Contents Introduction
Introduction...........................113
Description ......................................113
Standard applications .....................115
Advanced applications....................116
Preparation............................121
Installation.............................122
Choosing the best place.................122
Standard fixing method...................122
Fixing the receiver on a wall box
(indoor use only) ..............................122
Connecting the receiver..................123
Recognition programming..126
Remote control or keypad (other
than a multi-functional mobile
keypad) recognition programming..126
Multi-functional mobile keypad
recognition programming................127
Control panel recognition
programming ..................................128
Receiver programming........129
Real tests...............................131
Closing the box ....................131
Logisty guarantee
and
extension conditions
.....132
Technical data.......................133
Description
The external receiver is used to remotely control an electrical appliance
from inside or outside the premises.
There are three external receiver versions:
Product Supply voltage Output Application
reference example
S771-22X 230 V AC 230 V 230 V
lighting control
S781-22X 230 V AC voltage-free electrical lock
dry contact control
S791-22X 12-30 V AC or DC voltage-free garage door
dry contact control
The programming LED, which can
only be seen when the box is open,
provides visual help with recogni-
tion programming and receiver pro-
gramming.
It also indicates the status of the
device controlled:
• LED on: activated
• LED off: de-activated.
Programming
button
Programming
LED
Terminal
block
Base
Fixing plate
G
B
114
Introduction
There is a choice of control applications as described on the following pages.
Some of these applications may be used simultaneously while others are exclusive applications.
The table below illustrates the combinations possible.
Example: an external receiver programmed for ON/OFF control can also be used for Timer or Presence simulation
applications.
Possible combinations
ON/OFF
Activation
on intrusion
Timer Remote control
Presence simulation
Pulse control
System status feed-
back
Exclusive applications

Produkt Specifikationer

Mærke: Hager
Kategori: Alarmsystem
Model: S791-22X
