Gigabyte Z690 UD Manual
Læs gratis den danske manual til Gigabyte Z690 UD (41 sider) i kategorien Bundkort. Denne vejledning er vurderet som hjælpsom af 50 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 25.5 anmeldelser. Har du et spørgsmål om Gigabyte Z690 UD, eller vil du spørge andre brugere om produktet?
Side 1/41
Z690 UD AC
Z690 UD AX
Z690 UD
Z690 UD AX DDR4
Z690 UD DDR4
User's Manual
Rev. 1101
For more product details, please visit GIGABYTE's website.
https://ww w.gigabyte.com/Motherboard/Z690-UD-AC-rev-10?m=ma#kf
https://ww w.gigabyte.com/Motherboard/Z690-UD-AX-rev-10?m=ma#kf
https://ww w.gigabyte.com/Motherboard/Z690-UD-rev-10?m=ma#kf
https://ww w.gigabyte.com/Motherboard/Z690-UD-AX-DDR4-rev-10?m=ma#kf
https://ww w.gigabyte.com/Motherboard/Z690-UD-DDR4-rev-10?m=ma#k f
GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
For detailed product information, carefully read the User's Manual.
For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's
website.
https://download.gigabyte.com/FileList/Manual/mb_manual_quick-guide_am5.pdf?m=sw
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before
updating motherboard BIOS, drivers, or when looking for technical information.
Example:
Produkt Specifikationer
| Mærke: | Gigabyte |
| Kategori: | Bundkort |
| Model: | Z690 UD |
| Bredde: | 305 mm |
| Dybde: | 244 mm |
| Højde: | 70 mm |
| Vægt: | 1000 g |
| Wi-Fi: | Ingen |
| Antal HDMI-porte: | 1 |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 2.0-porte: | 4 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 4 |
| Udgange til hovedtelefoner: | 1 |
| Ethernet LAN: | Ja |
| Lyd-output kanaler: | 7.1 kanaler |
| Strømkilde type: | ATX |
| Harmoniseret systemkode (HS): | 84733020 |
| Maksimal intern hukommelse: | 128 GB |
| Mikrofonindgang: | Ja |
| Medfølgende software: | Norton Internet Security (OEM version)\nRealtek Gaming LAN Bandwidth Control Utility |
| Understøttede Windows-operativsystemer: | Windows 10 x64 |
| Processorproducent: | Intel |
| Antal DisplayPorts: | 1 |
| USB-stik type: | USB Type-A, USB Type-C |
| Ethernet-grænsefladetype: | 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Komponent til: | PC |
| Understøttet datalagringsdrev typer: | HDD & SSD |
| Perifere (Molex) strømstik (4-pin): | 1 |
| Antal PS/2-porte: | 1 |
| Processor sokkel: | LGA 1700 |
| Understøtter RAID: | Ja |
| Understøttelse af parallel behandlingsteknologi: | 2-Way CrossFireX, Quad-GPU CrossFireX |
| Kompatibel processor serie: | Intel Core i5, Intel Core i7, Intel Core i9 |
| Bundkort chipset familie: | Intel |
| Bundkort chipsæt: | Intel Z690 |
| Understøttede hukommelsestyper: | DDR5-SDRAM |
| Antal hukommelsesstik: | 4 |
| Hukommelses slots type: | DIMM |
| Ikke-fejlkorrigerende kode: | Ja |
| Understøttede hukommelsesclock-hastigheder: | 4000,4800,5200,5400,5600,5800,6000 MHz |
| Ikke-bufferet hukommelse: | Ja |
| Antal SATA III-stik: | 6 |
| Hukommelseskanaler: | To-kanals |
| USB 2.0-stik: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) stik: | 1 |
| S/PDIF-udgangsstik: | Ja |
| CPU-ventilatorstik: | Ja |
| ATX strømstrik (24 stikben): | Ja |
| Indbrudsttik til kabinet: | Ja |
| Antal kabinetventilatorstik: | 3 |
| Lydstik på frontpanel: | Ja |
| Motherboard form faktor: | ATX |
| Understøttede lagerdrev brugerflader: | M.2, PCI Express 4.0, SATA III |
| BIOS-type: | UEFI AMI |
| BIOS-hukommelsesstørrelse: | 256 Mbit |
| ACPI-version: | 5.0 |
| Nulstil CMOS-jumper: | Ja |
| RAID-niveauer: | 0, 1,5, 10 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte: | 1 |
| Specielle funktioner: | @BIOS\nEasyTune\nFast Boot\nGame Boost\nON/OFF Charge\nRGB Fusion\nSmart Backup |
| PCI Ekspres x1 (Gen 3.x) slots: | 2 |
| PCI Ekspres x16 (Gen 3.x) slots: | 2 |
| Maksimalt antal SMP-processorer: | 1 |
| TPM-stik: | Ja |
| PC sundhedsovervågning: | FAN, Temperature, Voltage |
| EPS strømstik (8-pin): | Ja |
| Stik til frontpanel: | Ja |
| Seriel port overskrifter: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) -stik: | 1 |
| Header med RGB-LED-ben: | Ja |
| Desktop Management Interface (DMI) version: | 2.7 |
| System Management BIOS (SMBIOS) version: | 2.7 |
| Thunderbolt-headere: | 2 |
| Antal USB 3.2 Gen 2x2 type-C-porte: | 1 |
| PCI Express x16 (Gen 5.x) slots: | 1 |
