Step 2

Screw mount to pipe securely, engag-

ing a minimum of of pipe into 1/2”

mount (Fig 4). When aligned to desired

locaon, ghten set screw (Fig 1, #2)

to 30 36 in lbs of torque (this is ap-- -

proximately when the set screw will

stop moving and the long arm of the

“long arm hex wrench” (Fig 1, #3) will

start to bend slightly).

What s Included’

QTY —Small Ceiling Mount BK/WH1

QTY — x 3/8" PPH and QTY — Machine Screw Flat Washer (Fig 1, #1)1 1/4"-20 2 1/4”

QTY — cup point set screw (Fig 1, #2)1 10/32 x 1/4”

QTY — long arm hex wrench (for set screw) (Fig 1, #3)1 3/32”

Fig 1

Rev 2.1

5/15/2020

HCM-1C

Small Base Camera

Ceiling Mount

Setup Guide

Mounng Instrucons

Step 1

Screw NPT pipe, or pipe nipple, to a properly 1”

installed mounng plate or pipe ange (Fig 2).

Tighten unl pipe can no longer be ghtened with

a pipe wrench.

If using a plate or ange you must us a 1.5” 1.5” -

1” reducing bushing (Fig 3).

NOTE: Plate/ange, reducer bushing and NPT 1”

pipe or nipple are not included.

Fig 2 Fig 4

For more informaon on HuddleCamHD

mounts and other products please visit:

hps://huddlecamhd.com/ Rev 2.1

5/15/2020

HuddleCamHD

HC- -WEBCAM 94

HC-GO

HC- -EPTZ XXX

HC3X-XX-G2

HC3XA-XX

HC3XW-XX-G2

HC10X USB2- -XX

HC10XA-XX

HC10X-XX-G3

HC20X-XX-G2

Step 4 / 4

Pass cabling through pipe or dress

to outside of pipe and connect for

a clean installaon.

Mounng Instrucons Connued...

Mount Compability

Step 3 / 4

Mount camera upright to top of mount

or invert to boom of mount with includ-

ed 1/4 20 machine screw. (Fig 1, # 1) U--

lize (0,1,2) machine screw at wash-1/4”

ers as required. (Fig 1, #1) Note: 1/4”

machine screw at washers are to be

used depending upon depth of thread

insert in base of camera, in order to

achieve a snug t.

Other Cameras…

This mount has been

designed for use with most

small based cameras ulizing

a 1/4 20” -mounng hole as

can be found on SONY,

Panasonic, Cisco, Polycom

and Vaddio cameras.

PTZOpcs

PT 80- -WEBCAM

PTEPTZ ZCAM-XXX-

PTVL-XXX- ZCAM

PT12X-XXX-ZCAM

PT20X-XXX- ZCAM

PT12X-XXX XX- - G2

PT20X-XXX XX- - G2

PT30X-XXX XX- - G2
