Congratulations!
Thank you for purchasing Global Water Instrumentation, Inc. Model AD200-1 , the single
channel voice dialer that can be incorporated into hard wired or wireless security systems
or used as a stand-alone unit. This versatile dialer can be easily expanded to operate in
conjunction with an alarm, temperature or water level sensor, or any other sensor that can
provide the appropriate trigger. 1The AD200- is compatible with continuous, normally
closed (NC) dry contact or voltage sensors. It can be programmed to sequentially dial any
combination of four standard telephone, cellular telephones, alpha/voice pagers and/or
numeric pagers. The dialer features busy-line and no answer detection to ensure timely
transmission of the recorded message of up to 16 seconds. This manual describes how to
set up, install and operate the AD200-1. Please read the entire booklet before operating
the dialer.
Table of Contents:
I) AD200-1 ................................................................................................ 3 Checklist
II) Inspection............................................................................................................... 3
III) Product Summary ................................................................................................. 3
IV) Panel Displays........................................................................................................ 4
V) N.C. Dry Contact Installation Hookup ............................................................... 5
VI) Voltage Level Activation Hookup........................................................................ 5
VII) Programming the Dialer....................................................................................... 6
VIII) Testing Your System........................................................................................... 11
IX) Specifications ....................................................................................................... 13
X) Dialer Accessories ............................................................................................... 13
XI) Important Information/Maintenance................................................................ 14
XII) Warranty.............................................................................................................. 16
