THANK YOU FOR PURCHASING A HOTONE PRODUCT!

Owner's Manual

INPUT

BOOST

CH A/B

REVERB

SEND

FX LOOP

RETURN

SPEAKER

OUTPUT

BALANCED

OUTPUT

CAB SIM

LINE

OUTPUT

POWER AMP

Signal Path

www.hotoneaudio.com

IMPORTANT: TURN ON FIRST, TURN OFF LAST.

Always mute the mixer/audio interface or turn down the volume knob on your amp

before plugging or unplugging power jacks, cables, etc.

When you're using a mixer or an audio interface, please adjust the knobs onboard

carefully to avoid signal clipping.

This unit CANNOT be supplied by phantom power.

Speciﬁcations

Built-in Boost: Max. +12 dB pure clean boost

Power Requirement: 18-20V DC center positive

Current Consumption: Min. 4.5A

Speaker Output: 4-16 , self-adaptiveΩ

Max. Output Power (19V):

75 Watts @ 4 / 40 Watts @ 8 / 20 Watts @ 16Ω Ω Ω

Dimensions: 190mm(D) 118.5mm(W) 53.5mm(H)× ×

Weight: 792g (without PSU)

CH A: Hotone Mojo Diamond, inspired by legendary Fender Tweed*

CH B: Hotone Heart Attack, inspired by legendary Mesa Boogie Rectiﬁer*

BASS/MIDDLE/TREBLE: Controls the low, mid and high frequency response

GAIN: Controls the gain amount

VOL. : Controls the output volume

18-20V DC adapter plug (center positive)

Unit on/off switch

Cabinet connector jack (4-16 )Ω

Cab sim on/off switch (works on both LINE OUTPUT and BALANCED OUTPUT jacks)

1/4” (6.35mm) TRS jack (connect to your mixer or audio interface)

BALANCED OUTPUT jack ground wire lift switch (eliminates hum noise)

Balanced XLR output jack (connect to your mixer or audio interface)

0 to +12 dB of clean boost

Boost on/off switch

Boost on/off status light

Amp channel status light (CH A=green, CH B=red)

Amp channel A/B switch

Reverb on/off switch

Reverb on/off status light

Reverb knob

Amp on/off status light

Guitar connection jack

FX Loop jacks:

SEND: Connect to your effects input (or use as a preamp output)

RETURN: Connect to your effects output (or use as a power amp input)

14 15

*Fender Tweed is an ampliﬁer model of Fender Musical Instruments Corp or at io n.

Mesa Boogie Rectiﬁer is an ampliﬁer model of Mesa/Boogie Ltd.

The mentioned manufacturer and product names are trademarks or reg is te re d tr ad em ar ks o f th ei r

respective owners. The trademarks were used merely to identify the s ou nd c ha ra ct er o f th e pr od uc t.
