ENDaily Reference Guide

1. ON-OFF/Reset button

with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Display

10. Program number and remaining time indicator

11. 3D Zone Wash option button with indicator light

12. Half Load option button with indicator light/ Settings - 3 sec. press

13. Extra Dry option button with indicator light

14. Delay option button with indicator light

15. START/Pause button with indicator light

THANK YOU FOR BUYING AHOTPOINT ARISTON PRODUCT.

In order to receive amore complete assistance, please

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

PRODUCT DESCRIPTION

The control panel of this dishwasher activates pushing by ON/OFF button.

For energy saving the control panel deactivates automatically after 10 minutes if no cycle has started.

APPLIANCE

CONTROL PANEL

W11558344 panel

W11569662 button R

W11569657 button L

W11569647 display

1 2 3 4

11 12 13

5 6 7 8 9 10

1. ActiveDry

2. Cutlery rack

3. Foldable aps

4. Upper rack

5. Upper rack height adjuster

6. Upper sprayer arm

7. Lower rack

8. 3D Zone Wash

9. Lower sprayer arm

10. Filter Assembly

11. Salt reservoir

12. Detergent and Rinse Aid dispensers

13. Rating plate

14. Control panel

Daily Reference Guide

FIRST TIME USE

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

LETTER SETTING

VALUES

(Default - in bold)

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

ActiveDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Light on the oor (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included in

the settings menu.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on

the dishes and on the machine’s functional components.

The salt reservoir is located in the lower part of the dish-

washer (under the lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the control

panel is lit.

1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir right up to its

edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

Residual saline solution or grains of salt can lead to corrosion, irrep-

arably damaging the stainless steel components.

The guarantee is not applicable if faults are caused by such circumstances.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that the

water hardness setting is based on the actual water hardness in your house.

This information can be obtained from your local water supplier. The facto-

ry setting is “3”. See „WATER HARDNESS TABLE”.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (Soft) 0 - 6 0 - 10 0 - 7

2 (Medium) 7 - 11 11 - 20 8 - 14

3 (Average) 12 - 16 21 - 29 15 - 20

4 (Hard) 17 - 34 30 - 60 21 - 42

5 (Very hard) 35 - 50 61 - 90 43 - 62

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty.

The frequency of regeneration depends on the water hardness level setting

- regeneration takes place once per 4-6 Eco cycles with the water hardness

level set to 3. The regeneration process occurs at the beginning of the cycle

with additional fresh water.

• Single regeneration consumes ~3 L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dis-

penser Ashould be lled when the RINSE AID REFILL

indicator light in the control panel is lit.

1. Open the dispenser B by pressing and pulling up

the tab on the lid.

2. Pour in the rinse aid (max. 110 ml), making sure it

does not overow from the dispenser. If this hap-

pens, clean the spill immediately with adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appli-

ance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set a mid-

range number (4-5).

FILLING THE DETERGENT DISPENSER

Only use detergent which has been specically designed for dishwashers.

DO NOT USE washing up liquid.

Using excessive detergent may result in foam residues remaining in

the machine after the cycle has ended.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

To achieve the best washing and drying results, the combined use of

detergent, rinse aid liquid and rened salt is required.

We recommend using detergents that do not contain phosphates or

chlorine, as these products are harmful to the environment.

Good washing results also depend on the correct amount of detergent

being used.

Exceeding the stated amount does not result in a more eective wash

and increases environmental pollution.

The amount can be adjusted to the soil level. In the case of normal-

ly soiled items, use approximately either 35g (powder detergent) or

35ml (liquid detergent) and additional tea spoon of detergent directly

inside the tub. If tablets are used, one tablet will be enough.

If the crockery is only lightly soiled or if it has been rinsed with water

before being placed in the dishwasher, reduce the amount of deter-

gent used accordingly (minimum 25 g/ml) e.g. skip the powder/gel

putted inside the tub.

For good washing results also follow the instructions shown on the

detergent box.

For further questions please ask the detergent producers.

To open the detergent dispenser use the

opening device C. Introduce the detergent

into the dry dispenser D only. Place the

amount of detergent for pre-washing di-

rectly inside the tub.

1. When measuring out the detergent refer to

the mentioned earlier information to add the

proper quantity. Inside the dispenser D, there

are indications to help the detergent dosing.

2. Remove detergent residues from the edges of

the dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program. Usage of detergent not designed for dishwashers

may cause malfunction or damage to the appliance.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	H7I HP42 LO
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Pakkedybde:	675 mm
Pakkebredde:	625 mm
Pakkehøjde:	910 mm
Placering af apparat:	Fuldt indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	42 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Vaskeprogrammer:	Forvask
Justerbare fødder:	Ja
Dør farve:	Ikke anvendelig
Vaskeklasse:	C
Indikator for LED-programfase:	Ingen
Vandforbrug pr. cyklus:	9.5 L
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Sort
Antal kuverter:	15 kuverter
Cyklustid:	210 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Auto-Mixed, Daily 50°C, Delicate 45°C, Eco 50°C, Hygiene, Intensive 65°C, Pre-wash, Quick 45°C, Self-Clean 65°C, Silent 55°C
Halv belastning:	Ja
Tørringsklasse:	A
Indikator for afspændingsmiddel:	Ja
Energieffektivitetsskala:	A til G
Selvrensende:	Ja
AquaSensor funktion:	Ja
AquaStop funktion:	Ingen
Indikator for resterende tid:	Ingen
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	76 kWh
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Doseringsassistent:	Ingen
Selvrensende filter:	Ja
Ekstra tørt:	Ja
Antal kurve:	2 kurv(e)
Automatisk belastningsgenkendelse:	Ingen
Automatisk døråbning:	Ja
Ready-indikator:	Ingen
Gulvindikatorlys:	Ja
Fodjusteringstype:	Forende og bagende
Garantiperiode:	2 År
