD Phenom™ processor/

AMD Athlon™ II processor/ AMD Athlon™ processor/

AMD Sempron™ processor

User's Manual

Rev. 1001

12ME-MA785M2-1001R

Motherboard

GA-MA785GPM-UD2H/

GA-MA785GM-UD2H/

GA-MA785GM-US2H

June 26, 2009

Motherboard

GA-MA785GPM-UD2H/GA-MA785GM-UD2H/GA-MA785GM-US2H

- 4 -

Table of Contents

Box Contents ...................................................................................................................6

Optional Items .................................................................................................................6

GA-MA785GPM-UD2H/GA-MA78GM-UD2H(US2H) ......................................................7

Motherboard Layout .......................................................................................................7

Block Diagram .................................................................................................................8

Chapter 1 Hardware Installation .....................................................................................9

1-1 Installation Precautions .................................................................................... 9

1-2 Product Specications .................................................................................... 10

1-3 Installing the CPU and CPU Cooler ............................................................... 13

1-3-1 Installing the CPU ...................................................................................................13

1-3-2 Installing the CPU Cooler .......................................................................................15

1-4 Installing the Memory ..................................................................................... 16

1-4-1 Dual Channel Memory Conguration .....................................................................16

1-4-2 Installing a Memory ...............................................................................................17

1-5 Installing an Expansion Card ......................................................................... 18

1-6 Setup of the ATI Hybrid CrossFireX™ Conguration ....................................... 19

1-7 Back Panel Connectors .................................................................................. 20

1-8 Internal Connectors ........................................................................................ 23

Chapter 2 BIOS Setup ..................................................................................................35

2-1 Startup Screen ............................................................................................... 36

2-2 The Main Menu .............................................................................................. 37

2-3 MB Intelligent Tweaker(M.I.T.) ........................................................................ 39

2-4 Standard CMOS Features .............................................................................. 44

2-5 Advanced BIOS Features .............................................................................. 46

2-6 Integrated Peripherals .................................................................................... 49

2-7 Power Management Setup ............................................................................. 52

2-8 PnP/PCI Congurations ................................................................................. 54

2-9 PC Health Status ............................................................................................ 55

2-10 Load Fail-Safe Defaults .................................................................................. 57

2-11 Load Optimized Defaults ................................................................................ 57

2-12 Set Supervisor/User Password ...................................................................... 58

2-13 Save & Exit Setup .......................................................................................... 59

2-14 Exit Without Saving ........................................................................................ 59

- 6 -

Box Contents

GA-MA785GPM-UD2H, GA-MA785GM-UD2H,

or GA-MA785GM-US2H motherboard

Motherboard driver disk

User's Manual

Quick Installation Guide

One IDE cable

Two SATA 3Gb/s cables

I/O Shield

Optional Items

Floppy disk drive cable (Part No. 12CF1-1FD001-7*R)

2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)

2-port IEEE 1394a bracket (Part No. 12CF1-1IE008-0*R)

2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)

S/PDIF In and Out cable (Part No. 12CR1-1SPINO-1*R)

COM port cable (Part No. 12CF1-1CM001-3*R)

LPT port cable (Part No. 12CF1-1LP001-0*R)

• The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

• The motherboard image is for reference only.

- 7 -

GA-MA785GPM-UD2H/GA-MA785GM-UD2H(US2H)

Motherboard Layout

"*" The GA-MA785GPM-UD2H/GA-MA785GM-UD2H adopts All-Solid Capacitor design.

j Only for GA-MA785GPM-UD2H.

(Note) Use this port to connect a PS/2 keyboard or PS/2 mouse.

KB(Note) _USB

CPU_FAN

Socket AM2

ATX

GA-MA785GPM-UD2H/

GA-MA785GM-UD2H/

GA-MA785GM-US2H

CD_IN

F_AUDIO

AUDIO

SPDIF_IO

PCIEX1

IDE

PWR_LED

DDR2_1

DDR2_2

ATX_12V_2X4

AMD 785G

AMD SB710

SATA2_3

SATA2_0

SATA2_4

SATA2_2

SATA2_1

PCI1

DVI

VGA

CODEC

OPTICAL

HDMI

USB

LAN

PCI2 CLR_CMOS

BATTERY

M_BIOS

FDD

F_PANEL

COM

RTL8111C

B_BIOS

IT8718

TSB43AB23

SYS_FAN

PCIEX16

ESATA

1394

USB

NB_FAN

F_1394_1

F_USB1

F_USB2

F_USB3

SidePort Memory

DDR2_3

DDR2_4

LPT

- 9 - Hardware Installation

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or •

warranty sticker provided by your dealer. These stickers are required for warranty validation.

Always remove the AC power by unplugging the power cord from the power outlet before •

installing or removing the motherboard or other hardware components.

When connecting hardware components to the internal connectors on the motherboard, •

make sure they are connected tightly and securely.

When handling the motherboard, avoid touching any metal leads or connectors.•

It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-•

ponents such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keep your hands dry and rst touch a metal object to eliminate static electricity.

•

Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

Before unplugging the power supply cable from the motherboard, make sure the power sup-•

ply has been turned off.

Before turning on the power, make sure the power supply voltage has been set according to •

the local voltage standard.

Before using the product, please verify that all cables and power connectors of your hard-•

ware components are connected.

To prevent damage to the motherboard, do not allow screws to come in contact with the •

motherboard circuit or its components.

Make sure there are no leftover screws or metal components placed on the motherboard or •

within the computer casing.

Do not place the computer system on an uneven surface•

Do not place the computer system in a high-temperature environment.•

Turning on the computer power during the installation process can lead to damage to sys-•

tem components as well as physical harm to the user.

If you are uncertain about any installation steps or have a problem related to the use of the •

product, please consult a certied computer technician.

Chapter 1 Hardware Installation

Produkt Specifikationer

Mærke:	Gigabyte
Kategori:	Bundkort
Model:	GA-MA785GPMT-UD2H
Bredde:	243 mm
Dybde:	243 mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	6
Digital akustisk og optisk udgang:	1
Udgange til hovedtelefoner:	6
Intern hukommelse:	0.125 GB
Lyd-output kanaler:	7.1 kanaler
Certificering:	RoHS
Strømkilde type:	ATX
Maksimal intern hukommelse:	16 GB
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ja
Medfølgende software:	Norton Internet Security
Kompatible operativsystemer:	Windows Vista/XP/ME/9X
Processorproducent:	AMD
Drivere inkluderet:	Ja
Antal VGA-porte (D-sub):	1
Grafikadapter:	Radeon HD 4200
Netværksfunktioner:	10/100/1000 Mbit
Antal PS/2-porte:	1
Processor sokkel:	Sokkel AM3
FireWire-porte (IEEE 1394):	1
PCI Express x16 slots:	1
Bundkort chipsæt:	AMD 785G
Lydchip:	Realtek ALC889A
Antal hukommelsesstik:	4
LAN Kontroller:	Realtek RTL8111C
USB 2.0-stik:	3
Antal SATA stik:	5
S/PDIF-udgangsstik:	Ja
CPU-ventilatorstik:	Ja
ATX strømstrik (24 stikben):	Ja
Anal EATX-strømstik:	1
Indbrudsttik til kabinet:	Ja
Lydstik på frontpanel:	Ja
Antal DVI-D-porte:	1
Motherboard form faktor:	micro ATX
PCI Ekspres x1 slots:	1
Antal IEEE1394-stik:	1
Antal eSATA-porte:	1
RAID-niveauer:	0, 1
Hukommelsesspænding:	1.5 V
Strømstik til ventilator:	Ja
CD/AUX lyd, indgående:	Ja
Floppy-drev, stik:	Ja
Controller-grænsefladetype:	ITE IT8718
Specielle funktioner:	@BIOS\nQ-Flash\nXpress BIOS Rescue\nDownload Center\nXpress Install\nXpress Recovery2\nEasyTune\nEasy Energy Saver\nTime Repare\nQ-Share
PCI-slots:	2
Antal parallelle ATA-stik:	1
