FOR YOUR SAFETY
Read and observe all WARNINGS and CAUTIONS
shown throughout these instructions.
While performing installations described in this booklet,
gloves, safety glasses or goggles should be worn.
IMPORTANT – Observe all governing codes and ordinances.
• Note to Installer – Be sure to leave these instructions
for the consumer’s and local inspector’s use.
• Note to Consumer – Keep these instructions with
your Owner’s Manual for future reference.
• Skill Level – Installation of this dishwasher requires
basic mechanical, electrical and plumbing skills.
Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliances Warranty.
See warranty information.
• Completion Time – 1 to 3 Hours. New installations
require more time than replacement installations.
IMPORTANT – The dishwasher MUST be installed to
allow
for future removal from the enclosure if service is required.
Care should be exercised when the appliance is installed
or removed,
to reduce the likelihood of damage to the
power supply cord.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual for
available custom panel kits.
Your dishwasher is a water heating appliance.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• Remove all power leading to the appliance from the
circuit breaker or fuse box before beginning installation.
Failure to do so can result in a risk of electrical shock.
•
To reduce the risk of electric shock, fire, or injury to persons,
the installer must ensure that the dishwasher is completely
enclosed at the time of installation.
• The improper connection of the equipment grounding
conductor can result in a risk of electric shock. Check
with a qualified electrician or service representative
if you are in doubt that the appliance is properly
grounded. If house wiring is not 2-wire with ground, a
ground must be by the installer. When house wiring
is aluminum, be sure to use UL-Listed anti-oxidant
compound and aluminum-to-copper connectors.
•
To reduce the risk of electric shock, fire, or injury to persons,
the installer should check to ensure that wires are not pinched
or damaged, the house wiring is attached to the junction box
bracket through a strain relief, and all electrical connections
made at the time of install (wire nuts) are contained inside of
the junction box cover.
WARNING
• Retire todos los conductores de corriente del
electrodoméstico de disyuntor o de la caja del fusible
antes de comenzar con la instalación. Si no cumple con
esto, se podrá producir el riesgo de descargas eléctricas.
• Para reducir el riesgo de descarga eléctrica, incendio
o lesiones a personas, el instalador debe asegurarse
de que el lavaplatos esté completamente cerrado en
el momento de la instalación.
• La conexión inadecuada del conductor de conexión a
tierra del equipamiento puede provocar un riesgo de
descarga eléctrica. Consulte a un electricista calificado
o representante de servicio técnico si tiene dudas
sobre la correcta conexión a tierra del aparato. Si el
cableado doméstico no cuenta con un cable de 2 hilos
con conexión a tierra, un instalador debe realizar una
conexión a tierra. Cuando el cableado doméstico es de
aluminio, asegúrese de usar un compuesto antioxidante
y conectores de aluminio a cobre aprobados por UL.
• Para reducir el riesgo de descarga eléctrica, incendio
o lesiones a personas, el instalador deberá realizar un
control para asegurar que los cables no estén pellizcados
ni dañados, que el cableado del hogar esté conectado a la
ficha de la caja de empalmes a través de un amortiguador
de refuerzo, y que todas las conexiones eléctricas
realizadas en el momento de la instalación (tuercas para
cables) estén dentro de la tapa de la caja de empalmes.
ADVERTENCIA
See your Owner’s Manual for details on how to contact us regarding installation questions
Built-In DishwashersInstallation Instructions
31-4000220 Rev 4 06-21 GEA
Opening the door will cause the
dishwasher to tip forward when it is
not fully installed. When opening the door prior to the
dishwasher being fully installed, hold the top of the
dishwasher securely with one hand and hold the door
with the other hand. Gloves should be worn.
CAUTION
Abrir la puerta hará que el
lavavajillas se incline hacia
adelante cuando no se encuentre completamente
instalado. Al abrir la puerta antes de haber instalado
completamente el lavavajillas, sostenga la parte superior
del lavavajillas de forma segura con una mano y sostenga
la puerta con la otra mano. Se deberán usar guantes.
PRECAUCIÓN
READ CAREFULLY
KEEP THESE INSTRUCTIONS
PARTS SUPPLIED:
• 2 Bottle Jets clips (on some models)
• Junction box cover
• #10 hex-head screw
• Drain hose hanger
• Hose clamp
• 2 Plug buttons
• Toekick (pre-installed on some models)
• 2 Tub trim pieces (on some models)
• Handle and 1/8” Allen wrench (on some models)
• 2 Mounting brackets for wood countertops
or side cabinets
• 2 #8-18 x 5/8” Phillips special head screws,
to secure dishwasher to underside of
countertop or to side cabinets
• Insulation pieces (on some models)
• Literature, samples and/or coupons
TOOLS YOU WILL NEED:
• Phillips-head screwdriver
• 1/4” and 5/16” nutdriver
• 6” Adjustable wrench
• Level
• Carpenter’s square
• Measuring tape
• Safety glasses
• Flashlight
• Bucket to catch water when flushing the line
• 15/16” socket
• Gloves
• Pliers
For New Installations Only:
• Tubing cutter
• Drill and appropriate bits
• Hole saw set
MATERIALS YOU WILL NEED:
• ´*+7*DUGHQ+RVH7KUHDGÛHOERZLQFOXGLQJ
gasket) - with opposite end sized to fit Hot Water Line
• Thread seal tape
• UL-listed wire nuts (3)
• Masking tape
Materials For New Installations Only:
• Air gap for drain hose, if required
• Waste tee for house plumbing, if applicable
• Electrical cable or Power Cord Kit WX09X70910 (5’ 5” long)
or WX09X70911 (7’ 11” long) depending on installation.
• Strain relief for electrical connection
• Hose clamps
• Hand shut-off valve (recommended)
• Hot Water Line–3/8” minimum, copper tubing (including
ferrule, compression nut) or GE Appliances Part #
WX28X326, flexible braided hose.
• WD24X10065 drain hose (12’ long) or WD24X10062
drain hose (4’ long), if needed.
Installation Preparation
2
Hole Saw SetTubing Cutter Drill and Bits
Phillips-Head
Screwdriver
15/16” Socket
1/4” and 5/16”
Nutdriver
Bucket
Flashlight
Gloves
Carpenter’s
Square
Safety Glasses
Level
Junction
Box Cover
#10
Hex-Head
Junction
Box Screw
3/8" long
#8 Phillips
Special
Head Screws
5/8" long Literature
Pliers
Strain
Relief
Optional -
12' Drain Hose - WD24X10065
4’ Drain Hose - WD24X10062
Hot
Water
Line
Waste Tee Electrical Cable
(or Power Cord,
if applicable)
Wire Nuts (3)
GHT 90°Elbow
Hand
Shut-Off
Valve
Air Gap
Plug
Buttons
Masking Tape
Toekick
Tub Trim Pieces
(on some models)
Insulation
(on some models)
Mounting
Brackets
Drain Hose Hanger
Thread
Seal Tape
(if applicable)
6” Adjustable
Wrench
Hose
Clamps
Measuring Tape
Hose Clamp
Handle and 1/8” Allen wrench
(on some models)
Bottle
Jets clips
(on some
models)
