Side 1/2

T e c h n o l o g y G m b H

www.raidsonic.de

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

4x 2.5“ U.2 SSD Backplane

Key features

• Host connector: 4x U.2 / Mini SAS HD (SFF-8643)

• Supports U.2 (SFF-8639) SSD, up to 32 Gbit/s

• Full aluminium and steel backplane for 5.25“ bay

• Individually lockable carriers to secure the SSDs

• LED indicator for power and access

• Two 40x40x10 mm cooling fans

• Supports Windows®

Fast, faster, U.2 NVMe

This backplane provides space for 4x 2.5“ U.2 or even SATA/ SAS SSDs. The system works reliablly and quiet and cools the SSDs thanks to two 40x40 mm fans,

which are adjustable in two levels. The high-quality manufacturing rounds off the package.

Packing content

1x IB-2242U2K, 8x frame screw, 16x HDD tray screw, 2x key,

1x manual *cables not included!

Model

Article no.

EAN code

Brand

Colour

Material

Interface to host computer

SSD size

SSD height

SSD interface

SSD capacity

Interface standard

Transfer rate

Space required

HotSwap

IB-2242U2K

60799

4250078171355

ICY BOX

Black

Aluminium and Metal

4x Mini SAS HD (SFF-8643)

2.5“

Up to 15 mm

U.2 (SFF-8639)

Unlimited

PCIe 3.0 x4

Up to 32 Gbit/s

1x 5.25“ bay

Yes

Technical data

Cooling

Fan control

Lock

LED

Power supply

Operating system

System requirements

Two 40x40 mm fans

2 levels

Yes

Power and access

SATA 15 Pin

Windows®

4x free U.2 port (SFF-8643) on your host computer,

4x U.2 cable (SFF-8643 to SFF-8643). Other U.2

ports on the motherboard with PCIe 3.0 p1-x4 support, e.g. Slimline SAS (SFF-8654),

Oculink (SFF-8611), can be used with the appropriate cables or adapters. If a PCIe

expansion card with 4x Mini SAS HD (SFF-8643) port is used, the motherboard must

support PCIe x4x4x4x4 mode! The host on the motherboard must support the HotPlug

function in order to support the HotSwap function of the U.2 SSD!

ICY BOX

IB-2242U2K

T e c h n o l o g y G m b H

www.raidsonic.de

4x 2.5“ U.2 SSD Backplane

The sprinter in the storage segment

U.2 is ﬁnding its way more and more into professional storage solutions. No surprise, U.2 delivers PCIe

(NVMe) data transfer rates of up to 32 Gbit/s into the 2.5“ format and supports HotSwap. The IB-

2242U2K supports 2.5“ SSDs with a hight of up to 15 mm.

Cooling in two levels

The IB-2242U2K contains two 40 mm fans for optimal cooling. The fans are adjustable in two levels with a

switch on the back side and offer the right mode for every application.

Under lock and key

Data security is very important for ICY BOX. Each of the four carriers can be locked separately thank to the

integrated locks and thus protect your SSDs against unauthorized access.

Logistical data

Packing unit:

Total weight:

Gross weight: : (with packing)

Net weight:

Dimension/Carton:

Dimension :(with packing)

Dimension of article:

Country of Origin:

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • • info@raidsonic.de www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

8 pcs. / carton

8 kg

0.889 kg

0.708 kg

440x335x215 mm

214x195x80 mm

145x150x41 mm

China

ICY BOX IB-2242U2K
