WELCOME
PREPARATION
Before beginning the assembly of this product, ensure
that all parts are present. Compare all parts with the
package contents list and hardware contents list. If
any part is missing or damaged, do not attempt to
assemble the product.
After opening the top of the carton, remove the
mounting hardware package from the foam inserts,
then remove the motor from the packaging and place it
on a soft surface, such as a carpet, to avoid damage to
the nish.
Estimated Assembly Time: Under 60 minutes
Tools Required for Assembly (not included): Electrical
Tape, Phillips Screwdriver, Pliers, Safety Glasses, Step
Ladder, and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape
Measure, Wiring Handbook, and Wire Cutters
CARE AND MAINTENANCE
At least twice each year, lower the canopy to check
the downrod assembly, and then tighten all screws on
the fan. Clean the motor housing with only a soft brush
or lint-free cloth to avoid scratching the nish. Clean
the blades with a lint-free cloth. You may occasionally
apply a light coat of furniture polish to wood blades for
added protection.
Important: Shut off the main power supply before you
begin any maintenance tasks. Do not use water or a
damp cloth to clean the ceiling fan.
FAN WEIGHT
The net weight of this fan is: 20.72 lbs. (9,4 kg).
TABLE OF CONTENTS
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Mounting Bracket Installation . . . . . . . . . . . . . . . . . . . .6
Standard or Angle Mounting Instructions . . . . . . . . . . .7
Closemount Instructions. . . . . . . . . . . . . . . . . . . . . . .10
Wiring.....................................11
Canopy Installation. . . . . . . . . . . . . . . . . . . . . . . . . . .12
Blade Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Light Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . .14
Operating Installation . . . . . . . . . . . . . . . . . . . . . . . . .17
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . .18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Limited Lifetime Warranty. . . . . . . . . . . . . . . . . . . . . .20
