HOW TO READ THE MANUAL

Some paragraphs in the manual contain important information regarding

safety and operation and are emphasized in this manner:

NOTE

IMPORTANT

It gives details or further infor-

mation on what has already been said, and aim to prevent damage to the

machine.

WARNING!

Non-observance will result in the risk of injury to

oneself or others.

DANGER!

Non-observance will result in the risk of serious

injury or death to oneself or others.

The manual describes several machine models that can mainly dier in:

– type of transmission: with hydrostatic continuous speed adjustment.

– particular ttings and/or attachments.

The symbol

highlights all the dierences in usage and is followed by the

indication of the version to which it refers.

The symbol “

” refers to another part of the manual where further informa-

tion or clarication can be found.

NOTE

Whenever reference is made to a position on the ma-

chine “front”, “back”, “left” or “right” side, this refers to the positions of the

seated operator.

INTRODUCTION

Dear Customer,

thank you for having chosen one of our products. We hope you will be com-

pletely satised with your new ride-on lawnmower and that it will fully meet

all your expectations.

This manual has been compiled in order that you may get to know your ma-

chine and to be able to use it safely and eciently. Don’t forget that it forms

an integral part of the machine, so keep it handy so that it can be consulted

at any time, and pass it on to the purchaser if you resell the machine.

This new machine of yours has been designed and made in line with current

regulations, and is safe and reliable if used for cutting and collecting grass

exactly following the instructions given in this manual (proper usage). Using

the machine in any other way or ignoring the instructions for safe usage,

maintenance and repair is considered “incorrect usage” (

5.1) which will

invalidate the guarantee, and the manufacturer will decline all responsibility,

placing the blame with the user for damage or injury to himself or others

insuch cases.

Since the product is continually being improved, you may nd slight dier-

ences between your machine and the descriptions contained in this manual.

Certain modications can be made to the machine without prior warning and

without the obligation to update the manual, although the essential safety and

function characteristics will remain unaltered. In case of any doubts, do not

hesitate to contact your Dealer. And now enjoy your work!

After-sales Service

This manual provides all the necessary information to run the machine and

for correct basic maintenance operations which can be performed by the

user. Contact your Dealer for operations not described in this manual.

INDEX

1. SAFETY REGULATIONS ....................................................2

Regulations for using the machine safely

2. IDENTIFICATION OF THE MACHINE

AND COMPONENTS ...........................................................5

Explanations on how to identify the machine and its main com-

ponents

3. UNPACKING AND ASSEMBLY ...........................................6

Explanations on how to remove the packing and on how to as-

semble separated parts

4. CONTROLS AND INSTRUMENTS ................................... 8

Position and functions of all the controls

5. OPERATING INSTRUCTIONS ..........................................12

Provides indications for working eciently and safely

5.1 Safety recommendations ......................................... 12

5.2 Why the safety devices cut in ................................... 12

5.3 Preliminary operations before starting work ............. 13

5.4 Using the machine ................................................... 14

5.5 Using on slopes ....................................................... 17

5.6 Transport position .................................................... 18

5.7 Advice on how to obtain a good cut ........................... 18

5.8 Summary of main steps to follow when

using the machine .........................................................19

6. MAINTENANCE ..............................................................19

All the information for maintaining the machine in peak ef-

ciency

6.1 Safety recommendations ......................................... 19

6.2 Routine maintenance .............................................. 20

6.3 Checks and adjustments ............................................ 21

6.4 Dismantling and renewing parts ............................... 24

7. TROUBLESHOOTING ..................................................... 27

A help in quickly resolving any problems

8. ATTACHMENTS ON REQUEST ........................................29

A description of the attachments available for particular types

of work

9. TECHNICAL SPECIFICATIONS .........................................30

A summary of the main specications of your machine

10. ALPHABETICAL INDEX ................................................. 31

Where information can be found

MAJOR HONDA DISTRIBUTOR ADDRESSES ............... i

“EC Declaration of Conformity”

CONTENT OUTLINE ....................................................... ii

1 EN

ORIGINAL INSTRUCTIONS

INSTRUCTION MANUAL

HF2317 • HF2417 • HF2625

Ride-on lawnmower

Honda France Manufacturing S.A.S.

Pôle 45 - Rue des Châtaigniers - 45140 ORMES - FRANCE

Write your machine’s model here

H F 2 _ _ _ _ _ _

Note your machine serial number here

M A _ _ _ _ _ _ _ _ _

12-2019 Printed in Italy

ENGLISH

CG71505502H16 • HF2317 - HF2417K5 - HF2625

– Add fuel, using a funnel, only outdoors; do not smoke during this

operation and each time fuel is handled;

– Top-up with fuel before igniting the engine; never remove the tank

cap or add fuel while the engine is running or when it is hot;

– If you have spilled some fuel, do not attempt to ignite the engine

but move the machine away from the area of spillage and avoid

creating any source of ignition until the fuel has evaporated and

fuel vapours have dissipated;

– Always put the tank and fuel container caps back on and tighten

well;

– Do not inhale fuel fumes.

– Open the fuel tank slowly to allow the pressure inside to decrease

gradually.

– Never start the machine in the same place in which you relled it

with fuel; the engine must be started in an area at least 3 metres

from where you refuelled.

– If fuel is spilt on clothing, change clothing before starting the en-

gine.

5) Replace faulty silencers.

6) Before using the machine, check its general condition and in

particular:

the appearance of the cutting means, and check that the screws

and cutting-means assembly are not worn or damaged. Replace the

entire cutting means and all damaged or worn screws to preserve

balance. Any repairs must be done at a specialised centre.

7) Check the battery status regularly, and replace it if there is any

damage to the casing, cover or terminals.

8) Before starting work, always t the exit guards (grass catcher, rear

discharge guard).

C) DURING USE

1) Do not operate the engine in a conned space where dangerous

carbon monoxide fumes can develop. All starting operations have

to be eected in an open or well ventilated area. Always remember

that exhaust gases are toxic. When starting up the machine, do not

direct the silencer and therefore the exhaust fumes towards am-

mable materials.

2) Work only in daylight or with good articial light in good visibility

conditions. Keep persons, children and animals away from the work-

ing area. Get another adult to keep the children under supervision.

3) Avoid working with wet grass, in the rain and when there is a risk

of a thunderstorm, especially lightening.

4) Before igniting the engine, disengage the cutting means or the

power socket and put the gear in neutral.

5) Pay special attention when approaching obstacles that could

compromise visibility.

6) Engage the parking brake when parking the machine.

7) The machine must not be used on slopes of over 10° (17%), re-

gardless of the mowing direction.

8) Remember there is no such thing as a "safe” slope. Driving on

grass slopes requires particular care. To prevent overturning or loss

of control over the machine:

– Do not stop or start suddenly when going up or downhill.

– Engage the drive slowly and always keep the machine in transmis-

sion, especially when travelling downhill;

– Machine speeds should be kept low on slopes and during tight

turns;

– Watch out for humps, hollows and other hidden hazards;

– Never mow across the face of the slope. Lawns on a slope have

to be mowed moving up and down and never across them. When

changing direction, take great care that the wheels facing the

slope do not hit any obstacles (such as stones, branches, roots,

etc.) that may cause the machine to slide sideways, tip over or

make you lose control.

9) Reduce speed before any change of direction on slopes, and

always apply the parking brake before leaving the machine at a

standstill and unattended.

10) Be very careful near ravines, ditches or embankments. The ma-

chine could overturn if a wheel slides over the edge or if the earth

gives way.

1. SAFETY REGULATIONS

1.1 GENERAL SAFETY REGULATIONS

WARNING!

READ THE INSTRUCTION BOOKLET THOR-

OUGHLY BEFORE USING THE MACHINE. Keep for future refer-

ence.

A) TRAINING

1) WARNING! Read these instructions carefully before operating

the machine. Become acquainted with the controls and the proper

use of the machine. Learn how to stop the engine quickly. Failure to

follow the warnings and instructions may result in re and/or serious

injury. Save all warnings and instructions for future reference.

2) Never allow children or persons unfamiliar with these instructions

to use the machine. Local regulations may restrict the age of the

operator.

3) Never mow while people, especially children, or pets are nearby.

4) Never use the machine if the user is tired or unwell, or has taken

medicine, drugs, alcohol or any substances which may slow his

reexes and compromise his judgement.

5) Bear in mind that the operator or user is responsible for accidents

or unexpected events occurring to other people or their property. It is

the user’s responsibility to assess the potential risk of the area where

work is to be carried out, and to take all the necessary precautions

to ensure his own safety and that of others, particularly on slopes or

rough, slippery and unstable ground.

6) If the machine is sold or lent to others, make sure that the operator

looks over the user instructions contained in this manual.

7) Do not allow children or other passengers to ride on the machine

as they could fall o and injure themselves or compromise safe driv-

ing by the operator.

8) The machine operator must follow the driving instructions carefully

and, in particular:

– Avoid distractions and maintain concentration whilst working;

– Bear in mind that control of a machine sliding on a slope will not

be regained by the application of the brake. The main reasons for

loss of control are:

• Insucient wheel grip;

• Excessive speed;

• Inadequate braking;

• Type of machine unsuitable for its task;

• Lack of knowledge about eects which may result from soil

conditions, especially on slopes;

• Incorrect use as a towing machine.

9) The machine is supplied with a series of micro-switches and safety

devices which must never be tampered with or removed; this will

invalidate the warranty and relieve the manufacturer from all respon-

sibility. Always check that the safety devices are working properly

before using the machine.

B) PRELIMINARY OPERATIONS

1) While using the machine, always wear anti-slip and resistant work

footwear and long pants. Do not operate the machine when barefoot

or wearing open sandals. Never wear scarves, shirts, necklaces,

bracelets, clothing with owing parts, laces or ties or any hanging or

apping accessory that could catch in the machine or in any objects

or materials in the work area. Tie hair back if it is long. Wear hearing

protection devices.

2) Use of hearing protections can reduce the ability to hear any warn-

ings (shouting or alarms). Be careful of what occurs around you in

the work area.

3) Thoroughly inspect the entire work area and remove anything that

could be thrown by the machine or damage the cutting-means as-

sembly or engine (stones, branches, iron wire, bones, etc.).

4) WARNING: DANGER! Petrol is highly ammable.

– Keep the fuel in approved containers, in a safe place, away from

any naked lights or heat sources. Keep the containers out of the

reach of children.

2EN

Produkt Specifikationer

Mærke:	Honda
Kategori:	Plæneklipper
Model:	HF 2417 HM B

Har du brug for hjælp?

Hvis du har brug for hjælp til Honda HF 2417 HM B stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Plæneklipper Honda Manualer

Honda HF 2417 HM B Manual

16 August 2025

Honda HF 2417 Manual

16 August 2025

Honda HF2417HTE Manual

13 August 2025

Honda HRX 537C5 VK Manual

13 August 2025

Honda HRX476C Manual

12 August 2025

Honda HRH 536 HX Manual

11 Januar 2025

Honda HRX 476 C2 Manual

1 Januar 2025

Honda izy Manual

8 September 2024

Honda HRS 536 C5 VK Manual

30 August 2024

Honda HRG466C1 Manual

30 August 2024

Plæneklipper Manualer

Nyeste Plæneklipper Manualer

Texas Razor 4611TR/W Manual

16 August 2025

Texas XT 460 Manual

16 August 2025

Wolf Garten Ambition 320E Manual

16 August 2025

Wolf Garten Ambition 400E Manual

16 August 2025

Stihl RM 650 VS Manual

15 August 2025

Stihl RMA 239.1 C Manual

15 August 2025

Weibang LEGACY 48 PRO LV Manual

14 August 2025

Zoef Robot Harm 2.0 Manual

14 August 2025

Zoef Robot Betsie & Dirk MR2600ZW Manual

14 August 2025

Weibang VELOCITY 56 WTP Manual

13 August 2025
