Side 1/3
Installation Instructions
Aseptoflex adapter
E330xx / E331xx
706008/00 05/2011
UK
UK
UK
UK
UK
2
Mount
adapter (C) to sensor (A) first,
then sensor + adapter to the pro-
cess connection by means of a nut,
a clamping flange or similar (B).
If it is not possible to slide the fixing
element (B) down over the top of the
sensor: slide it up over the bottom
of the sensor before the adapter is
mounted.
A
B
C
NOTE: A guarantee for a long-term stable and maintenance-free fitting, with no
bug traps in the hygienic sealing of the metal seal (Aseptoflex connection) is only
valid for once-only mounting.
Mounting of the adapter:
Slightly grease the threads and
sealing areas of the sensor and ad-
apter with the lubricating paste (1).
The paste must be suitable and
approved for the application and
compatible with the elastomers
used.
Recommendation: Klüber paste
UH1 84-201 with USDA-H1 appro-
val for the food industry.
Make sure that the O-ring (D) is
correctly positioned.
D
1
