Quick installation guide IB-PCI210

1. Package contents

1x IB-PCI210, 1x full proﬁle bracket, 1x screw set, 1x manual

2. Installation

2.1 Mount the M.2 SSD with a slight angle into the M.2 slot.

2.2 Fasten the SSD module with the screw.

2.3 Make sure the computer is turned off and all power cables are

disconnected from the system.

2.4 Open the computer case and plug the IB-PCI210 into an available

PCIe slot.

2.5 Secure the bracket on the housing of the PC.

2.6 Close the case and restart your PC.

2x M.2 SSD to PCIe 2.0 p1-x1 card with RAID

Quick installation guide IB-PCI210

3. RAID setting

ATTENTION: Setting or changing the RAID mode requires the device

to re-format the drives. This will erase all data on the SSDs drives that

are being formatted. Make sure to backup all existing data ﬁrst!

3.1 Select the mode you wish to install.

3.2 Press the Mode button for 5 seconds to conﬁrm your selection.

2x M.2 SSD to PCIe 2.0 p2-x1 card with RAID

Mode button

Produkt Specifikationer

Mærke:	Icy Box
Kategori:	Ikke kategoriseret
Model:	IB-PCI210
Bredde:	65 mm
Dybde:	125 mm
Højde:	5 mm
Vægt:	160 g
Produktfarve:	Grøn
Pakkevægt:	200 g
Pakkedybde:	160 mm
Pakkebredde:	125 mm
Pakkehøjde:	25 mm
Materiale:	Plast
Harmoniseret systemkode (HS):	84733020
Understøttede Windows-operativsystemer:	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64
Understøttede Mac-operativsystemer:	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Værtsgrænseflade:	PCIe
Intern:	Ja
Output-grænseflade:	M.2
RAID-niveauer:	0, 1
Udvidelseskort standard:	PCIe 2.0
Dataoverførselshastighed (maks.):	6 Gbit/sek.
