1. Safety instructions

1.1 Symbols

The symbols in these instructions point out risks and have the following meaning:

Warning in case of risks.

Non-observance can result in malfunctioning.

Non-observance can result in malfunctioning and

personal injury.

Information on proper product handling.

1.2 Intended use

• The KINAX 2W2 is a precision instrument. It is used to determine angular po-

sitions, processing and providing measured values of electrical output signals

for the downstream device. Encoders use for this purpose only.

• The angular position transmitter is not intended to measure rotation speed.

• The device is intended for installation in industrial plants and meets the requi-

rements of EN 61010-1.

• Device versions with explosion protection may only be used in the planned

purposes and have to be installed in a housing with an ingress protection of at

least IP20 according to EN 60529. The operation in other explosive atmospheres

is not permissible.

• Manufacturer is not liable for any damage caused by inappropriate handling,

modiﬁ cation or any application not according to the intended purpose.

1.3 Commissioning

• Installation, assembly, setup and commissioning of the

device has to be carried out exclusively by skilled workers.

• Observe manufacturer’s operating instructions.

• Check all electric connections prior to commissioning the

plant.

• If assembly, electric connection or other work on the device

and the plant are not carried out properly, this may result

in malfunctioning or breakdown of the device.

• Safety measures should be taken to avoid any danger to

persons, any damage of the plant and any damage of the

equipment due to breakdown or malfunctioning of the

device.

• Do not operate the device outside of the limit values stated

in the operating instructions.

• Operation of device versions with explosion protection is

only permissible when...

- the details on the type label of the device match the on-

site conditions for the permissible Ex area in use (group

of equipment, equipment category, zone, temperature

class or maximum surface temperature)

- the details on the type label of the device match the

electrical supply network

- the device is undamaged and

- it has been checked that there is no explosive atmos-

phere, oils, acids, gases, vapors, radiation etc. present

during installation.

1.4 Repair work and modiﬁ cations

Repair work and modiﬁ cations shall exclusively be carried

out by the manufacturer. In case of any tampering with the

device, the guaranty claim shall lapse. We reserve the right

of changing the product to improve it.

1.5 Disposal

The disposal of devices and components may only be realised

in accordance with good professional practice observing the

country-speciﬁ c regulations.

1.6 Transport and storage

Transport and store the devices exclusively in their original

packaging. Do not drop devices or expose them to sub-

stantial shocks.

Programmable

Transmitter

for angular position

KINAX 2W2

Camille Bauer Metrawatt AG

Aargauerstrasse 7

CH-5610 Wohlen/Switzerland

Telefon +41 56 618 21 11

Telefax +41 56 618 21 21

info@cbmag.com

www.camillebauer.com

Operating Instructions

2. Scope of delivery

- Transmitter for angular position KINAX 2W2, acc. made to order

- 3 clamps

- 1 Operating instructions in German, French and English

- 1 Type examination certiﬁ cate, only with ATEX-approval

3. Application

The KINAX 2W2 transmitter converts the angular position of a shaft into a load

independent direct current signal, proportional to the angular position.

Due to the compact design, the angular position transmitters are particularly suitable

for installation in or mounting / on devices and apparatuses.

Explosion-proof “ ” versions with I.S. meas uring output Intrinsically safe Ex ia IIC T6

rounds off this series of transmitters.

4. Main features

• Compact angular position transmitters for installation or mounting

• Capacitive scanning system

• 4...20mA analog output signal with 2-wire connection

• Drive shaft without stops, rotating

• Low starting troque < 0.001 Nm

• Non-wearing and low-maintenance

• Adjustment / Independent ﬁ ne adjustment of the analog output, zero position

and measuring range

• Characteristic of the output value / Programmable as a linear, V-characteristic,

or any characteristic curve

• Wirh explosion prevention „Ex ia IIC T6 Gb“ according to ATEX available

5. Technical data

5.1 Measuring input

Measuring ranges: Programmable between 0 to 50° or 0 to 350°

Shaft-diameter 2 mm, 6 mm [0.078 , 0.236 ] and 1/4ʺ ʺ ʺ

Starting torque: < 0.001 Ncm [0.0014 oz-in] at 2 mm [0.078 ] shaftʺ

< 0.03 Ncm [0.0425 oz-in] at 6 mm [0.236ʺ] resp. 1/4ʺ shaft

Direction of rotation: programmable

5.2 Measuring output

Output variable IA: Load-independent DC current, proportional to the

input angle

Standard ranges: 4…20 mA, 2-wire connection

DC voltage: Standard (Non-Ex):

Input voltage Ui: 12...33 V

Explosion protection intrinsic ia:

Input voltage Ui: 12...30 V

max. input current Ii: 160 mA

max. input power Pi: 1 W

max. internal capacitance Ci: 6.6 nF

max. internal inductance Li: is negligible

Max. residual ripple: 0.3 % p.p.

Setting time: < 5 ms

External resistance: Rext. max. [kΩ] = H [V] – 12 V

IA [mA]

H = Power supply

IA = Output signal end value

5.3 Accuracy

Reference value: Measuring range

Basic accuracy: 0.5 % with linear characteristic

2W2 Be 149 973-06 01.17

PM1000653 000 01

Calculation additional error:

Output characteristic Deﬁ nition Additional error

Linear

20 mA

4 mA

0 MW

Programmable

Angle max = MW

Angle min = 0°

[fAdd]=%

Device type 350°:

fAdd=( x100-0,05)

Device type 50°:

fAdd=( x100-0,05)

e.g. at MW=180°:

f = fadd + fAbs = 0,05% + 0,5% = 0,55%

simple V-characteristic

Angle max.

20 mA

4 mA

0°

Programmable

Angle max = MW

Angle min = 0°

[fAdd]=%

Device type 350°:

fAdd=( x100)

Device type 50°:

fAdd=( x100)

Offset V-characteristic

20 mA

4 mA

Angle min.

Angle max.

MS=(angle max.)-(angle

min.)

Angle max = ± ﬁ nal angle

Angle min. = > 0°

[fAdd]=%

Device type 350°:

fAdd=( x100)

Device type 50°:

fAdd=( x100)

Beliebige Kennlinie

4 mA

20 mA

Angle max.

Angle min.

MS=(angle max.)-(angle

min.)

[fAdd]=%

Device type 350°:

fAdd=( x100)

Device type 50°:

fAdd=( x100)

Reproducibility: < 0,2 %

Inﬂ uence of temperature

(-40 … +75 °C)

[-40 ... +167 °F]: ± 0,2 % / 10 K

5.4 Installation Data

Material: Housing: Metal (aluminium), Surface chromated

Alodine 400

Mounting position: Any

Admissible static

loading of shaft:

5.5 Regulations

Spurious radiation: En 61000-6-3

Immunity: EN 61000-6-2

Common-mode voltage: 100 V AC, CATII

Test voltage: 750 V DC, 1 min.

all electrical connections against housing

Housing protection: IP 50 acc. to EN 60529

5.6 Environmental conditions

Climatic rating: Standard version

Temperature – 25 to + 75 °C [-13...+167 °F]

Annual mean relative humidity ≤ 90 % or

Version with improved climatic rating

Temperature – 40 to + 75 °C [-40...+167 °F]

Annual mean relative humidity ≤ 95 %

Ex version

Maximum

Power

Temperature class

Pi T6 T5 T4

1000 mW 40°C [104°F] 55°C [131°F] 75°C [167°F]

900 mW 75°C [167°F]44°C [111.2°F] 59°C [138.2°F]

800 mW 75°C [167°F]49°C [120.2°F] 64°C [147.2°F]

700 mW 75°C [167°F]54°C [129.2°F] 69°C [156.2°F]

660 mW 75°C [167°F]56°C [132.8°F] 71°C [159.8°F]

The min. permissible ambient temperature is -40 degrees.

Altitude: 2000 m max.

Transportation and

storage temperature: – 40 to 80 °C [-40...+176 °F]

Vibration resistance: 5 g per 2h in 3 directions

Shock resistance: 3x50 g per 10 splicing in all directions

5.7 Operation in potentially explosive environments:

Gas explosion

prevention: Labeling: Ex ia IIC T6 Gb

Conform to standard: ATEX:

EN 60079-0:2012

EN 60079-11:2012

Type of protection: ia

Temperature class: T6

Group according to

EN 60079-00:2012: II

• The operation in other explosive atmospheres is not permissible.

• It is not permissible to make any alteration to equipment that is used in poten-

tially explosive environments.

Devices with explosion prevention must be operated in

accordance with the stipulations of the operating instructions.

The relevant laws, regulations and standards for the planned

application must be observed.

5.8 Dimensional drawing

4.5 low

30 ±0.1

120° 16.5 26.1

Ø 2

Ø 20 f7

Ø 40 f7

–0.008

–0.014

11 6

Fig. 1. KINAX 2W2 with standard drive shaft at front only, 2 mm, length 6 mm [0.078 , ∅ ʺ

0.236 , screw terminal version.ʺ]

4.5 low

30 ±0.1

120° 7 26.1

Ø 2

Ø 20 f7

Ø 40 f7

–0.008

–0.014

11 12

1.5

Fig. 2. KINAX 2W2 with special drive shaft at front and at rear.

front: 2 mm, length 12 mm [0.078 , 0.472 ]. Rear: 2 mm, length 6 mm [0.078 , 0.236∅ ʺ ʺ ∅ ʺ ʺ]

4.5 low

30 ±0.1

120° 726.1

Ø6 g6

Ø 20 f7

Ø 40 f7

11 12

1.5

–0.004

–0.012

Fig. 3. KINAX 2W2 with special drive shaft at front only, 6 mm, length 12 mm [0.236 , 0.472 ].∅ ʺ ʺ

4.5 low

30 ±0.1

120° 7 26.1

Ø 20 f7

Ø 40 f7

11 12

1.5

Ø2

Ø6 g6 –0.004

–0.012

Fig. 4. KINAX 2W2 with special drive shaft at front and at rear.

front: 6 mm, length 12 mm [0.236 , 0.472 ]. Rear: 2 mm, length 6 mm [0.078 , 0.236 ].∅ ʺ ʺ ∅ ʺ ʺ

4.5 low

30 ±0.1

120° 7 26.1

Ø1/4˝

(6.35 g6)

Ø 20 f7

Ø 40 f7

11 12

1.5

–0.005

–0.014

Fig. 5. KINAX 2W2 with special drive shaft at front only, 1/4 , length 12 mm [0.472 ].∅ ʺ ʺ

Sense

Drive shafts dia.

2 mm 6 mm resp. 1/4˝

radial max. 16 N 83 N

axial max. 25 N 130 N

0,18°

0,25°

0,05°

0,09°
