Compaq Presario CQ58
Maintenance and Service Guide

© Copyright 2012 Hewlett-Packard
Development Company, L.P.
AMD, the AMD Arrow logo, and
combinations thereof, are trademarks of
Advanced Micro Devices, Inc. Bluetooth is a
trademark owned by its proprietor and used
by Hewlett-Packard Company under license.
Microsoft, Windows, and Windows Vista
are U.S. registered trademarks of Microsoft
Corporation. SD Logo is a trademark of
its proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: May 2012
Document Part Number: 679370-001

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not
place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat
surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface,
such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the
skin or a soft surface, such as pillows or rugs or clothing, during operation. The device and the AC
adapter comply with the user-accessible surface temperature limits defined by the International
Standard for Safety of Information Technology Equipment (IEC 60950).
iii

iv Safety warning notice

Table of contents
1 Product description ........................................................................................................... 1
2 External component identification ..................................................................................... 5
Finding your hardware and software information ......................................................................... 5
Display ................................................................................................................................... 5
Button ..................................................................................................................................... 7
Keys ....................................................................................................................................... 8
Lights ...................................................................................................................................... 9
TouchPad .............................................................................................................................. 10
Front ..................................................................................................................................... 10
Left side ................................................................................................................................ 11
Right side .............................................................................................................................. 13
Bottom .................................................................................................................................. 14
3 Illustrated parts catalog .................................................................................................. 15
Service tag ............................................................................................................................ 16
Computer major components ................................................................................................... 17
Display assembly subcomponents ............................................................................................. 20
Mass storage devices ............................................................................................................. 22
Miscellaneous parts ................................................................................................................ 23
Sequential part number listing .................................................................................................. 24
4 Removal and replacement procedures ............................................................................ 27
Preliminary replacement requirements ....................................................................................... 27
Tools required ......................................................................................................... 27
Service considerations ............................................................................................. 27
Plastic parts ............................................................................................. 27
Cables and connectors ............................................................................. 27
Drive handling ......................................................................................... 28
Grounding guidelines .............................................................................................. 28
Electrostatic discharge damage .................................................................. 28
v

Packaging and transporting guidelines ........................................ 30
Component replacement procedures ........................................................................................ 32
Service tag ............................................................................................................. 32
Computer feet ......................................................................................................... 33
Battery ................................................................................................................... 34
Memory module ...................................................................................................... 35
WLAN module ........................................................................................................ 36
Keyboard ............................................................................................................... 38
Optical drive .......................................................................................................... 42
Hard drive ............................................................................................................. 44
RTC battery ............................................................................................................ 47
Top cover ............................................................................................................... 48
Power button board ................................................................................................. 51
TouchPad button board ............................................................................................ 52
Optical drive connector cable ................................................................................... 55
Speakers ................................................................................................................ 57
USB board ............................................................................................................. 59
System board ......................................................................................................... 61
Fan/heat sink assembly ........................................................................................... 63
Display assembly .................................................................................................... 66
Power connector cable ............................................................................................ 75
5 Using Setup Utility (BIOS) and System Diagnostics ........................................................... 77
Starting Setup Utility (BIOS) ..................................................................................................... 77
Updating the BIOS ................................................................................................................. 77
Determining the BIOS version ................................................................................... 78
Downloading a BIOS update .................................................................................... 78
Using System Diagnostics ........................................................................................................ 79
6 Specifications ................................................................................................................. 80
Computer specifications .......................................................................................................... 80
15.6-in, SVA, display panel display specifications ..................................................................... 81
Hard drive specifications ........................................................................................................ 82
7 Backup and recovery ...................................................................................................... 83
Restore ................................................................................................................................. 83
Creating recovering media ...................................................................................................... 84
Performing a system restore ..................................................................................................... 85
Restoring using the dedicated recovery partition (select models only) ............................. 85
Restoring using the recovery media ........................................................................... 86
vi

Changing the computer boot order ............................................................................ 86
Backing up and recovering your information ............................................................................. 87
Using Windows Backup and Restore ......................................................................... 88
Using Windows system restore points ........................................................................ 88
When to create restore points .................................................................... 88
Create a system restore point ..................................................................... 88
Restore to a previous date and time ............................................................ 89
8 Power cord set requirements .......................................................................................... 90
Requirements for all countries .................................................................................................. 90
Requirements for specific countries and regions ......................................................................... 91
9 Recycling ........................................................................................................................ 92
Index ................................................................................................................................. 93
vii

viii

Category Description
Memory Two customer-accessible/upgradable memory module slots
DDR3-1333-MHz single channel support (DDR3-1600 downgrade to DDR3-1333) on
computer models equipped with an AMD E2-1800 processor
DDR3-1066-MHz single channel support (DDR3-1600 downgrade to DDR3-1066) on
computer models equipped with an AMD E1-1200 or E-300 processor
Supports 8192-MB of system RAM in the following configurations:
●8192-MB (4096-MB×2; not supported on computer models equipped with a 32-
bit operating system)
●6144-MB (4096-MB+2048×1; not supported on computer models equipped with
a 32-bit operating system)
●4086-MB (4096-MB×1 or 2048×2; not supported on computer models equipped
with Windows 7, 32-bit operating system)
●2048-MB (2048×1; not supported on computer models equipped with Windows
7, 32-bit operating system)
Hard drive Supports 6.35-cm (2.5-in) hard drives in 9.5-mm (.37-in) and 7.0-mm (.28-in)
thicknesses (all hard drives use the same bracket)
Customer-accessible
Serial ATA
Supports the following hard drives:
●750-GB, 5400-rpm, 9.5-mm
●640-GB, 5400-rpm, 9.5-mm
●500-GB, 5400-rpm, 9.5-mm
●320-GB, 5400-rpm, 9.5-mm
Optical drive Fixed
Serial ATA
12.7-mm tray load
Supports DVD±RW Double-Layer with SuperMulti Drive
Supports zero power optical drive
Audio and video Two Altec-Lansing speakers
HD audio
Supports Microsoft premium requirements
VGA webcamera (fixed, no tilt with activity LED; 640×480 by 24 frames per second)
One digital microphone
Ethernet Integrated 10/100 network interface card (NIC)
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
2 Chapter 1 Product description
Produkt Specifikationer
Mærke: | HP |
Kategori: | Bærbare computer |
Model: | CQ58-103SO |
Bredde: | 376 mm |
Dybde: | 247 mm |
Højde: | 31.3 mm |
Vægt: | 2450 g |
Brugervejledning: | Ja |
Produktfarve: | Sort |
Produkttype: | Notebook |
Skærm diagonal: | 15.6 " |
Skærmopløsning: | 1366 x 768 pixel |
Berøringsskærm: | Ingen |
Kompatible hukommelseskort: | MMC,SD |
Wi-Fi: | Ja |
Bluetooth: | Ingen |
Batteriteknologi: | Lithium-Ion (Li-Ion) |
Formfaktor: | Muslingeskal |
Naturligt aspektforhold: | 16:9 |
Opbevaringstemperatur (T-T): | -20 - 60 °C |
Relativ luftfugtighed ved drift (H-H): | 10 - 90 % |
Relativ luftfugtighed ved opbevaring (H-H): | 5 - 95 % |
Antal HDMI-porte: | 1 |
DVI-port: | Ingen |
Ethernet LAN-porte (RJ-45): | 1 |
Antal USB 2.0-porte: | 3 |
Udgange til hovedtelefoner: | 1 |
Ethernet LAN: | Ja |
Wi-Fi-standarder: | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
Processorkerner: | 2 |
Driftstemperatur (T-T): | 5 - 35 °C |
Ethernet LAN-datahastigheder: | 10,100 Mbit/s |
Intern hukommelse: | 4 GB |
Kabler inkluderet: | Vekselstrøm |
Operativsystem installeret: | Windows 7 Home Premium |
Kabelteknologi: | 10/100Base-T(X) |
Netværksstandarder: | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
AC-adapter inkluderet: | Ja |
Indbygget kortlæser: | Ja |
HDD kapacitet: | 640 GB |
LED-baggrundsbelysning: | Ja |
Antal indbyggede højttalere: | 2 |
Batterilevetid (maks.): | - t |
Bæredygtighedscertifikater: | EPEAT Silver,ENERGY STAR |
Processorfrekvens: | 1.3 GHz |
Processorserie: | AMD E |
Processortråde: | 2 |
Processor-cache: | 1 MB |
Processor cache type: | L2 |
Intern hukommelsestype: | DDR3-SDRAM |
Maksimal intern hukommelse: | 8 GB |
Hukommelse form faktor: | SO-DIMM |
Samlet lagringskapacitet: | 640 GB |
Lagermedie: | HDD |
On-board grafikkort, model: | AMD Radeon HD 6310 |
Diskret grafikadaptermodel: | Ikke tilgængelig |
On-board grafikkort: | Ja |
Diskret grafikadapter: | Ingen |
Indbygget grafikadapterfamilie: | AMD Radeon HD 6000 |
Indbygget mikrofon: | Ja |
Mikrofonindgang: | Ja |
S/PDIF-udgang: | Ingen |
Docking-stik: | Ingen |
ExpressCard-slot: | Ingen |
Cardbus PCMCIA slot type: | Ingen |
Smartcard slot: | Ingen |
Opladningsport type: | DC-in-stik |
Pegeredskab: | Touchpad |
Numerisk tastatur: | Ingen |
Tastatur i fuld størrelse: | Ja |
Vekselstrømsadapter strøm: | 65 W |
Slot til kabellås: | Ingen |
Driftshøjde: | -15 - 3048 m |
Ikke-drift højde: | -15 - 12192 m |
Hukommelsesstik: | 2x SO-DIMM |
Processorproducent: | AMD |
Processormodel: | E-300 |
Oprindelsesland: | Kina |
Drivere inkluderet: | Ja |
Skærmoverflade: | Glans |
Antal VGA-porte (D-sub): | 1 |
Optisk drevtype: | DVD Super Multi DL |
Antal battericeller: | 6 |
HDD-grænseflade: | SATA |
Windows taster: | Ja |
HDD-størrelse: | 2.5 " |
HDD hastighed: | 5400 rpm |
Intel® Mindre Forretnings-fordele (Intel® SBA): | Ingen |
Hukommelseslayout (slots x størrelse): | 1 x 4 GB |
Antal installerede HDD'er: | 1 |
Operativsystemets arkitektur: | 64-bit |
Bundkort chipsæt: | AMD A68M |
Maksimal intern hukommelse (64-bit): | 8 GB |
Højttalerproducent: | Altec Lansing |
Har du brug for hjælp?
Hvis du har brug for hjælp til HP CQ58-103SO stil et spørgsmål nedenfor, og andre brugere vil svare dig
Bærbare computer HP Manualer
4 August 2025
4 August 2025
4 August 2025
4 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
Bærbare computer Manualer
- XPG
- Medion
- Asus
- Hannspree
- Kogan
- Krüger&Matz
- Airis
- SilverCrest
- Hyundai
- Schneider
- BEKO
- Xplore
- Panasonic
- Xiaomi
- Dell
Nyeste Bærbare computer Manualer
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
12 August 2025
