Side 1/1

Presets

iTrip will remember the last 3 stations that you ve used, and will allow you’

to select any of them easily as a preset. Press the NAV switch IN twice to

get to the Presets Screen. From there, press UP or DOWN to move the

indicator to your choice and press IN to select it.

Preferences

Since your iTrip is useful in lots of different real-world situations, we ve’

built in a lot of options.

Press and hold the NAV switch IN to access the Preferences menu. There are

4 preferences and they re easy to change. Move the NAV switch UP or DOWN ’

until the indicator is on the preference you'd like to change, then press the

switch IN to make the selection. Try them out and see what works best for you.

Mono or Stereo: Press the NAV switch IN three times for this screen. iTrip’s

selectable Stereo or Mono modes allow you to adjust for the best possible

audio signal. In large cities with radio stations crowding the dial, iTrip’s Mono

mode gives a stronger signal. Some audio content sounds the same in either

Stereo or Mono, so you may want to select Mono mod sometimes for a

cleaner sound.

EQ, AutoPlay: Press the NAV switch IN four times for these preferences.

EQ: This option gives your iTrip the best general-purpose equalization

setting for FM. If you'd like to enhance the sound quality of your iTrip

simply turn this option ON.

AutoPlay: With AutoPlay ON, iTrip immediately starts playing your first iPod

playlist or your currently selected track as soon as it is connected. AutoPlay

is enabled by default.

Quick Start Guide

Thank you for purchasing Griffin iTrip for iPod nano. The iTrip you hold in

your hands is a slim FM transmitter designed specifically for use with 2nd

Generation iPod nano as introduced by Apple in late 2006.

Getting Started

Getting started with iTrip is easy. Just slip your iPod nano on to the iTrip

sled until it is fully seated. All of iTrip s controls are literally at your’

fingertips, and iTrip uses Griffin s SmartDisplay technology to show you’

tuning and preference information right on the bright clear screen of your iPod.

iTrip s 3-way navigation NAV switch makes it simple to change settings.’( )

The NAV switch moves 3 ways: UP, DOWN and IN. Pressing UP or DOWN will

highlight an item in an iTrip menu, and pressing IN will lock in your selection.

iTrip will automatically exit its setup menus after 4 seconds and return you

to your previous place in your iPod display.

Choosing a Frequency

On your FM receiver, select an FM frequency that plays nothing but static,

with no audio in the background. The ideal choice would be a frequency with

nothing playing on any of the neighboring frequencies. When in doubt, 88.1

is usually a good choice.

Transmitting Your Music

With your iPod nano fully seated in the iTrip sled, press play on your iPod.

iTrip will begin broadcasting. To check the broadcasting frequency, press IN

on iTrip s NAV switch. The nano s screen will now display the frequency at’ ’

which iTrip is currently broadcasting. Move the NAV switch UP or DOWN to

select a frequency matching the one you chose on your radio. Press the NAV

switch IN to confirm your selection.

P963_2G iTrip_sled_QS2.ai

02/06/07 145pm

Additional Features

DistortionFree™ Technology

During broadcast, you'll want to set the volume of your iPod to around 65% of

maximum for the best signal. If you turn the volume up too high, Griffin's

DistortionFree™ Technology automatically reduces the volume on your iPod to

keep your music playing without distortion.

Low Power Mode

For convenience, iTrip is powered by your iPod's battery. To help conserve battery

power when not in use, iTrip will automatically shut itself off after 2 minutes of

silence. iTrip will also go to sleep when you put your iPod to sleep by holding down (

the PLAY/PAUSE button .)

Dimensions: 1.57" x 3.97" x 0.55" (40mm x 10mm x 14.3mm)

Weight: 0.9 oz.

Antenna: Built-In

Power: Supplied by iPod connection

Modulation: FM Stereo

Oscillator: High-Stability Crystal, Phase-Lock Loop Control

Frequency Response: 50 Hz to 15 kHz

Operating Range: 20 ft 6.1m( )

4 1

Warning: You may

damage your iTrip by

removing your iPod

nano in this manner!

Install and remove

your iPod nano in

this manner.

Griffin Technology

9690-NANOTRIP2

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired operation.

. 3-Way touch navigation button

. Status light

. Dock connector

. 1/8“ 3.5mm( ) headphone jack/adapter

. USB mini-B port

iTrip is a registered trademark of Griffin Technology. • iPod is a trademark of Apple, Inc.,

registered in the U.S. and other countries. • Patent Pending • Made in China • Designed in Tennessee

1 YEAR WARRANTY

We stand behind every product with the industry’s best customer service, backed by a simple, fair

warranty. Using this product signifies your acceptance of the terms of the warranty, so please read

our warranty details at www.griffintechnology.com/support/ before using your Griffin product.

Play your iPod

nano

through any FM radio

iPod

The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications

to this equipment. Such modifications could void the user’s authority to operate the equipment.
