Side 1/3
SPECIFICATION:
MODEL NO. : IDX-1530UW
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : Watts 1500
BOX DIMENSION : 328x442x68mm
UNIT DIMENSION : 290x370x30mm
GROSS WEIGHT : 2.42kgs
UNIT WEIGHT : 2.11kgs
When using electrical appliances, basic safety precautions should always be followed, including
the following:
1. Read all instructions carefully.
2. Do not use the Induction Cooker on any metal table.
3. Do not use the Induction Cooker next to devices, which react sensitively to magnet (e.g.
radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, ammable materials, etc. away from the Induction Cooker and from
the convenience outlet where the Induction Cooker is plugged.
5. Before using the Induction Cooker, check if the voltage indicated corresponds with the
convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be
replaced with the same type and size or bring the Induction Cooker to the nearest Authorized
Service Center.
7. Do not use the two-way socket with another appliance.
8. Do not place the unit near gas stove, an electric burner, in heated oven or near any hot
surface.
9. Do not touch the Induction Cooker and the power plug with wet hands.
10. Do not block the ventilation slots of the Induction Cooker. Keep a minimum distance of 10cm
to 20cm away from the wall or from other items.
11. The Induction Cooker’s surface is made of glass, if damaged, unplug immediately.
12. Do not insert objects like wires or tools into the ventilation slots, this may cause electric
shocks.
13. Do not allow the cord to touch the hot surface of the unit.
14. The Induction Cooker does not heat up during cooking, but the heat from the cookware can
be transferred to in the Induction Cooker. Do not touch the hot surface of the glass.
15. Scientic tests have proven that Induction Cookers are safe to use. However, persons with a
pacemaker should keep a minimum distance of 60cm from the unit while using.
16. Do not place any metal kitchen utensils, pan lids, knives or other metal objects on the cooker.
These may heat up when the Induction Cooker is turned on.
17. Do not place any magnetic objects on the glass surface while the Induction Cooker is in use.
18. To protect against electric shock, do not immerse the Induction Cooker in water.
19. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances by person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
20. This induction cooker is intended for tabletop use only.
21. not use the Induction Cooker for other than intended use. Do
22. Not intended for outdoor use.
23. For household use only, not intended for any business purposes.
24. Save this instruction for future references.
25. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this
appliance must not be supplied through an external switching device, such as timer, or
connected to a circuit that is regularly switched on and off by the utility.
1
DESCRIPTION OF PARTS:
OPERATING PRINCIPLE:
Induction Cooker applies the heating principle of the magnetic eld inducing the whorl electric current.
It utilizes the magnetic eld produced by the current passing the loop when the magnetic force line
passes the bottom of the stainless-steel cookware. It produces numberless whorl electric current that
will heat up the stainless-steel cookware rapidly. This process is extremely ecient and minimizes
the use of electricity.
The Imarex Induction Cooker automatically detects if the cookware is induction-ready.
SUITABLE COOKWARES:
Magnetized stainless steel and cast iron
Acceptable pot diameter is 12cm-24cm
NOTE: FOR OPTIMAL PERFORMANCE AND EFFICIENCY, USE POTS THAT ARE WITHIN THE
SIZE OF THE CIRCULAR PRINT ON THE INDUCTION PLATE.
UNSUITABLE COOKWARES:
Non-magnetized stainless steel, aluminum, plastic, glass and Porcelain.
CAUTION:
Do not leave an empty cookware with the Induction Cooker ON
When STIR-FRYING with little oil in the pot, don’t overheat the oil, otherwise it will kindle
easily
When FRYING, the volume of the oil in the pot should be not less than 0.9 liter since little
oil might burn easily
CONTROL PANEL:
2
