For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
Z690 A ELITE AX D4 V2
(Z690 AORUS ELITE AX DDR4 V2)
Z690 A ELITE DDR4 V2
(Z690 AORUS ELITE DDR4 V2)
User's Manual
Rev. 1001
12ME-Z69EW42-1001R
Z690 A ELITE AX
D4 V2
Z690 A ELITE
DDR4 V2
Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of
documentations:
For quick set-up of the product, read the Quick Installation Guide included with the product.
For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 4 -
1-1 Motherboard Layout
Chapter 1 Product Introduction
Temperature sensor
M2_WIFIj
DP_HDMI20
U32
U320G
U32_LAN
LGA1700
ATX
AUDIO
DDR4_A1
DDR4_A2
DDR4_B1
DDR4_B2
BAT
Intel® Z690
CLR_CMOS
M_BIOS
THB_C1
THB_C2
CODEC
PCIEX16
PCIEX4_1
PCIEX4_2
F_U32C
F_U32
USB20
6080110
M2A_CPU
SYS_FAN1
F_USB2D_LED1
F_AUDIO
F_USB1
LED_C1
SYS_FAN3
SPI_TPM
F_PANEL
CPU_FAN
CPU_OPT
SYS_FAN4_PUMP
iTE®
Super I/O
D_LED2 LED_C2
ATX_12V_2X4
ATX_12V_2X2
USB 2.0 Hub
USB 2.0 Hub
SATA3 357
246 CPU DRAM
VGA BOOT
U32G2
Realtek®
2.5GbE LAN
RST_SW
RST
SYS_FAN2
QFLED
QFLASH_PLUS
6080110
M2P_SB
6080110
M2Q_SB
6080110
M2M_SB
Z690 A ELITE AX D4 V2
Z690 A ELITE DDR4 V2
j Only for Z690 A ELITE AX D4 V2.
