HP Pavilion dv6 Entertainment PC

Maintenance and Service Guide

Development Company, L.P.

ATI Mobility Radeon is a registered

trademark of Advanced Micro Devices, Inc.

Bluetooth is a trademark owned by its

proprietor and used by Hewlett-

Packard Company under license. Intel,

Celeron, Core, and Pentium are trademarks

of Intel Corporation in the U.S. and

other countries. Microsoft, Windows, and

Windows Vista are U.S. registered

trademarks of Microsoft Corporation.

SD Logo is a trademark of its proprietor.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

First Edition: July 2010

Document Part Number: 597854-001

MSG revision history

Revision Publication date Description

A August 2010 ●Updated commodities in the following location: Product description

on page 1.

●Added newly supported processors to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Removed obsolete processors from spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Added newly supported system boards to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Removed obsolete system boards from spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Added newly supported hard drives to spare parts listings in the following

locations: Computer major components on page 18, Mass storage devices

on page on page 32, Sequential part number listing 35, and Hard drive

on page 55.

●Added newly supported WLAN modules to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and WLAN module on page 57.

●Added newly supported keyboards to spare parts listings in the following

locations: Computer major components on page 18 and Sequential part

number listing on page 35.

●Updated miscellaneous parts to spare parts listings in the following locations:

Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Updated hard drive specifications in the following location: Hard drive

specifications on page 107.

iii

B November 2010 ●Updated commodities in the following location: Product description

on page 1.

●Added newly supported processors to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Added newly supported Thermal Pad Kit to spare parts listings in the following

locations: Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Added newly supported system boards to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Added newly supported display assemblies and removed obsolete display

assemblies from spare parts listings in the following locations: Computer major

components on page 18 35, Sequential part number listing on page , and

BrightView display assembly on page 77.

●Added newly supported hard drives and removed obsolete hard drives from

spare parts listings in the following locations: Computer major components

on page on page Sequential part number18, Mass storage devices 32,

listing 35 55on page , and Hard drive on page .

●Added newly supported optical drives to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and Optical drive on page 63.

●Added newly supported keyboards to spare parts listings in the following

locations: Computer major components on page 18 and Sequential part

number listing on page 35.

●Added newly supported top covers to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 67on page , and Top cover on page .

●Added newly supported fan/heat sink assembly to spare parts listings in the

following locations: Computer major components on page 18, Sequential

part number listing on page 35, and Fan/heat sink assembly on page 95.

●Updated miscellaneous parts to spare parts listings in the following locations:

Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Updated optical disc specifications in the following location: Blu-ray Writer

with DVD±R/RW SuperMulti DL Drive on page 110.

iv MSG revision history

RJ-11 (modem) ..................................................................................................................... 133

Universal Serial Bus .............................................................................................................. 133

9 Power cord set requirements ........................................................................................ 134

Requirements for all countries or regions ................................................................................. 134

Requirements for specific countries or regions .......................................................................... 135

10 Recycling .................................................................................................................... 136

Battery ................................................................................................................................ 136

Display ............................................................................................................................... 136

Index ............................................................................................................................... 140

Category Description

Chipset Intel HM55 Express Chipset

Graphics Intel HD graphics

Switchable discrete graphics

ATI Capilano Pro (ATI Mobility Radeon™ HD 6550) graphics with 1024-MB of dedicated

video memory (64MB x 16 DDR3 @ 800 MHz x 8 pcs) and 128-MB of sideport video

memory

ATI Robson XT (ATI Mobility Radeon HD 63 of dedicated video70) graphics with 512-MB

memory (64MB x 16 DDR3 @ 800 MHz x 4 pcs) and 128-MB of sideport video memory

ATI Madison Pro (ATI Mobility Radeon HD 5650) graphics with 1024-MB of dedicated

video memory (64MB x 16 DDR3 @ 800 MHz x 8 pcs) and 128-MB of sideport video

memory

ATI Park XT (ATI Mobility Radeon HD 5470) graphics with 512-MB of dedicated video

memory (64MB x 16 DDR3 @ 800 MHz x 4 pcs) and 128-MB of sideport video memory

Supports Blu-ray and/or HD-DVD playback with HD Decode, DX11 support

and HDMI support

Panels 39.6-cm (15.6-inch) SVA HD LED BrightView (1366x768) (5.5 mm max)

39.6-cm (15.6-inch) HD+ LED Touchscreen

Supports lighted logo on top bezel

Memory Two customer-accessible/upgradeable SODIMM slots

DDR3 PC3-10600 1333-MHz memory

Supports dual channel

DDR3/1333-MHz and DDR3/1066-MHz (only computer models equipped with the Intel

Core i7-840QM 1.86 GHz processor, the Intel Core i7-820QM 1.73GHz processor, the

Intel Core i7-740QM 1.73 GHz processor, and the Intel Core i7-720QM 1.6 GHz

processor run at DDR3/1333-MHz; all other computer models run at DDR3/1066-MHz)

Supports up to 8 GB system memory in the following configurations:

1024-MB total system memory (1024 MB x 1)

2048-MB total system memory (1024 MB x 2, dual-channel)

2048-MB total system memory (2048 MB x 1)

3072-MB total system memory (1024 MB x 1 + 2048 MB x 1)

4096-MB total system memory (2048 MB x 2, dual-channel)

6144-MB total system memory (2048 MB x 1 + 4096 MB x 1)

8192-MB total system memory (4096 MB x 2, dual-channel)

Hard drives Supports 6.35-cm (2.5-in) hard drives (HD), 12.7-mm (.50-in), and 9.5-mm (.37-in)

thicknesses

Supports one hard drive

Supports solid state drives (SSD)

2 Chapter 1 Product description

Category Description

Supports Accelerometer Hard Drive Protection

Single hard drive configurations:

160-GB SSD

250 GB (7200 rpm, 9.5 mm)

320 GB (7200 rpm, 9.5 mm)

500 GB (7200 rpm, 9.5 mm)

640 GB (5400 rpm and 7200 rpm, 9.5 mm)

750 GB (5400 rpm and 7200 rpm, 9.5 mm)

1 TB (5400 rpm, 12.7 mm)

Optical drives 12.7-mm tray load

Serial ATA (SATA)

Fixed (removal of one screw required)

Supports the following optical drives:

LightScribe DVD±R/RW SuperMulti DL Drive

DVD±R/RW SuperMulti DL Drive

Blu-ray ROM with LightScribe DVD±R/RW SuperMulti DL Drive

Blu-ray ROM with DVD±R/RW SuperMulti DL Drive

Blu-ray Writer with DVD±R/RW SuperMulti DL Drive

Webcam Low-light VGA camera

Fixed (no tilt)

Activity LED

640 × 480 by 24 frames per second

Microphone 2 omnidirectional microphones, dual-array with appropriate software (supports beam

forming, echo cancellation, and noise suppression)

Audio HD Audio

Dolby advance audio

Integrated subwoofer

Supports Microsoft® Premium Requirements

Pavilion-branded Altec Lansing speakers

Ethernet Integrated 10/100/1000 network interface card (NIC)

Wireless Integrated wireless local area network (WLAN) options by way of wireless

module:

Atheros AR9285 802.11b/g/n 1x1 WLAN module

Category Description

Ralink RT3090BC4 802.11b/g/n 1x1 WiFi and Bluetooth 2.1+EDR Combo Adapter

Intel® Centrino® Advanced–N + WiMAX 6250 WLAN module

Intel Centrino Wireless-N 1000 802.11b/g/n 1x2

Broadcom 4313 802.11b/g/n 1x1 WLAN module

Broadcom 4313 802.11b/g/n 1x1 WiFi and 2070 Bluetooth 2.1+EDR Combo Adapter

Broadcom 43225 802.11b/g/n WLAN module

Broadcom 43224 802.11a/b/g/n 2x2 WLAN module

TV tuner DVB-T TV tuner module (select models only)

DVB-T TV tuner antenna (select models only)

Remote control (full-function with teletext) (select models only)

External media card 5-n-1 Digital Media Reader

Digital Media Slot supports Secure Digital (SD ) Memory Card, MultiMediaCard (MMC),

Secure Digital High Capacity (SDHC), Memory Stick (MS), Memory Stick Pro (MSP), xD-

Picture Card (XD)

Supports mini versions with adapter (adapter not included)

Internal card expansion One half-size mini-card slot for WLAN

Ports VGA, 15-pin supporting 1920 × 1200 resolution at 75 Hz

VGA, 15-pin supporting 1600 × 1200 resolution at 75 Hz

Hot Plug/Unplug and auto detect for correct output to wide-aspect versus standard aspect

video

High-Definition Multimedia Interface (HDMI) v1.3 supporting 1080p and 1920 x 1080 at

60 Hz and 1920 x 1200 at 60 Hz DVI Mode

eSATA port combo with fourth USB port

USB 2.0 (three ports)

RJ-45 Ethernet

Headphone/line out

Microphone input (audio-in)

AC Smart Pin adapter plug

Keyboard/pointing

devices

38.1-cm (15-inch) full-size keyboard

Dura-coat, island-style

Backlit dura-coat, island-style (select models only)

Mylar clickpad cover

4 Chapter 1 Product description

Category Description

Clickpad

Multitouch gestures enabled as default

Taps enabled as default

Power requirements 6-cell, 55-Wh, 2.55-Ah Li-ion battery

6-cell, 62-Wh, 2.8-Ah Li-ion battery

9-cell, 93-Wh, 2.8-Ah Li-ion battery

65-W AC adapter

90-W AC adapter

120-W AC adapter

65-W slim travel adapter (smart-pin)

Security Security cable slot

Fingerprint reader with Digital Persona software support (select models only)

Operating system Preinstalled:

Windows® 7 Professional (32 and 64 bit)

Windows 7 Home Premium (32 and 64 bit)

Windows 7 Home Basic (32 and 64 bit)

FreeDOS

Serviceability AC adapter

Battery (system)

Hard drive

Memory module

Optical drive

Mini Card components

2 External component identification

Top components

TouchPad

Component Function

TouchPad Moves the pointer and selects or activates items on the screen.

To view or change the pointing device preferences:

1. Select Start .> Devices and Printers

2. Right-click the device representing the computer.

3. Select Mouse settings.

6 Chapter 2 External component identification

TouchPad buttons

Item Description Function

(1) TouchPad On/Off button Turns the TouchPad on and off. Quickly double-tap

to turn the TouchPad on and off.

(2) Left TouchPad button Functions like the left button on an external mouse.

(3) Right TouchPad button Functions like the right button on an external

mouse.

To view or change pointing device preferences:

1. Select Start .> Devices and Printers

2. Right-click the device representing your computer.

3. Select Mouse settings.

Top components 7

Lights

Item Description Function

(1) TouchPad light Amber—The TouchPad is disabled.

(2) Caps Lock light On—The Caps Lock is on.

(3) Power light ●On—The computer is on.

●Flashing—The computer is in Sleep.

●Off—The computer is off or in Hibernation.

(4) Volume Mute light Amber—The computer sound is off.

(5) Wireless light ●White—An integrated wireless device, such as a

wireless local area network (WLAN) device and/or

a Bluetooth® device, is detected.

●Amber—No wireless devices are detected.

(6) Fingerprint Reader light ●White—The fingerprint was read.

●Amber—The fingerprint was not read.

8 Chapter 2 External component identification

Buttons and Fingerprint Reader (select models only)

Item Description Function

(1) Power button Press the Power button to:

●Turn on the computer.

●Initiate Sleep.

●Exit Sleep.

●Exit Hibernation.

If the computer has stopped responding and Windows

shutdown procedures are ineffective, press and hold the

Power button for at least five seconds to shut down the

computer.

For more information about the power settings, select

Start > Control Panel > System and Security >

Power Options.

(2) Fingerprint Reader (select models only) Allows a fingerprint logon to Windows, instead of a

password logon.

For information about changing the factory settings, see Help and Support.

Top components 9

Keys

Item Description Function

(1) esc esc key Press the and fn keys at the same time to display

system information.

(2) E-mail key Opens a new e-mail in the default e-mail client.

(3) Media Application key Launches the MediaSmart application.

(4) Web Browser key Launches the default web browser.

(5) Print key Sends the currently-active document to the default printer.

(6) Calculator key Launches the Calculator application.

(7) fn fn key Press the key at the same time as a function key or the

esc key to execute frequently used system functions.

(8) Windows Logo key Displays the Windows Start menu.

(9) Function keys Press a function key and the fn key at the same time to

execute frequently used system functions.

(10) Windows Application key Displays a shortcut menu for items beneath the pointer.

(11) QuickLock key Initiates QuickLock.

(12) Backlight key Turns the backlit keyboard on or off.

10 Chapter 2 External component identification

Front components

Description Function

Speakers Produce sound.

Right-side components

Item Description Function

(1) USB ports (2) Connect optional USB devices.

(2) Optical drive Reads optical discs and, on select models, writes to

optical discs.

(3) Optical Drive light Flashing—Accessing the optical drive.

(4) Hibernate light White—The computer is in Hibernate.

(5) Hard Disk Drive light ●White—The hard disk drive is active.

●Amber—The hard disk drive is parked.

(6) AC Adapter light ●On—The computer is connected to external power.

●Off—The computer is not connected to external

power.

(7) Power connector Connects an AC adapter.

(8) Security cable slot Connects an optional security cable. The security cable is

designed to act as a deterrent, but might not prevent the

computer from being mishandled or stolen.

Front components 11

Left-side components

Item Description Function

(1) Vents (2) Enable airflow to cool internal components.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal

for the internal fan to cycle on and off during routine

operation.

(2) External Monitor port Connects an external VGA monitor or projector.

(3) RJ-45 (network) jack Connects a network cable.

(4) HDMI port Connects an optional video or audio device, such as a

high-definition television, or any compatible digital or

audio component.

(5) eSATA/USB port (select models only) Connects an optional high-performance eSATA

component, such as an eSATA external hard drive, or

connects an optional USB device.

NOTE: Depending on the computer model, the

computer might include only a USB port.

(6) USB port Connects an optional USB device.

(7) Audio-in (microphone) jack Connects an optional computer headset microphone,

stereo array microphone, monaural microphone.

(8) Audio-out (headphone) jack Produces sound when connected to optional powered

stereo speakers, headphones, ear buds, a headset, or

television audio.

(9) SD card reader Reads SD cards that are inserted into the reader.

12 Chapter 2 External component identification

Display components

Item Description Function

(1) Internal microphones (2) Record sound.

(2) Webcam light On—The webcam is in use.

(3) Webcam Records video and captures still photographs.

14 Chapter 2 External component identification

Wireless antennas

Two antennas send and receive signals from one or more wireless devices. These antennas are not

visible from the outside of the computer.

NOTE: For optimal transmission, keep the areas immediately around the antennas free from

obstructions.

To review wireless regulatory notices, see the country-specific section of the Regulatory, Safety and

Environmental Notices chapter in Help and Support.

Wireless antennas 15

3 Illustrated parts catalog

Service tag

When ordering parts or requesting information, provide the computer serial number and model

description provided on the service tag.

16 Chapter 3 Illustrated parts catalog

Item Description Function

(1) Serial number (s/n) This is an alphanumeric identifier that is unique to

each product.

(2) Part number/Product number (p/n) This number provides specific information about the

product's hardware components. The part number

helps a service technician to determine what

components and parts are needed.

(3) Warranty period This number describes the duration of the warranty

period for the computer.

Service tag 17

Computer major components

18 Chapter 3 Illustrated parts catalog

Item Description Spare part number

(1) 39.6-cm (15.6-in), high definition (HD) display assembly with low light VGA webcam and two

microphones (includes wireless antenna transceivers and cables) for use in:

BrightView, black computer models 603647-001

BrightView, white computer models 603648-001

BrightView, red computer models 603649-001

BrightView, chrome computer models 603650-001

BrightView, midnight blue computer models 615932-001

BrightView, black computer models with WiMAX 629279-001

BrightView, etched computer models with WiMAX 629280-001

BrightView, Rossignol Special Edition AT (Attraxion) computer models 635372-001

BrightView, Rossignol Special Edition KP (Koopman) computer models 635373-001

BrightView, etched computer models 595131-001

Touchscreen computer models 631019-001

NOTE: For more information about display assembly spare part numbers, see

Display assembly components

on page 28.

(2) Power button board (includes cable) 603682-001

(3) Keyboard—Dura-coat, island-style keyboard (includes keyboard cable) for use in:

Adriatic Region 597635-BA1

Belgium 597635-A41

Brazil 597635-201

Czech Republic 597635-221

Czech Republic Rossignol Special Edition AT (Attraxion) 635376-221

France 597635-051

France Rossignol Special Edition AT (Attraxion) 635376-051

French Canada 597635-121

Germany 597635-041

Germany Rossignol Special Edition AT (Attraxion) 635376-041

Greece 597635-DJ1

Hungary 597635-211

Israel 597635-BB1

International use 597635-B31

International use Rossignol Special Edition AT (Attraxion) 635376-B31

Italy 597635-061

Computer major components 19

Item Description Spare part number

Italy Rossignol Special Edition AT (Attraxion) 635376-061

Japan 597635-291

Latin America 597635-161

Korea 597635-AD1

Norway 597635-DH1

Norway Rossignol Special Edition AT (Attraxion) 635376-DH1

Portugal 597635-131

Russia 597635-251

Saudi Arabia 597635-171

Spain 597635-071

Spain Rossignol Special Edition AT (Attraxion) 635376-071

Switzerland 597635-BG1

Switzerland Rossignol Special Edition AT (Attraxion) 635376-BG1

Taiwan 597635-AB1

Thailand 597635-281

Turkey 597635-141

United Kingdom 597635-031

United Kingdom Rossignol Special Edition AT (Attraxion) 635376-031

United States 597635-001

Backlit keyboard —Dura-coat, island-style keyboard (includes keyboard cable) for use in:

Adriatic Region 597630-BA1

Belgium 597630-A41

Brazil 597630-201

Czech Republic 597630-221

France 597630-051

French Canada 597630-121

Germany 597630-041

Greece 597630-DJ1

Hungary 597630-211

Israel 597630-BB1

International use 597630-B31

Italy 597630-061

20 Chapter 3 Illustrated parts catalog

Item Description Spare part number

Discrete graphics memory and a 35 W processor 603691-001

(10) Processor (includes replacement thermal material)

Intel Core i7-840QM processor with 1.86 GHz, SC turbo up to 3.2GHz, Quad 45 W 612260-001

Intel Core i7-820QM processor with 1.73 GHz, SC turbo up to 3.06GHz, Quad 45

583053-001

Intel Core i7-740QM processor with 1.73 GHz, SC turbo up to 2.93 GHz, Quad 45

612259-001

Intel Core i7-720QM processor with 1.6 GHz, SC turbo up to 2.8 GHz, Quad 45 W 586170-001

Intel Core i5-580M processor with 2.66 GHz, SC turbo up to 3.33 GHz, Dual 35 W 625825-001

Intel Core i5-560M processor with 2.66 GHz, SC turbo up to 3.33 GHz, Dual 35 W 625824-001

Intel Core i5-540M processor with 2.53 GHz, SC turbo up to 3.06 GHz, Dual 35 W 594188-001

Intel Core i5-520M processor with 2.4 GHz, SC turbo up to 2.93 GHz, Dual 35 W 594187-001

Intel Core i5-480M processor with 2.66 GHz, SC turbo up to 2.93 GHz, Dual 35 W 634693-001

Intel Core i5-460M processor with 2.53 GHz, SC turbo up to 2.8 GHz, Dual 35 W 626039-001

Intel Core i5-450M processor with 2.4 GHz, SC turbo up to 2.66 GHz, Dual 35 W 613585-001

Intel Core i5-430M processor with 2.26 GHz, SC turbo up to 2.53 GHz, Dual 35 W 597624-001

Intel Core i3-390M processor with 2.66 GHz, Dual 35 W 634692-001

Intel Core i3-380M processor with 2.53 GHz, Dual 35 W 625823-001

Intel Core i3-370M processor with 2.4 GHz, Dual 35 W 613584-001

Intel Core i3-350M processor with 2.26 GHz, Dual 35 W 597623-001

Intel Pentium P6300 processor with 2.26 GHz 635500-001

Intel Pentium P6200 processor with 2.13 GHz 625831-001

Intel Pentium P6100 processor with 2.00 GHz 613587-001

Intel Pentium P6000 processor with 1.86 GHz 613586-001

(11) System board (includes replacement thermal material) for use with:

ATI Mobility Radeon HD 6550 graphics, 1024-MB dedicated memory, and a dual-

core processor

631044-001

ATI Mobility Radeon HD 6370 graphics, 512-MB dedicated memory, and a dual-core

processor

631042-001

ATI Mobility Radeon HD 5650 graphics, 1024-MB dedicated memory, and a quad-

core processor with WiMAX (Worldwide Interoperability for Microwave Access)

630278-001

ATI Mobility Radeon HD 5650 graphics, 1024-MB dedicated memory, and a quad-

core processor

615278-001

ATI Mobility Radeon HD 5650 graphics, 1024-MB dedicated memory, and a dual-

core processor with WiMAX

630279-001

22 Chapter 3 Illustrated parts catalog

BrightView display assembly spare parts

Item Description Spare part number

(1) Display bezel 603651-001

Display bezel (Rossignol Special Edition AT (Attraxion)) 638394-001

(2) BrightView display panel 595130-001

(3) Display Hinge Kit (includes left and right hinges) 603656-001

(4) Webcam/microphone module (includes cable) 603660-001

(5) Display Cable Kit 603657-001

Display Cable Kit with WiMAX 629284-001

(6) Display hinge covers 603661-001

(7) Display enclosure (includes wireless antenna transceivers and cables and logo LED

board and cable)

Midnight blue 615933-001

30 Chapter 3 Illustrated parts catalog

Produkt Specifikationer

Mærke:	HP
Kategori:	Bærbare computer
Model:	Pavilion dv6-3053ee
Bredde:	378 mm
Dybde:	245 mm
Vægt:	2450 g
Brugervejledning:	Ja
Produktfarve:	Sort
Produkttype:	Notebook
Pakkevægt:	345 g
Pakkedybde:	160 mm
Pakkebredde:	450 mm
Skærm diagonal:	15.6 "
Skærmopløsning:	1366 x 768 pixel
Berøringsskærm:	Ja
Kompatible hukommelseskort:	Memory Stick (MS), MMC, MS PRO, SD, xD
Wi-Fi:	Ja
Bluetooth:	Ja
Batteriteknologi:	Lithium-Ion (Li-Ion)
Formfaktor:	Muslingeskal
HD-type:	HD
Naturligt aspektforhold:	16:9
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Antal HDMI-porte:	1
DVI-port:	Ingen
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	3
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Processorkerner:	2
Driftstemperatur (T-T):	0 - 35 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Intern hukommelse:	4 GB
Hurtig start guide:	Ja
Kabler inkluderet:	Vekselstrøm
Operativsystem installeret:	Windows 7 Home Premium
Kabelteknologi:	10/100/1000Base-T(X)
Netværksstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
AC-adapter inkluderet:	Ja
Indbygget kortlæser:	Ja
HDD kapacitet:	500 GB
LED-baggrundsbelysning:	Ja
Antal indbyggede højttalere:	2
Batterilevetid (maks.):	- t
Intel® Wireless Display (Intel® WiDi):	Ingen
Bæredygtighedscertifikater:	ENERGY STAR
Processorfrekvens:	2.26 GHz
Processorserie:	Intel® Core™ i5
Processor boost frekvens:	2.53 GHz
Processortråde:	4
Processor-cache:	3 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Maksimal intern hukommelse:	8 GB
Hukommelse form faktor:	SO-DIMM
Samlet lagringskapacitet:	500 GB
Lagermedie:	HDD
On-board grafikkort, model:	Intel® HD Graphics
Diskret grafikadaptermodel:	AMD Mobility Radeon HD 5470
On-board grafikkort:	Ja
Diskret grafikadapter:	Ja
Indbygget grafikadapterfamilie:	Intel® HD Graphics
Indbygget mikrofon:	Ja
Mikrofonindgang:	Ja
S/PDIF-udgang:	Ingen
Cardbus PCMCIA slot type:	Ingen
Smartcard slot:	Ingen
Opladningsport type:	DC-in-stik
Pegeredskab:	Clickpad
Numerisk tastatur:	Ingen
Tastatur i fuld størrelse:	Ja
Tastatur i ø-stil:	Ja
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Vekselstrømsadapter strøm:	90 W
Slot til kabellås:	Ingen
Driftshøjde:	-15 - 3048 m
Ikke-drift højde:	-15 - 12192 m
Hukommelsesstik:	2x SO-DIMM
Processorproducent:	Intel
Processormodel:	i5-430M
Tilslutning af hovedtelefoner:	3,5 mm
Oprindelsesland:	Kina
Drivere inkluderet:	Ja
Antal VGA-porte (D-sub):	1
Berøringsskærmstype:	Kapacitiv
Garantibevis:	Ja
Optisk drevtype:	DVD Super Multi DL
Antal battericeller:	6
Prøvesoftware:	Norton Online Backup
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	1
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ingen
Intel® Virtualization Technology (VT-x):	Ja
Berøringsteknologi:	Multi-touch
HDD-grænseflade:	SATA
Windows taster:	Ja
Tilslutning af mikrofon:	3,5 mm
Bus type:	DMI
Processorgeneration:	4th gen Intel® Core™ i5
Intel® Flex Memory Access:	Ja
Intel® Trusted Execution Teknologi:	Ingen
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ja
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
HDD hastighed:	7200 rpm
Processor sokkel:	BGA 1288
Processor litografi:	32 nm
Stepping:	C2
Thermal Design Power (TDP):	35 W
Maksimalt antal PCI Express-kanaler:	16
PCI Express slots version:	2.0
PCI Express-konfigurationer:	1x16
Fejlkorrigerende kode understøttet af processor:	Ingen
Tjunction:	105 °C
Processor front side bus:	- Mhz
Systembus-hastighed:	2.5 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Arrandale
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ja
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Mindre Forretnings-fordele (Intel® SBA):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® Demand Based Switching:	Ingen
Termiske overvågningsteknologier:	Ja
Fysisk adresseudvidelse (PAE):	Ja
Intel® Dual Display Capable Teknologi:	Ja
Intel® FDI Teknologi:	Ja
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ja
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ja
Processor-pakke størrelse:	rPGA 37.5x 37.5, BGA 34x28 mm
Processor kode:	SLBPM
Grafisk og IMC litografi:	45 nm
Processor ARK ID:	43537
Hukommelseslayout (slots x størrelse):	2 x 2 GB
Antal installerede HDD'er:	1
Indbygget grafikadapter basefrekvens:	500 Mhz
Indbygget grafikadapter dynamisk frekvens (maks.):	766 Mhz
Diskret grafikhukommelsestype:	GDDR3
CPU-multiplikator (bus/kerneforhold):	17
Operativsystemets arkitektur:	64-bit
Understøttede instruktionssæt:	SSE4.1, SSE4.2
Intel® Smart Cache:	Ja
LightScribe:	Ja
Højde (front):	30.8 mm
Højde (bagside):	36 mm
Diskret grafikadapterhukommelse:	0.512 GB
Antal behandling Die transistorer:	382 M
Behandling Die størrelse:	81 mm²
Maksimal intern hukommelse (64-bit):	8 GB
Højttalerproducent:	Altec Lansing
Antal eSATA/USB 2.0-porte:	1
Fysisk adresse udvidelse (PAE):	36 Bit
