Hotpoint Opvaskemaskine LFS114W

Læs gratis den danske manual til Hotpoint LFS114W (16 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 18 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 9.5 anmeldelser. Har du et spørgsmål om Hotpoint LFS114W, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/16

Instruction booklet

DISHWASHER

Contents

Installation, 2-5

Positioning and levelling

Technical data

Electrical connection

Connecting the water supply

Description of the appliance, 6

Overall view

Control panel

Loading the racks, 7

Lower rack

Cutlery basket

Upper rack

Start-up and use, 8

Starting the dishwasher

Loading the detergent

Washing options

Wash cycles, 9

Wash cycle table

Rinse aid and refined salt, 10

Loading the rinse aid

Loading the refined salt

Care and maintenance, 11

Shutting off the water and electricity supplies

Cleaning the dishwasher

Preventing unpleasant odours

Cleaning the sprayer arms

Cleaning the water inlet filter

Cleaning the filters

Leaving the machine unused for extended periods

Precautions and advice, 12-13

General safety

Disposal

Saving energy and respecting the environment

Troubleshooting, 14

After Sales Service, 15

After Sales Service

Essential Contact Information

Parts and Accessories

Appliance Registration

Hotpoint Guarantee, 16

LFS 114

English, 1

Positioning and levelling

1. Remove the appliance from all packaging and

check that it has not been damaged during

transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides

or back panel are in contact with the adjacent

cabinets or even with the wall. This appliance can also

be recessed under a single worktop* (see the

Assembly instruction sheet).

3. Position the dishwasher on a level and sturdy floor. If

the floor is uneven, the front feet of the appliance may

be adjusted until it reaches a horizontal position (the

angle of inclination must not exceed 2 degrees). If the

appliance is levelled correctly, it will be more stable

and much less likely to move or cause vibrations and

noise while it is operating.

4*. Adjust the height of the rear foot from the front of

the appliance* on the central lower part of the

dishwasher, turning a hexagonal spanner (red color)

with an opening of 8 mm in a clockwise direction to

increase the height or in an anticlockwise direction to

decrease the height.

Anti-condensation strip*

After installing the dishwasher, open the door and

stick the adhesive transparent strip under the

wooden shelf in order to protect it from any

condensation that may form.

Keep this instruction manual in a safe place for

future reference. If the appliance is sold, given away

or moved, please ensure the manual is kept with the

machine, so that the new owner may benefit from the

advice contained within it.

Please read this instruction manual carefully: it

contains important information regarding the safe

installation, use and maintenance of the appliance.

If the appliance must be moved at any time,

keep it in an upright position; if absolutely

necessary, it may be tilted onto its back.

Advice regarding the first wash cycle

After the appliance has been installed, immediately

before running the first wash cycle, completely fill

the salt dispenser with water and add only then

approximately 1 kg of salt (see chapter entitled

Rinse aid and refined salt). The water may overflow:

this is normal and is not a cause for concern. Select

the water hardness value (see chapter entitled Rinse

aid and refined salt). - After the salt has been

poured into the machine, the LOW SALT indicator

light * switches off.

If the salt container is not filled, the water

softener and the heating element may be damaged

as a result.

* Only available in selected models.

Installation

Technical data

Dimensions

width 59.5 cm

height 82 cm

depth 57 cm

Capacity 12 standard place-settings

Water supply

pressure

0,05 ÷ 1MPa (0.5 ÷ 10 bar)

4.3 psi – 145 psi

Power supply

voltage See appliance data plate

Total absorbed

power See appliance data plate

Fuse See appliance data plate

This dishwasher conforms to

the following European

Community Directives:

-73/23/EEC dated 19/02/73

(Low Voltage) and subsequent

modifications

-89/336/EEC dated 03/05/89

(Electromagnetic Compatibility)

and subsequent modifications

-97/17/EC (Labelling)

-2002/96/ CE (Waste

Electrical and Electronic

Equipment WEEE)

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	LFS114W
Bredde:	595 mm
Dybde:	570 mm
Højde:	820 mm
Placering af apparat:	Delvist indbygget
Støjniveau:	53 dB
Antal vaskeprogrammer:	4
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	16 L
Farve på kontrolpanel:	Hvid
Antal kuverter:	12 kuverter
Tørringsklasse:	A
Indkapslet varmeelement:	Ja
