Hotpoint
®
ductless mini-split systems deliver unmatched heating and cooling
at an accessible price point. When pros choose Hotpoint
®
they’re providing
homeowners with best-in-class performance, nonstop comfort, and superior
reliability — all backed by one of the toughest names in the industry.
America’s hardest working equipment.
DUCTLESS HEAT PUMP
ENVIRONMENTALLY COMPLIANT
All Hotpoint® systems use R-32 refrigerant, ensuring
that they meet EPA Low GWP refrigerant regulations.
*
WI-FI CONNECTIVITY
Hotpoint® systems connect seamlessly to the SmartHQ™
App from GE Appliances, giving homeowners more
control over their comfort.
PROTECTIVE BASEPAN HEATER
A built-in basepan heater on outdoor units prevents
systems from freezing, keeping systems operating at
peak performance.
ALL-SEASON COMFORT
With heating down to -15°F and cooling up to 115°F,
homeowners know they’re coming home to comfort -
no matter the weather outside.
EFFICIENT OPERATION
High-power turbo mode and warm start technology
help heat and cool rooms more quickly, and an auto
louver adjusts airlow upward when cooling and
downward when heating.
HIGH-PERFORMANCE INVERTER TECHNOLOGY
A DC inverter compressor keeps indoor temperatures
consistent in almost any climate and helps homeowners
save money on energy.
FEDERAL & STATE INCENTIVES
Potential eligibility for federal and state incentives
makes Hotpoint
®
the easy choice for price-conscious
consumers.
**
EASY TO INSTALL, EASY TO SERVICE
A mounting template and mounting plate with
dimensions make installation a breeze, while an
extended kickstand and easy-access control board
let you service systems without removing casings.
Plus, a two-way piping drain on the right and left sides
makes installation easier and ensures units ıt in more
applications.
BUILT TO LAST
A hydrophilic aluminum ın helps prevent condensation
buildup and ensures water lows through the unit smoothly.
WORRY-FREE WARRANTY
Unlock a 5-year limited parts and compressor warranty
with registration.
*Hotpoint models use R32 refrigerant. R32 is classified as a mildly flammable A2L refrigerant. At this time, some building codes restrict the use of products with
A2L refrigerants in some applications. These restrictions vary by location. Refer to all local building codes for guidance on acceptable use of Low GWP (A2L)
refrigerants for your application.
**All Hotpoint systems meet or exceed the 2025 CEE Split Air Source Heat Pump Specification and may qualify for the 2025 Energy Ecient Home Improvement
Credit (25C). For further information, please visit www.cee1.org.
© Copyright 2025 GE Appliances, a Haier Company.
Our continued commitment to quality products may mean a change in specifications without notice.
Pub No. 26-H2501 Rev. 06-20-2025
09K 12K 18K 24K
Model Number
Outdoor
1H09HN2DAB 1H12HN2DAB 1H18HN2DAB 1H24HN2DAB
UPC
084691980575 084691980582 084691980599 084691980605
Indoor
HW09HN2DAB HW12HN2DAB HW18HN2DAB HW24HN2DAB
UPC
084691980612 084691980629 084691980636 084691980643
Cooling
Capacity Range Btu/hr
3,100~11,000 3,300~13,800 4,100~20,000 4,700~25,200
SEER2
18 18 18 18
EER2
12 12 12 10.6
Rated Capacity 95°F Btu/hr
9,000 12,000 18,000 24,000
Moisture Removal Pt./h
1.0 1.2 2.2 2.4
Heating
Heating Capacity Range Btu/hr
2,100~11,000 2,800~13,300 3,800~20,000 4,300~25,600
HSPF2 (IV)
9.5 9.5 9.5 9.5
HSPF2 (V) 7.2 7.1 7.2 7.1
Rated Heating Capacity
47°F Btu/hr
10,000 13,000 19,000 25,000
Rated Heating Capacity
5°F Btu/hr
7,000 13,300 17,5009,100
Max. Heating Capacity
5°F Btu/hr
7,000 13,300 17,5009,100
COP@5F 1.8 1.8 1.8 1.8
Operating Range
Cooling °F (°C) 14~115°F (-10~46°C) 14~115°F (-10~46°C) 14~115°F (-10~46°C) 14~115°F (-10~46°C)
Heating °F (°C) -15~75°F (-26~24°C) -15~75°F (-26~24°C) -15~75°F (-26~24°C) -15~75°F (-26~24°C)
Power Supply
Voltage, Cycle, Phase V/Hz/-
208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Outdoor Unit
Compressor Type DC Inverter Rotary DC Inverter Rotary DC Inverter Rotary DC Inverter Rotary
Maximum Fuse Size A 15 15 20 25
Minimum Circuit Amp A 12 12 14 18
Basepan Heater Yes Yes Yes Yes
Outdoor Noise Level dB 55 55 59 60
Dimension: Height in (mm) 21 3/4 (553) 21 3/4 (553) 25 1/4 (642) 25 1/4 (642)
Dimension: Width in (mm) 31 1/2 (800) 31 1/2 (800) 32 1/4 (820) 32 1/4 (820)
Dimension: Depth in (mm) 11 (280) 11 (280) 12 (306) 12 (306)
Weight (Net/Ship)- lbs (kg) 67.9/80.47 (30.8/36.5) 67.9/80.47 (30.8/36.5) 80.69/93.26 (36.6/42.3) 83.78/96.34 (38/43.7)
Indoor Unit
Fan Speed Stages 5 + Auto 5 + Auto 5 + Auto 5 + Auto
Maximum Indoor Sound Level (dB)
(Turbo/High/Med/Low/Quiet)
45/43/38/32/28 46/44/39/33/29 49/46/43/40/31 54/50/47/44/38
Dimension: Height in (mm) 11 (292) 11 (292) 12 1/8 (307) 13 5/8 (345)
Dimension: Width in (mm) 31 3/4 (805) 31 3/4 (805) 34 1/2 (875) 43 1/2 (1105)
Dimension: Depth in (mm) 7 7/8 (200) 7 7/8 (200) 8 1/2 (217) 9 1/2 (240)
Weight (Net/Ship)- lbs (kg) 18.74/24.47 (8.5/11.1) 18.74/24.47 (8.5/11.1) 21.83/28.22 (9.9/12.8) 32.63/41.67 (14.8/18.9)
Refrigerant Line
Refrigerant R32 R32 R32 R32
Connections Flare Flare Flare Flare
Liquid O.D. in 1/4 1/4 1/4 1/4
Suction O.D. in 1/2 1/2 3/8 3/8
Factory Charge Oz 25.8 25.8 38.8 45.9
Maximum Line Length Ft (m) 66 (20) 66 (20) 83 (25) 83 (25)
Line Length no additional charge
needed Ft (m)
25 (7) 25 (7) 25 (7) 25 (7)
Maximum Height Ft (m) 33 (10) 33 (10) 50 (15) 50 (15)
DUCTLESS HEAT PUMP
MODEL SPECIFICATIONS
