2 Gossen Metrawatt GmbH
Tabel of Contents Page
1 Information on Application ............................................... 2
2 System Requirements ...................................................... 2
2.1 Hardware ......................................................................................2
2.2 Operating System ..........................................................................2
2.3 Supported Devices .........................................................................2
3 Installation ....................................................................... 3
3.1 Driver Installation on your PC ..........................................................3
3.2 Initial Hardware Startup ..................................................................4
4 Safety Messages during Driver Installation on Windows 7 ...5
5 Product Support ............................................................... 5
These operating instructions describe the program
GMC-I Driver Control as from version 1.21.
1 Information on Application
All of the steps necessary for setting up USB drivers for instru-
ments of Gossen Metrawatt GmbH, are described in this docu-
ment.
The system requirements are listed in the following chapter.
The installation of the device drivers is described under section 3
for Windows 7 and subsequent versions.
2 System Requirements
Prerequisites for you PC with regard to hardware and operating
system are listed in concrete terms in the following subsections.
2.1 Hardware
• Processor and RAM see minimum system requirements of the
respective operating system
• VGA monitor with a resolution of at least 1024 x 768 pixels
• Hard disk with at least 10 MB available memory capacity
• Mouse and keyboard
• One or more USB ports
2.2 Operating System
• Windows 7, 8 or 10
2.3 Supported Devices
GMC-I Driver Control as from version 1.21 supports the following
devices:
Adapters and Modules for Test Instruments and Controllers
IrDa-USB Converter for test instruments with a serial port
(e. g. for PROFITEST 0100SII / C, METRISO C and GEOHM C)
RS232-USB R2500/R2700
SECUSTORE
SECUTEST SI+
Testers
SECULIFE ST BASE(25)
SECULIFE ST PRO
SECUTEST BASE(10)
SECUTEST PRO
MINITEST 3P MASTER
MINITEST MASTER
MINITEST PRO
PROFITEST PRIME (AC)
PROFITEST MASTER (IQ)
SECULIFE SR
METRISO XTRA (G1000+)
Multimeter
METRAport 40 USB
USB-METRAHIT 2x
USB-METRAHIT X-TRA
Laboratory Power Supplies
SYSKON P500
SYSKON P800
SYSKON P1500
SYSKON P3000
SYSKON P4500
Install GMC-I Driver Control
Set up Device Drivers
(automatic during initial startup
after connecting the device with
the USB interface of the PC)
Connect the Test Instrument
Exchange Data
e. g. IZYTRONIQ
