Product introduction Page 1- - -- -- -- -- --- -- -- -- --- -- -- -- -- --- -- -- -- -- - -
Disclaimers Page 1-- -- -- -- --- -- -- -- --- -- -- -- -- --- -- -- -- --- -- -- -- --- -- -- -- -
Product Detail GVM-1300D Page 2-- -- -- -- - - -- -- -- -- ---- - - -- -- -- - -- -
Product Detail GVM-1500D Page 3-- -- -- -- - - -- -- -- -- ---- - - -- -- -- - -- -
Product structure analysis Page 4-- -- -- -- --- -- -- -- --- - - -- -- -- -- --- - - -
Installation method Page 5 7~-- -- -- -- --- -- -- -- --- -- -- -- - -- ----- -- --- -
Accessories installation method Page 8-- -- -- -- --- -- -- -- --- -- -- -- --
Description of product control keys Page 9----------- -- ------ -- --
Function introduction and instruction for use Page 10~13----
Precautions Page 13---------- ------------------------ --------------------
APP control and multiple units control Page 14--------------- ---
Use and preservation Page 15-----------------------------------------
Simple faults and troubleshooting Page 15~16-------------------
Packing list Page 17------------------------------------------------ -------
①Please use the matching power adapter or lithium battery with the same
specification to power the product. Do not use power adapter with
different output voltage parameters.
The product is not waterproof, please use it in rainproof environment.②
The product is not anti-corrosion, therefore do not let the product touch
When using the product, make sure the product is put firmly and prevent
If the product will not be used for a long time, please switch off the power
Product Name: Photography Light
Product Type: Photography fill light
Functions/features: APP (Bluetooth connection), brand new LED screen,
joint control, high display finger lamp beads, multiple scene modes
Lamp beads quantity: 960pcs
Color rendering index: ≥97
Color temperature: 3200K~5600K
Brightness: 25000lux/0.5m, 10000lux/1m
Light adjustment method: Step-less adjustment
Product net weight: 1.35 KG
Product size (mm): 270*368*40 MM
Power supply mode: DC input & battery
Battery capacity: 7.4V-4400mAh*2
Heat dissipation: Natural heat dissipation
Product material: aluminum alloy
Place of Origin: China. Huizhou
Product Name: Photography Light
Product Type: Photography fill light
Functions/features: APP (Bluetooth connection), brand new LED screen,
joint control, high display finger lamp beads, multiple scene modes
Lamp beads quantity: 1128pcs
Color rendering index: ≥97
Color temperature: 3200K~5600K
Brightness: 27000lux/0.5m, 11000lux/1m
Light adjustment method: Step-less adjustment
Product net weight: 1.55KG
Product size (mm): 270*418*40 MM
Power supply mode: DC input & battery
Battery capacity: 7.4V-4400mAh*2
Heat dissipation: Natural heat dissipation
Product material: aluminum alloy
Place of Origin: China. Huizhou
The lamp can be installed and fixed on the bracket by rotating the knob
clockwise, and unloaded by rotating in the counterclockwise direction.
Insert the diffuser from the side of the light panel.
Loosen the adjustment knobs on both sides of the U-bracket, adjust
the angle of the panel you need, and then tighten the adjustment knobs
on both sides of the U-bracket.
There are two power supply modes to choose.
① Connect the power cord and adapter for power supply.
② Purchase two other suitable lithium batteries and use them for power
( both battery cells must be plugged in to power )
Only some packages include the following accessories, subject to the actual purchase of the package
Light control folding can control the Angle of light.
Align the front mounting holes with the screw holes of the hinges and lock
DC15V power input interface
Mode control button: Change mode control
Change channel button: When is in master/slave mode, press this button
Multifunctional button: Press once to switch light mode. Press for 3 seconds
to enter/exit the scene mode; Spin the knob to adjust the parameters of the
LED screen: The screen display the current brightness, control mode,
light mode, light parameters, scene number, channel numerical, and
battery power of the light.
Brightness adjustment button: Adjust the brightness
③ Adjust brightness : (BRG) range 0%~100%
⑩ On-line control (Joint control between lamps):
The screen display the current brightness, control mode, light mode, light
parameters, scene number, channel numerical, and battery power of the light.
⑤ Adjust HUE: range 0 ~ 360° °
⑥ Adjust SAT: range 0%~100%
④ Adjust color temperature : (CCT) range 3200K~5600K
⑦ Adjustment scene (SC): range 1~8
Switch the photography light to the APP mode, connect the Bluetooth of the
camera light through the mobile phone, and then use the APP to control the
brightness, color temperature, hue, sat, scene, channel, and on/off of the
camera light. If there is a slave, you can also go through the APP Perform
Prepare two or more photography lights, set one to Master mode, and the
others to Slave mode, and set the channel (CH) of the master and slave.
When the master and slave channels are the same, the slave of the same
channel can be synchronously controlled through the controller behind
Prepare two or more photography lights, set one to APP mode, and connect
the mobile phone APP to set the channel; set the rest to Slave mode, and
set the same channel. When the APP mode machine connected with the
mobile phone APP and the slave machine channel are the same, at this
time, the connected APP mode machine can be controlled through the
mobile phone APP, and the slave machine of the same channel as the APP
mode machine can be synchronously controlled.
In Master mode / Rotate mode, short press the composite knob to switch the
light mode to SAT, and then turn the composite knob button to adjust the
In APP mode, connect to APP and adjust SAT through APP.
In Master mode / Rotate mode, short press the composite knob to switch
the light mode to HUE, and then turn the composite knob button to adjust
In APP mode, connect to APP and adjust hue through APP.
In Master mode / Rotate mode, short press the composite knob to switch
the light mode to CCT, and then turn the composite knob button to adjust
In APP mode, connect to APP and adjust color temperature through APP.
In Master mode/Rotate mode, long press for 3 seconds and press the
composite knob to enter/exit scene light (SC) mode. At this time, short
press the composite knob to select scenes, all scenes can be adjusted
by rotating the brightness adjustment knob; the current scene When it is
scene No. , turn the compound knob to adjust the color temperature; ⑤
when the current scene is scene No. or , turn the compound knob to ⑥ ⑦
adjust the time. (Other scenes can only adjust the brightness).
In Master mode / Rotate mode, turn the brightness adjustment knob to
In APP mode, connect to APP and adjust brightness through APP.
Press the mode button to change the control mode, such as:
Rotate, slave, master, APP
② Mode types and functions：
In Master mode/Slave mode, tap the plus/minus key to set the channel value.
In APP mode, connect to APP and set the channel value through APP.
In the APP mode, connect to the APP and adjust the scene through the APP.
Rotate mode: Adjust the parameters of the light through the controller behind
Slave mode: The channel can only be adjusted through the ▲ and ▼ buttons
of the controller behind the light. When the channels of the slave and the
master are the same, they can be synchronously controlled by the master.
Master mode: Adjust the light and channel of the light through the controller
behind the light, and the slaves of the same channel will also be adjusted
APP mode: Adjust the light parameters through APP.APP mode:
Short press the compound knob to switch the light mode, which are: CCT,
HUE, SAT; Long press the compound knob for 3 seconds to enter/exit the
CCT: Adjustable color temperature, range 3200K~5600K
HUE: Adjustable light color, range 0~360°
SAT: Adjustable light color saturation, range 0%~100%
SC: The product can simulate 8 kinds of scene lights: Lightning, Police ① ②
car, Candlelight, TV, Bad light bulb, Party, ③ ④ ⑤ ⑥ ⑦ ⑧Disco, Paparazzi.
Scan the QR code on the back of the manual to download the APP
If there is a slave, the APP will synchronously control the slave of the same
channel as the connected APP mode machine.
Turn on the video light and set the mode to APP mode. Open the “GVM_LED”
application software on the phone ( The phone needs to turn on bluetooth and
GPS), then enter the bluetooth’s search interface → Find the bluetooth named
“BT_LED” and connect Wait for connection After connect success, it will → →
automatically enter the app’s control interface. At this time, the video light have
been connected and you can controll the APP.
You can save 6 custom light effects in “My Scenes”. After setting the light
effect parameters click the “ ” icon in the right corner pop up the → →
“Save Current Scenes” click “OK”. This light effect can be found in “My →
Do not put the product in a highly humid, strong electromagnetic field, direct
sunlight, high-temperature environment. If not use the product for a long
time, disconnect the power and take out the battery.
Clean：Before clean, disconnect the power plug. And use wet cloth rather than any
detergent or soluble liquid, avoiding damaging the surface layer.
Repairing：If there is fault or performance degradation, do not unpack the shell by
yourself, avoiding damage the machine and lose the right of maintenance. When there
is a fault, do not hesitate to contact us, and we will do our best to deal with the problem.
Accessories：Please use the accessories provided by manufacturer and approved
ones, in order to maximize the performance.
Guarantee：Do does not modify the product, or you will lose the right of maintenance.
Power：Make sure the power is in the demanded range, not too high or too low. Correctly
load the battery, in order not the damage to machine.
Check if the mode were set as
slave mode, lightness and color
temperature of the products
cannot be controlled in slave
Pressthe“MODE”button for once,
switch the mode from slave mode
Check if the product is “OFF”
because of the APP of the
Press the “ON/OFF” button once
Check whether the device is
"BT_LED" is displayed on the
① Switch to APP mode after
② Turn on bluetooth and GPS on
③ Open the APP, search and
connect to Bluetooth BT_LED.
Check whether the color purity
SAT value is too low or 0; the
color purity value is 100, the
color difference is most obvious.
In the Master mode / Rotate
mo d e, l ig h tl y pr e ss t he
switch to SAT, then turn the
increase the color purity;
In WIFI mode, connect APP,
a d j u s t c o l o r p u r e S AT
Make sure the adapter is well
contacted with the power plug.
Charge the battery before using
adapter indicator light up
When using lithium battery,
make sure there's no "low
Brightness button Multifunctional button
Welcome to ”GVM-1300D/GVM-1500D”. This product is specially designed for senior
photography enthusiasts. The product is suitable for live / outdoor / studio photography,
and also for Youtube video shooting. The main features of the product are:
②App intelligent control system, which can be controlled by your intelligent mobile device.
③With an LED screen and stable system, it supports 360 rotation and can effectively
control the light. You can also install folding and soft light board to avoid excess light,
make the light softer, and customize the fill light, allowing you to easily and casually
shoot the desired results.
We believe that once using our product correctly, you can make huge progress when
shooting. Before using the product, you are strongly recommended to read the instructions
④The product can simulate 8 kinds of scene lights: Lightning, Police car, Candlelight,
TV, Bad light bulb, Party, disco, Paparazzi.
Step-less adjustable RGB color and dual color temperature feature, Brightness/color
temperature RGB hue/color purity can be arbitrarily controlled, color temperature range
3200K ~ 5600k, with tightly arranged high CRI LED lamp beads, which is helpful to
restore and enrich the color of objects and provide you with natural and vivid shooting
Before using this product, please read the instructions carefully and make sure
use the product correctly. If you don’t obey the instructions and warnings, you
maybe cause harm to yourself and the people around, or even damage the
product and other things around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
