Operating Instructions

FM/1/2 digi 42

WA-EKF 2738/07.95/S:MMS/D:Bau/80.10.0679.7

1. Putting into operation

The steps marked with the symbol are necessary to

carry out a switching program.

1.1 Reset

Press the "Reset" key with a pencil or similar

object. This sets the time switch to its basic setting.

– before every restart

– to delete all switching times and the time

(with the exception of the standard program)

The following appears after approximately

2 seconds:

Hand switch

Reset

Holiday

program

Enter

switching

time

1.2 Standard program (available on request)

Modules supplied with an integrated standard program

can be activated without programming on Mondays –

on time – at 20:00. The standard program contains

the following preset switching times which, however,

can also be changed.

Monday – Friday Saturday + Sunday

6:00 = ON 7:00 = ON

22:00 = OFF 23:00 = OFF

Activation of the standard program:

After pressing the "Reset" key (see 1.1):

Press the " " key on Mondays at 20:00:

The standard program is activated and

runs on time.

1.4 Entering switching times

42 memory locations are available

Each switching time occupies 1 memory location.

Keep pressing the "Prog." key until a free

memory location "– – : – –" is shown in the

display.

Select the switching functions " " (ON) or

" " " " (OFF) with the key for channel

1 or 2 (depending on the version).

With the

"h"

key: enter the hours

With the

"m"

key: enter the minutes

If a switching command is to be executed every

day, proceed with step . If 1 switching command

is to be executed only on one day or on cer tain

days skip step and continue with step .

Save with the "Prog." key or

With the "Day" key, select 1 day on which the

switching command is not to be carried out

(cursor flashes).

Confirm this day with the "Sel." key

(day of the week and cursor flash)

Press the "Day" key (day is deselected).

Repeat steps , and  for every day to be

deselected.

Save with the key (the next free "Prog."

memory location is displayed)

Save with the " " key.

The time switch goes over to automatic mode

and displays the current time.

Begin every additional switching time and the

associated switching state = ON or = OFF

again with 1.4.

Note:

If an input is incomplete, the segments still not

selected are displayed flashing.

If you have deselected a day on which the

switching command should be carried out,

Reselect the deselected day with the "Day"

key (day of the week and cursor flash).

Confirm this day with "Sel." (cursor flashes).

Press the "Day" key (day is reselected).

Save with the "Prog." key

(the next free memory location is displayed)

Save with the " " key.

1.5 Free channel block formation

On the two channel version, one timed instruction

space can be used to enter a switching command

(ON or OFF) for either channel 1 or channel 2,

or both channels if required.

Keep the " " key pressed during steps

, and .

With the "h" key: enter the hours

With the key: enter the minutes"m"

With the "Day" key: enter the current day

1= Mo ... 7 = Su

Release the " " key

The colon now flashes at one second intervals.

Note:

If the keys are pressed for longer than"h/m"

2 seconds, the display will enter fast-forward

scroll mode.

Deselect days

of the week

Select days

of the week

Enter

hours

Enter

minutes

Enter

time

Summer time

and winter

time

changeover

Days of

the week

flash

1.3 Entering the time and current day

of the week

After pressing the "Res" key (see 1.1):

During the summer time period:

press the "±1h" key once.

Connection

see appliance stamp/sticker/rating plate

Grässlin time switch modules are largely protected against

„spike“ or interference voltages. If faults still occur, counter-

measures against foltage peaks can be taken with familiar

elements (varistors, suppressor diodes etc.). Particular

attention must be paid to this when inductive loads are

connected.

Cursor of

the current

day of the

week flashes Ho = Holiday

Image I

If the holiday program is to start on a different day

to the current one – max. 6 days ahead – use the

"Day" key to select the day on which the holiday

program is to commence.

If the holiday program is to be executed for up to

max. 99 days, continue with steps +.

If the holiday program is to be executed for an

unlimited period, leave out step and continue

with step .

Enter the required number of holiday days with

the "Sel." key (1 to max. 99).

Press the " " key to save the entries.

If the current day of the week was entered as the

holiday program start, the following appears:

d = day number of

entered

holiday days

Image II

Image II remains until the holiday days have passed,

for example d:10, d:09, d:08 .......... etc.

Pressing the key again and holding it down now" "

allows the day of the week, the time and the cur rent

switching state – " " = ON or " " = OFF –

to be checked.

If a day of the week other than the current day was

entered as the holiday program start, the current time

is displayed after the " " key is pressed. The holiday

program is then started at midnight at the start of the

selected day of the week and its duration is displayed

(Figure II).

After the programmed holiday days have expired,

the current time appears in the display.

Aborting the holiday program prematurely

If the holiday program has already started:

●Press the key once" "

If the holiday program has not yet started:

●Press the key twice" "

3. Technical data

Connection see unit stamp

Switching capacity see unit stamp

Ambient temperature –10 °C to +55 °C

Running reserve see unit stamp

Memory locations 42

Shortest switching time 1 minute

Programmable every minute

2.3 Reading the programmed switching times

Press the key several times:"Prog."

– displays all entered switching times starting

with the first memory location.

– the first free memory location

"– – : – –" is then displayed.

– the number of memory locations still free is then

displayed.

If the memory locations are occupied, the following

appears in the display: "FR "

Press the " " key:

The time switch changes to automatic mode and

displays the current time.

Automatic Mode Manual Mode

Continuous Operation

= ON

= OFF

= ON

= Continuous ON

= Continuous OFF

The switching If the current The output will

times correspond switching state is remain fixed ON

to the entered changed manually, , or fixed OFF

program. the next switching as selected

command is indefinitely until the

again executed " " key is used

automatically to restore the timed

according to the function.

entered switching

program

Entering switching times as described under

1.4

The " " key must be pressed for each switching time.

Next, save the holiday switching times with the

"Prog." or " " key.

Entering the start and duration

of the holiday program

After entering the switching times for the

holiday program

Press the " " key once. the following image

appears:

2.7 Holiday program

Note:

The holiday program has priority over the standard

week program. The holiday program can only be

entered if all seven days of the week (1234567)

are selected.

2.4 Changing the programmed switching times

Keep pressing the "Prog." key until the switching

time to be changed is displayed.

The new data can then be entered as described in

Point 1.4.

Note on saving switching times:

If programming is not completed with the " " key

after the switching time is entered (1.4), the

complete switching command is still automatically

saved after approximately 90 seconds. The time

switch then changes to automatic mode and shows

the current time again.

2.5 Deleting individual switching times

Keep pressing the "Prog." key until the switching

time to be deleted is displayed.

Set to "– –" with the "h" or "m" key and keep

the " " key pressed for about 3 seconds.

The switching time is deleted and the current time is

displayed after the key is released.

2.6 AM/PM time display

If the key and the "±1" "h" key are pressed

simultaneously, the time display is switched to AM/PM

mode (used mainly in English-speaking countries).

2. Additional functions

2.1 Summer time and winter time setting

●Press the key once."±1h"

2.2 Manual switch " "

The current switching state can be changed at any

time with the " " key for channel 1 or 2 (depending

on the version). Use of this manual override facility

does not alter any of the programmed information.
