Imarflex IDX-3210C Manual

Imarflex Komfur IDX-3210C

Læs gratis den danske manual til Imarflex IDX-3210C (8 sider) i kategorien Komfur. Denne vejledning er vurderet som hjælpsom af 79 personer og har en gennemsnitlig bedømmelse på 3.7 stjerner ud af 40 anmeldelser. Har du et spørgsmål om Imarflex IDX-3210C, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

SPECIFICATION:

MODEL NO. : IDX- C 3210

RATED VOLTAGE : 230Va.c. 60Hz

POWER CONSUMPTION : Watts 3100

BOX DIMENSION : _______________

UNIT DIMENSION : _______________

GROSS WEIGHT : _______________

UNIT WEIGHT : _______________

IMPORTANT SAFEGUARD:

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instructions carefully.

2. Do not use the Induction Cooker on any metal table.

3. Do not use the Induction Cooker next to devices, which react sensitively to magnet (e.g.

radios, TV, cassette recorders, etc.).

4. Keep curtains, furniture, ammable materials, etc. away from the Induction Cooker and

from the convenience outlet where the Induction Cooker is plugged.

5. Before using the Induction Cooker, check if the voltage indicated corresponds with the

convenience outlet (230Va.c.)

6. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should

be replaced with the same type and size or bring the Induction Cooker to the nearest

Authorized Service Center.

7. Do not use the two-way socket with other appliance.

8. Do not place the unit near gas stove, an electric burner, in heated oven or near any hot

surface.

9. Do not touch the Induction Cooker and the power plug with wet hands.

10. Do not block the ventilation slots of the Induction Cooker. Keep a minimum distance of

10cm to 20cm away from the wall or from other items.

11. The Induction Cooker’s surface is made of glass, if damaged, unplug immediately.

12. Do not insert objects like wires or tools into the ventilation slots, this may cause electric

shocks.

13. Do not allow the cord to touch the hot surface of the unit.

14. The Induction Cooker does not heat up during cooking, but the heat from the cookware

may transferred to in the Induction Cooker. Do not touch the hot surface of the glass.

15. Scientic tests have proven that Induction Cookers are safe to use. However, persons

with a pacemaker should keep a minimum distance of 60cm from the unit while using.

16. Do not place any metal kitchen utensils, pan lids, knives or other metal objects on the

cooker. These may heat up when the Induction Cooker is ON.

17. Do not place any magnetic objects on the glass surface while the Induction Cooker is in

use.

18. To protect against electric shock, do not immerse the Induction Cooker in water.

19. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliances by

person responsible for their safety. Children should be supervised to ensure that they do

not play with the appliance.

20. This induction cooker is only intended for tabletop use.

21. Do not use the Induction Cooker for other than intended use.

22. Not intended for outdoor use.

23. For household use only, not intended for any business purposes.

24. Save this instruction for future references.

DESCRIPTION OF PARTS

OPERATING PRINCIPLE:

Induction Cooker applies the heating principle of the magnetic eld inducing the whorl electric

current. It utilizes the magnetic eld produced by the current passing the loop when the

magnetic force line passes the bottom of the stainless steel cookware. It produces

numberless whorl electric current that will heat up the stainless steel cookware rapidly. This

process is extremely ecient and minimizes the use of electricity. The Imarex Induction

Cooker automatically detects if the cookware is induction-ready.

SUITABLE COOKWARES:

 Magnetized stainless steel and cast iron

 Acceptable pot diameter is 12cm-24cm

NOTE: For optimal performance and eciency, use pots that are within

the size of the circular print on the induction plate.

UNSUITABLE COOKWARES:

 Non-magnetized stainless steel, aluminum, plastic, glass and Porcelain.

CAUTION:

 Do not leave an empty cookware with the Induction Cooker ON

 When STIR-FRYING with little oil in the pot, don’t overheat the oil, otherwise the pot may

get damage

 When FRYING, the volume of the oil in the pot should not be ss than 0.9 liters because le

the pot may get damaged

CONTROL PANEL

HOW TO USE:

1. Plug the unit into a convenient outlet Will hear a . “Beep” sound will be hear, ‘OFF’ will

appear on the display and power light indicator will be ashing.

2. Press “ON/OFF” key for standby mode. Will hear a beep sound and ‘ ’ON will appear on

the display.

3. Place the suitable cookware in the center of the induction plate.

4. Power Setting: Function keyPress the “ ” . The digital display shows “1800 (left) & 1300

(right)”, indicating the default power are 1600W & 1200W. Press “ ” or “+“ key to adjust -

the power level. It can be adjusted from 200W to 1800W for the (left induction plate) and

200W to 13 (right induction plate) 00W .

Note: User can choose to adjust either “Power” or “Temp”.

5. Temp Setting: Press the “ ”Function key twice. The digital display shows “240”, indicating

that the default temperature is 240°C. Press “ ” or “+“ key to adjust the temper- ature. It can

be adjusted from 60°C to 240°C.

6. Timer Setting: First, select the desired function, then p timerress the “ ” key The digital .

display shows “0:00” and timer light indicator will lights up, indicating the default time is 0

minute. Press “ ” or “+“ key to adjust the temperature. I- t can be adjusted from 0:01 to

3:00.

7. Lock Setting: Press “Lock” key to lock all the settings. The lock light indicator will lights

up. Under lock status, induction cooker would not respond to any key press. Press the

“Lock“ key for 3 seconds to unlock the “Lock” status.

8. After use, Press the “ON/OFF” key to switch back to sleeping mode.

9. Unplug the unit every after use.

TROUBLESHOOTING:

PROBLEM

POSSIBLE CAUSE

RECOMMENDATION

 No Pot/Pot not suitable

 Place a suitable pot into the induction plate

 Electrical Malfunction

 Bring the unit to the nearest Imarex Service

Center

 Damage Temperature

Sensor

 Bring the unit to the nearest Imarex Service

Center

 Voltage too high

 Unplug the unit and wait for about two

minutes before plugging in.

 Voltage too low

 Unplug the unit and wait for about two

minutes before plugging in.

 Temperature in the

induction plate is too

high

 Wait for a few minutes to let the induction

plate cool down. You may also use the

temperature setting to continue cooking.

 Damage Exhaust Fan

 Bring the unit to the nearest Imarex Service

Center

CLEANING AND MAINTENANCE:

1. Turn off the power and pull out the plug before cleaning.

2. Clean the unit after it cools down completely.

3. Select proper detergent to remove the dirt.

4. Use clean damp cloth to clean the unit after removing the dirt.

5. Do not clean the unit directly with water.

6. Clean the induction glass plate and pan before cooking, otherwise, food residue may get

dicult to clean and the plate may get discoloration.

7. You may clean air vent or air entry’s dirt by vacuum cleaner to suck or by cotton. If there

is dirt with oil, you can use toothbrush with a little detergent to clean the surface. Never a

clear inside with water or any kind of liquid.

8. Do not use caustic detergents to clean the unit. It may damage the unit by chemical

reaction.

9. Do not use benzene, thinner, scrubbing brush or polishing powder to clean the induction

cooker.

REMINDER: Please do not forget to ll up and send the warranty card with receipt to

our email address imarexfb@evergoodinc.com

Distributed By: Topgadget Distributions, Inc.

2120 A. Linao St. Malate, Manila

Made in China

Produkt Specifikationer

Mærke:	Imarflex
Kategori:	Komfur
Model:	IDX-3210C
