Side 1/3

T e c h n o l o g y G m b H

www.raidsonic.de

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

Full metal holder for two screens with

size up to 24" with a free standing

base

Key features

• The IB-AC638 remains the classic multiple stand design and makes it more

slim and ergonomic

• Easy Cable

™

Management cover & column

to make the cables tidy & well arranged

• Smart Torque Adjust

™

is always available at every Hinge Module

to meet various weights implemented.

• Horizontally adjustable VESA

support for a wide range of screen dimensions

• For screens size up to 24" diagonal screen measurement

• Special metal foot design to guarantee stability

• Simple monitor height setup

• Supports 100x100 and 75x75 VESA

standards

Model

Article no.

EAN

Brand

Colour

Material

Maximum size of monitor

IB-AC638

70557

4250078161035

ICY BOX

Silver

Steel / plastic / aluminium alloy

24"

Technical data

Number of monitors

Max weight arm total

VESA - Swivel (Hinge)

VESA - Tilt (Hinge)

VESA - Rotate (Pivot)

Base - Rotate (Pivot)

Mounting

6 kg / monitor

+/- 15° horizontal

+/- 15° vertical

360° horizontal

360° vertical

Full metal base

Packing content

IB-AC638, allen wrench, set of screws, quick installation guide

Torque adjustment Easy mount adjustment Cable management and

hight adjustment

Swivel and tilt adjustable VESA mount

ICY BOX

IB-AC638

T e c h n o l o g y G m b H

www.raidsonic.de

Full metal holder for two screens with size up to 24"

with a free standing base

Slim and ergonomically designed

The stand for two monitors, each with a maximum screen size of 24" (screen diagonal: 61 cm, max 6 kg

per monitor) is made entirely of high quality steel and an aluminum alloy and provides very high stability.

The design has also been taken to ensure that it doesn’t take up too much space on the table, and that the

use of screens is ergonomically.

For optimal order...

At work or at home on your PC, the monitor holder has a Easy Cable

™

cable guide on the back. In order

to balance the weights of different weighted screens well, a Smart Torque Adjust

™

torque adjustment ensures

that each VESA mount is stable.

User-friendly orientation

The various components of the mount can be rotated in different angles up to 360°. It also has the ability

to shift the entire screen mount to the left or right, or direct the screens with an inclination angle of

up to 15° depending on your own wishes.

Logistical data

Packing unit:

Total weight:

Gross weight : (with packing)

Net weight:

Dimension/carton:

Dimension :(with packing)

Dimension of article:

Country of origin:

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany

Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de

Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.

5 pcs./carton

17.3 kg/carton

3.22 kg

2.61 kg

492x492x304 mm

95x472x272 mm

347x716x55 mm

Taiwan

ICY BOX IB-AC638

Produkt Specifikationer

Mærke:	Icy Box
Kategori:	Ikke kategoriseret
Model:	IB-AC638
Bredde:	716 mm
Dybde:	347 mm
Højde:	550 mm
Vægt:	2610 g
Produktfarve:	Sølv
Pakkevægt:	3220 g
Pakkedybde:	95 mm
Pakkebredde:	472 mm
Pakkehøjde:	272 mm
Husmateriale:	Aluminium, Plastic, Steel
Monteringstype:	Skrivebord
Hældningsvinkelområde:	-15 - 15 °
Rotationsvinkel:	360 °
Maksimal vægtkapacitet:	12 kg
Maksimal skærmstørrelse kompatibilitet:	24 "
Drejevinkel:	15 °
Antal understøttede skærme:	2
Minimal skærmstørrelse kompatibilitet:	- "
Montering interface kompatibilitet (min.):	75 x 75 mm
Montering interface kompatibilitet (maks.):	200 x 100 mm
Maksimal vægtkapacitet (pr. skærm):	6 kg
