Thank you very much for choosing this Ikegami high quality TV Camera. Please
read this Instruction Manual carefully to keep your Ikegami camera at peak
performance for longer service duration. All Ikegami cameras are designed and
manufactured with utmost care and craftsmanship to provide long life and high
quality performance, if it is properly used and maintained as outlined in this manual.
This high performance TV camera is equipped with a 1/3" highly sensitive CCD
sensor, which has an extremely wide range of spectral response extended into the
near infra-red spectrum and it has a lot of useful facilities and functions to allow for
a wide range of uses in many different applications and conditions.
This Ikegami product is made of ECO friendly components based upon the
companies policy and corporate social responsibility to contribute towards the Global
Environmental Solution for energy conservation and environmental sustainability,
all the components used in this product are Non-hazardous, Non-Toxic , Lead-
Free and conform with Japan's Green Product regulations, the EU's RoHS directive
and other regulations and laws relating to Environmental and Hazardous Chemical
Substances.
Contents
Page
1. Handling precautions .................................................................... E-1
2. General ......................................................................................... E-1
3. Features ....................................................................................... E-2
4. Names of parts and their functions ............................................... E-5
5. Operation ...................................................................................... E-9
5-1. User setup ............................................................................. E-9
5-2. SETUP switches and their functions ..................................... E-9
5-3. Entering the setup mode and its basics ................................ E-10
5-4. Setup procedures .................................................................. E-12
6. Warranty and after-sale service .................................................... E-24
7. Specifications ............................................................................... E-25
8. External Appearance
9. Setup Menu Flow Chart
