Requirements and information: Tested for compatibility with following SBC like:

Raspberry Pi

1 Model B+, Pi 2 Model B, Pi

3 Model A+/B/B+, Pi

Zero/ZeroW,

Asus Tinker board /Tinker Board S and other SBC with 40 pin GPIO

Raspberry PI

board not included

Packing content:1x IB-RPA101, 1x quick installation guide

GPIO adapter for Raspberry Pi

The 1 to 2 expansion board is a great way to expand and extend your Raspberry Pi

Key Features

- Raspberry Pi

40 pin GPIO 1 to 2 expansion

- Small size design

- Compatible with all Raspberry Pi

models

- Fits to Raspberry Pi

, Asus Tinker board and other SBC with 40 pin GPIO interface

Assembly

Please follow the drawing to assemble the IB-RPA101.

The information contained in this manual is believed to be accurate and reliable. RaidSonic Technology GmbH

assumes no responsibility for any errors contained in this manual. RaidSonic Technology GmbH reserves the

right to make changes in the speciﬁcations and/or design of the above mentioned product without prior notice.

The diagrams contained in this manual may also not fully represent the product that you are using and are

there for illustration purposes only. RaidSonic Technology GmbH assumes no responsibility for any differences

between the product mentioned in this manual and the product you may have.Raspberry Pi

is a trademark

of the Raspberry Pi Foundation. DisplayPort

™

and the DisplayPort

™

logo are trademarks owned by the Video

ElectronicsStandards Association (VESA

) in the United States and other countries. All other trademarks and

brand names are the Property of their respective owners.

Schnellinstallationsanleitung IB-RPA101

Anforderungen und Informationen: Kompatibel mit folgenden SBC’s, wie z.B.:

Raspberry Pi

1 Model B+, Pi 2 Model B, Pi

3 Model A+/B/B+, Pi

Zero/ZeroW,

Asus Tinker board /Tinker Board S und andere SBC mit 40 pin GPIO

Verpackungsinhalt: 1x IB-RPA101, 1x Schnellinstallationsanleitung

Raspberry PI

nicht enthalten

GPIO Adapter für Raspberry Pi

Der 1 zu 2 Erweiterungsadapter ist eine prakti-

sche Möglichkeit, Ihren Raspberry Pi

zu ergänzen und zu erweitern.

Hauptmerkmale:

- Raspberry Pi

40 polige GPIO 1 auf 2 Erweiterung, kleine Bauform

- Kompatibel mit allen Raspberry Pi

Modellen

- Passend für Raspberry Pi

, Asus Tinker Board und andere SBC mit 40-poliger

GPIO-Schnittstelle.

Zusammenbau

Um das IB-RP101 einzubauen, folgen Sie bitte der Darstellung.

1 to 2 GPIO expansion board for Raspberry Pi

computer

Product overview / Produktübersicht

IB-RPA101

Quick installation guide IB-RPA101

#1- pin is marked with

square shape pad on the PCB

Der #1- pin ist mit einer eckigen

Form auf der PCB markiert

Produkt Specifikationer

Mærke:	Icy Box
Kategori:	Ikke kategoriseret
Model:	IB-RPA101
Bredde:	60 mm
Dybde:	25 mm
Højde:	85 mm
Vægt:	82 g
Produktfarve:	Sort
Produkttype:	Portudvidelse
Pakkevægt:	115 g
Pakkedybde:	103 mm
Pakkebredde:	45 mm
Pakkehøjde:	85 mm
Materiale:	Plast
Oprindelsesland:	Kina
Kapabilitet:	Raspberry Pi
Mærke kompatibilitet:	Raspberry Pi
