Quick guide

1 432 5 76 8

THANK YOU FOR BUYING A HOTPOINT PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

CONTROL PANEL

1. Control panel

2. Fan

3. Circular heating element

(non-visible)

4. Shelf guides

(the level is indicated on the front

of the oven)

5. Door

6. Upper heating element/grill

7. Lamp

8. Meat probe connection

9. Identification plate

(do not remove)

10. Lower heating element

(non-visible)

1. ON/OFF

For turning the oven on and off.

2. MENU

For gaining quick access to the

main menu.

3. FAVOURITES

To save and quickly retrieve up to

10 favorite functions.

4. BACK

For returning to the previous

menu.

5. DISPLAY

6. NAVIGATION BUTTONS

For navigating through menus,

moving the cursor and changing

settings.

7. OK / SELECT

For selecting functions and

confirming settings.

8. START

For starting the function that has

been selected.

ACCESSORIES

Download the Use and Care Guide from

www.hotpoint.eu for more information

WWW

WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS

MEAT PROBE TURNSPIT GRILL PAN SET

The number of accessories

may vary depending on

which model is purchased.

Other accessories can be

purchased separately from

the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across

the shelf guides, making sure that the side with the

raised edge is facing upwards.

Other accessories, such as the drip tray and the

baking tray, are inserted horizontally in the same way

as the wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift them up and pull the

lower parts out of their lodgings: The shelf guides can

now be removed.

• To refit the shelf guides, first fit them back into their

upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

FITTING THE SLIDING RUNNERS

Remove the shelf guides from the oven and remove

the protective plastic from the sliding runners.

Fasten the upper clip of the

runner to the shelf guide

and slide it along as far as it

will go. Lower the other clip

into position.

To secure the guide, press

the lower portion of the

clip firmly against the shelf

guide. Make sure that the

runners can move freely.

Repeat these steps on the

other shelf guide on the same level.

Please note: The sliding runners can be tted on any level.

USING THE TURNSPIT

Push the skewer through the

centre of the meat (bound

with string if poultry) and

slide the meat onto the

skewer until it is positioned

firmly on the fork and

cannot move. Push the

second fork onto the skewer

and slide it on until it holds

the meat firmly in place.

Tighten the fixing screw to secure it in position.

Insert the end into

the recess provided

in the oven’s cooking

compartment and rest

the rounded part on the

relevant support.

Please note: To collect the

cooking juices, position the

drip tray below and add

500ml of potable water. To

avoid burning yourself when the skewer is hot, only handle

it by the plastic handle (which must be removed before

cooking).

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Ovn
Model:	SI9 891 SP BM
Afrimningsfunktion:	Ja
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	595 mm
Dybde:	564 mm
Højde:	595 mm
Vægt:	36000 g
Produktfarve:	Sort
Kontroltype:	Berøring
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	0.9 m
Placering af apparat:	Indbygget
Indvendig belysning:	Ja
Installationsrum bredde:	568 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	601 mm
Tilsluttet belastning:	3650 W
Grill:	Ja
Konvektion madlavning:	Ja
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Installationsrum højde (min.):	560 mm
Kontrolposition:	Front
Timer type:	Digital
Rengøringstype:	Pyrolyse
Antal gitre:	1
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	73 L
Strøm for samtlige ovne:	- W
Antal ovne:	1
Ovn nettokapacitet:	73 L
Konventionel madlavning:	Ja
Holde varm funktion:	Ja
Pizza fremstillingsfunktion:	Ja
Antal lamper:	1 Lampe( r)
Energieffektivitetsindeks (EEI):	81.4
Energiforbrug (konventionel):	0.91 kWh
Energiforbrug (tvungen konvektion):	0.7 kWh
Dør med blød lukning:	Ja
Bageplade:	Ja
Grillrist inkluderet:	Ja
Blæser grillfunktion:	Ja
Antal bageplader:	2
Belysning placering:	Bagside
Brødfremstilling kapacitet:	Ja
Installationsrum bredde (min.):	560 mm
Stegetermometer:	Ja
Teleskopskinne medfølger:	Ja
Hotpoint-teknologier (madlavning):	Multiflow
