DAILY REFERENCE

GUIDE

Before using the appliance carefully read Health and Safety guide.

APPLIANCE

PRODUCT DESCRIPTION

CONTROL PANEL

1. Upper rack

2. Cutlery rack

3. Foldable aps

4. Upper rack height adjuster

5. Upper spray arm

6. Lower rack

7. Space Zone

8. Lower spray arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

1. On-O/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Delay indicator light

7. Display

8. Zone Wash 3D indicator light

9. Delay button

10. Zone Wash 3D button

11. Tablet (Tab) button with indicator light

12. Turbo button with indicator light

13. Extra Dry button with indicator light

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance,

please register your appliance on:

www.hotpoint.eu/register

You can download the Safety Instructions and the

Use and Care Guide, by visiting our website

docs.hotpoint.eu and following the Instructions on

the back of this booklet.

1 2 3 4 5 6 7 8 9 10 11 12 13

0000 000 00000

Service:

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the reta-

ining elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and should be lled when the SALT

REFILL indicator light in the control panel is lit .

1. Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. -Only the rst time you do this: ll the salt re

servoir with water.

3. Position the funnel (see gure) and ll the salt

reservoir right up to its edge (approximately

1 kg); it is not unusual for a little water to leak

out.

4. Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for avarage (3) water hardness.

•SwitchontheappliancebypressingtheON/OFF button.

•SwitchotheappliancebypressingtheON/OFF button.

•HolddownbuttonP for 5 seconds, until you hear a beep.

•SwitchontheappliancebypressingtheON/OFF button.

•Thecurrentselectionlevelnumberandthesaltindicatorlightboth

ash.

•PressbuttonP to select the desired hardness level (see WATER

HARDNESS TABLE).

•SwitchotheappliancebypressingtheON/OFF button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indi-

cator light switches o.

If the salt container is not lled, the water softener and the

heating element may be damaged as a result.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser shouldA

be lled when the in the controlRINSE AID REFILL indicator light

panel is lit.

1. Open the dispenser by pressing and pulling up the tab on the lidB .

2. Pour in the rinse aid (max.110 ml), making sure it does not overow

from the dispenser. If this happens, clean the spill immediately with a

dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can ad-

just the quantity of rinse aid used.

•SwitchthedishwasheronusingtheON/OFF button.

•SwitchitousingtheON/OFF button.

•PressbuttonP three times - a beep will be heard.

•SwitchitonusingtheON/OFF button.

•Thecurrentselectionlevelnumberandrinseaidindicatorlightash.

•PressbuttonP to select the level of rinse aid quantity to be

supplied.

•SwitchitousingtheON/OFF button

Setting is complete!

If the rinse aid level is set to ZERO (ECO), no rinse aid will be supplied. The

LOW RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 4 levels can be set according to the dishwasher model. The

factory setting is specic to the model, please follow instruction above

to check this for your machine.

• If you see bluish streaks on the dishes, set a low number (1-2).

• If there are drops of water or limescale marks on the dishes, set a

mid-range number (3-4).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser

use the opening device A. Introduce

the detergent into the dry dispenser

B only. Place the amount of

detergent for pre-washing directly

inside the tub.

1. When measuring out the detergent re-

fer to the mentioned earlier information

to add the proper quantity. Inside the

dispenser B there are indications to help

the detergent dosing.

2. Remove detergent residues from the edges of the dispenser and

close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the

closing device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 17 - 34 31 - 60Hard

5 Very hard 35 - 50 61 - 90

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	HIO 3P23 WL E UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1.28 m
Pakkevægt:	37500 g
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	43 dB
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Understøttede scanningstilstande:	1165 mm
Dør farve:	Hvid
Vandforbrug pr. cyklus:	11 L
Bestik rum type:	Kurv
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	15 kuverter
Cyklustid:	215 min.
Forsinket start (maks.):	12 t
Opvaskeprogrammer:	Auto, Eco 50°C, Intensive, Normal, Quick, Silent, Soak
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.95 kWh
Energieffektivitetsskala:	A til G
Selvrensende:	Ja
Installationsrum højde (min.):	820 mm
Produktstørrelse:	Fuld størrelse (60 cm)
Wi-Fi kontrolleret:	Ingen
Støjemissionsklasse:	B
Energieffektivitetsklasse:	E
Energiforbrug pr. 100 cyklusser:	96 kWh
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Lower, Upper
Strømforbrug (fortsat-tændt):	6 W
Tørresystem:	Turbotørring
Ekstra tørt:	Ja
Maksimal varmtvandsforsyning temperatur:	60 °C
Varighed af tilstanden fortsat-tændt:	12 min.
