PRODUCT DATA
The Honeywell Trademark is used under license from Honeywell International
Inc. by Air-Pure Systems.
Honeywell International Inc. makes no representations or warranties with
respect to this product. 68-0198-2
F111 (Series 1,2,3)
In Ceiling Media Air Cleaner
APPLICATION
The F111 (Series 1,2,3) Ceiling Media Air Cleaner is a media
air cleaner that uses either a single-speed or three-speed
direct drive forward curve blower motor with particle filter.
When equipped with CPZ™ modules (2), gases and odors are
adsorbed from the air passing through the unit. The air
cleaner removes airborne particles such as dust, soot, mold
spores, pollen and some cooking smoke from the air
circulated through the filter.
FEATURES
• High Efficiency Particulate Air (HEPA) filter models are
99.97% efficient and the hospital grade particle filter
models are 95% efficient at 0.3 micron particles. Both
models are more efficient on particles smaller and
larger. There is also a 95% ASHRAE model.
• Circulates up to 1250 cfm.
• Designed to overcome the increase in air flow
resistance normally caused by filter loading.
• White or black color cover to complement the ceiling.
• CPZ™ module removes up to 95% of the space odors
for up to 24 months.
• 3-Speed remote wall switch ( 3-speed models only)
• READ AND SAVE THESE
INSTRUCTIONS
Contents
Application.........................................................................1
Features ............................................................................1
Specifications ....................................................................2
Ordering Information .........................................................2
Planning the Installation ....................................................3
Installation .........................................................................4
Operation...........................................................................7
Service ..............................................................................8
Parts List ...........................................................................9
Limited Two-Year Warranty ...............................................12
F111 (SERIES 1,2,3) IN CEILING MEDIA AIR CLEANER
68-0198-2 Release 5-09 2
ORDERING INFORMATION
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Honeywell Commercial Air Products Distributor.
2. Air-Pure Systems
16873 Fish Point Rd. SE
Prior Lake, MN 55372
www.cleanairfacility.com
Phone: (800) 998-1919
Fax: (800) 221-3248
SPECIFICATIONS
IMPORTANT
The specifications given in this publication do not
include normal manufacturing tolerances. Therefore,
this unit may not exactly match the listed specifica-
tions. Also, this product is tested and calibrated
under closely controlled conditions, and some minor
differences in performance can be expected if those
conditions are changed.
Models: Refer to Table 1 for model descriptions.
Grill Color: White (standard) or Black (add ‘B’ to end of
model number).
Blower/Motor: Single speed (standard) or three speed ( add
‘-3S’ to the end of the model number) direct drive forward
curve.
Dimensions: See Fig. 1 for dimensions.
Table 1. F111 (Series 3) Description.
aFor single-speed and three-speed systems (set to High)
bF111C1061 has a new model number : F111C1012B
To Order F111 with a Black Grill
Replace the ‘W’ with a ‘B’ to any model number in Table 1.
Model Voltage
Efficiency
Gas, V.O.C. and
Odor Control
Modules (2)
Air Volumea
in cfm
(m3/hr)
Particulates at
0.3 Micron
(DOP Test)
V.O.C./Odor
(Most Gases/
Odors First Pass
Average)
F111A1253W-3S 120 Vac, 60 Hz, 8.5A 95% ASHRAE N/A N/A 1250 (2120)
F111A1063W-3S 120 Vac, 60 Hz, 7.2A 99.97% HEPA N/A N/A 950 (1610)
F111C1073W-3S 120 Vac, 60 Hz, 7.5A 95% ASHRAE 85% CPZ™ modules 1150 (1950)
F111C1003W-3S 120 Vac, 60 Hz, 7.0A 99.97% HEPA 85% CPZ™ modules 825 (1400)
F111C1012W-3S 120 Vac, 60 Hz, 8.0A 95% at 0.3 micron 85% CPZ™ modules 1125 (1910)
F111A2253W-3S 230 Vac, 50 Hz, 4.2A 95% ASHRAE N/A N/A 1125 (1910)
F111A2007W-3S 230 Vac, 50 Hz, 3.5A 99.97% HEPA N/A N/A 900 (1530)
F111C2073W-3S 230 Vac, 50 Hz, 4.0A 95% ASHRAE 85% CPZ™ modules 1025 (1740)
F111C2003W-3S 230 Vac, 50 Hz, 3.2A 99.97% HEPA 85% CPZ™ modules 825 (1400)
F111C1053W-3S 230 Vac, 50 Hz, 3.5A 95% at 0.3 micron 85% CPZ™ modules 950 (1610)
F111C1061b
N/A = not applicable.
same as F111C1012B-3S
