Side 1/2
Countertop Hot Case
GCW Series
GILES Food Service Equipment
ISO 9001-2015 Certified
2750 Gunter Park Drive West • Montgomery, AL 36109 USA
Phone 334.272.1457 • Fax 334.239.4117 • Phone Toll Free 800.554.4537
Website:
www.gfse.com
• Email:
services@gfse.com
Design Features
• Bright, efficient LED lighting provides 2500K warm light
rated up to 50,000 hrs of operation.
• Removable pan divider keeps food pans organized and
evenly spaced.
• Holds 2” to 4” deep pans. Each space can hold (1) full
size pan, (2) 1/2 size pans, or (3) 1/3 size pans.
• Full-serve & self-serve configurations or a combination
of both. Easily field-convertible between the two.
• All stainless steel construction
• Full-serve model features curved front glass that tilts
forward for easy cleaning.
• Adjustable 4” legs for easy leveling. Unit can also be
installed without legs and sealed to a countertop.
• Manufactured and assembled in the USA.
The newest addition to the Giles line of hot food holding
equipment. The GCW is ideal for countertop “grab-n-go”
sales opportunities, even light buffets. An innovative LED
lighting system provides attractive & energy efficient
illumination for displayed items.
A bottom conductive heating plate & overhead infrared heat
keep foods fresh & moist at an optimum holding
temperature.
The Giles GCW Hot Case is available in 2 & 3-pan models
in full-serve & self-serve options. Units may be combined
with a mating kit to create a seamless display up to any
length desired. *Each individual unit is equipped with its own
cord & plug.
Standard Items Provided *Note: Service pans not provided
Pan Divider Pan divider ships inside the unit and may be removed for easy cleaning.
Adjustable Legs 4” adjustable legs come factory assembled and may be removed if desired.
Optional mating kit
for extending food
holding capacity
66296
REV-D
ECO3336
10/7/2024
PRINTED IN USA
Inches [mm]
Dimensions:
Model Width Height Depth Counter Space
GCW-2/1
31.7 in
(805 mm)
25.4 in
(646 mm)
27.5 in
(698 mm)
6.1 sq ft
(0.57 sq m)
GCW-3/1
45.3 in
(1152 mm)
25.4 in
(646 mm)
27.5 in
(698 mm)
8.7 sq ft
(0.81 sq m)
Electrical Specification:
Model Volts Ph Hz
Watts Amps
GCW-2/1 120 1 60 1,200 10.0
GCW-3/1 120 1 60 1,776 14.8
Power cord plug requires NEMA 5-20 Receptacle
Shipping Specification:
Model Crated Wt Crated Dimensions Cube
GCW-2/1-FS
120 lb
(54 kg)
46”W x 40”L x 36”H
[1168 mm x 1016 mm x 914 mm]
38 cu ft
(1.1 cu m)
GCW-2/1-SS
105 lb
(48 kg)
46”W x 40”L x 36”H
[1168 mm x 1016 mm x 914 mm]
38 cu ft
(1.1 cu m)
GCW-3/1-FS
160 lb
(73 kg)
57”W x 40”L x 36”H
[1448 mm x 1016 mm x 914 mm]
48 cu ft
(1.4 cu m)
GCW-3/1-SS
140 lb
(64 kg)
57”W x 40”L x 36”H
[1448 mm x 1016 mm x 914 mm]
48 cu ft
(1.4 cu m)
How To Specify
Model Style Volt Ph Hz Item Number
GCW-2/1-FS Full-serve 120 1 60 71870
GCW-2/1-SS Self-serve 120 1 60 71871
GCW-3/1-FS Full-serve 120 1 60 71868
GCW-3/1-SS Self-serve 120 1 60 71869
❶
Warmer Model & Style. Choose Item Number:
GILES Food Service Equipment
ISO 9001-2015 Certified
2750 Gunter Park Drive West • Montgomery, AL 36109 USA
Phone 334.272.1457 • Fax 334.239.4117 • Phone Toll Free 800.554.4537
Website:
www.gfse.com
• Email:
services@gfse.com
Countertop Hot Case
GCW Series
*Specifications and/or product design are subject to change without notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased equipment.
Specifications
66296
REV-D
ECO3336
10/7/2024
PRINTED IN USA
*Glass open dimension
N/A for self-serve model
3-Pan Model
2-Pan Model
Select Optional Accessories & Quantities:
Qty Description Part No.
Mating Kit 71894
Full-size Pan, 2-1/2” Deep 76024
Full-size Pan, 4” Deep 76175
1/2-size Pan, 2-1/2” Deep 76185
1/2-size Pan, 4” Deep 76186
1/3-size Pan, 2-1/2” Deep 76188
1/3-size Pan, 4” Deep 76189
❷
