Side 1/2

T e c h n o l o g y G m b H

www.icybox.de

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

Monitor stand with table mount for

two monitors up to 32" (81 cm)

Key features

• Space-saving design for extra workspace on the desk

• Freely swivelling monitor arm for different viewing angles on the monitor

• Stepless height adjustment for an ergonomic sitting position

• Built-in spring tension gauge for perfect weight adjustment of the monitor

• Cable management for an organised and tidy workspace

• Optional mounting with clamp base or table feed-through

Model

Article no.

EAN code

Brand

Colour

Material

Maximum size of monitor

Number of monitors

Max. weight of monitor

Mounting

VESA® compatible

Swivel (Hinge) - VESA®

Tilt (Hinge) - VESA®

Rotate (Pivot) - VESA®

Base - Rotate (Pivot)

Tilt (arm)

Tilt

Swivel (Hinge)

Max arm extend

Max arm height

Table thickness

IB-MS514-TSS

60874

4250078172079

ICY BOX

Silver/white

Aluminium, plastic, steel

32" (81cm)

1 – 9 kg / monitor arm

Table feed-through or clamp base

75x75, 100x100

+180° – -180°

+45° – -45°

360°

+- 90° / +- 180°

+180° – -180°

+45° – -45°

+90° – -90°

509 mm / monitor arm

450 mm

For clamp base: 10 – 85 mm

For table feed-through: 10 – 80 mm

Technical data

Packing content

IB-MS514-TSS, allen wrench, set of screws,

quick installation guide

ICY BOX

IB-MS514-TSS

T e c h n o l o g y G m b H

www.icybox.de

Monitor stand with table mount for two monitors up to 32" (81 cm)

Space-saving

Thanks to its slim design, the IB-MS514-TSS is perfect for smaller workspaces despite the use of two monitors.

With three joints each, the monitor arms can be moved to almost any position and ergonomically adapt to the

individual viewing direction through tilt and height adjustment.

Where are the cables?

With Easy Cable™ Management, the monitor cables can be cleverly arranged along the monitor arms. This

keeps your workspace visually appealing and prevents cables from getting tangled with other work utensils.

The ability to move the monitor arm joints is not impaired by the cable management.

Firmly and securely mounted

If your desk has a cut-out, you can securely attach the dual monitor arm to tabletops with a thickness of 10 to

80 mm using a table grommet. For tabletops with a thickness of 10 to 85 mm, you can alternatively mount it

using a clamping foot, accessories are included.

Logistical data

Packing unit:

Total weight:

Gross weight : (with packing)

Net weight:

Dimension/carton:

Dimension :(with packing)

Dimension of article:

Country of origin:

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.icybox.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

4 pcs./carton

24.60 kg/carton

6.00 kg

5.25 kg

420x550x320 mm

270x400x145 mm

100x1074x509 mm

China

ICY BOX IB-MS514-TSS

Produkt Specifikationer

Mærke:	Icy Box
Kategori:	Ikke kategoriseret
Model:	IB-MS514-TSS
Bredde:	509 mm
Dybde:	100 mm
Højde:	1074 mm
Vægt:	5250 g
Produktfarve:	Silver, White
Pakkevægt:	6000 g
Pakkedybde:	145 mm
Pakkebredde:	270 mm
Pakkehøjde:	400 mm
Panel montering grænseflade:	75 x 75, 100 x 100 mm
Husmateriale:	Aluminium, Plastic, Steel
Pakketype:	Kasse
Monteringstype:	Skrivebord
Nem at installere:	Ja
Hovedkassen højde (udvendigt):	320 mm
Hovedkassens længde (udvendigt):	550 mm
Hovedkassens bruttovægt (udvendigt):	24600 g
Hovedkassens bredde (udvendigt):	420 mm
Oprindelsesland:	Kina
Højdejustering:	Ja
Drejevinkel område:	-180 - 180 °
Hældningsvinkelområde:	-45 - 45 °
Produkter pr. hovedkasse (udvendigt):	4 stk
Montering:	Klemme/bolt gennemgang
Rotationsvinkel:	360 °
Rotation:	Ja
Maksimal vægtkapacitet:	9 kg
Pivot vinkel:	-90 - 180 °
Hældningsindstilling:	Ja
Forbedret kabelstyring:	Ja
Maksimal skærmstørrelse kompatibilitet:	32 "
Antal understøttede skærme:	2
Minimal skærmstørrelse kompatibilitet:	- "
Montering interface kompatibilitet (min.):	75 x 75 mm
Montering interface kompatibilitet (maks.):	100 x 100 mm
Forlængelsesarm (max.):	509 mm
Skrivebord tykkelse (min):	10 mm
Skrivebord tykkelse (maks.):	85 mm
