Side 1/2

HOW TO USE THE ROTISSERIE

1. Set the Thermostat Control to max.

2. Set the Heat Selector Switch (up, down or all).

3. Insert the pointed end of spit through Skewer, making sure the points of

Skewer face in the same direction as pointed end of the Spit. Slide

Skewer towards square of the Spit and secure with Thumbscrew.

4. Place food to be cooked on the Spit by running the Spit directly through

the center of the food.

5. Place the second Skewer into the other end of the Spit and secure Skewer

with the Thumbscrew.

6. Insert the point end of the Spit into the Drive Socket. Make sure that the

Square end of the Spit rests on the Spit Support.

7. Switch ON the Convection/Rotisserie Switch.

8. Turn the Timer Switch to desired position.

9. Once the cooking cycle ends, remove the spit by placing the Hooks of the

Skewer holder under the grooves on other side of the Spit. Lift the left

side of the Spit first by lifting it up and out, then pull the Spit out of the

Drive Socket and carefully remove the roasted food and place it on a

platter.

HOW TO USE THE CONVECTION

1. Set the Thermostat control to desired temperature.

2. Set the Heat Selector Switch (up, down or all).

3. Switch ON the Convection/Rotisserie Switch.

4. Set the Timer to desired cooking tim e.

CLEANING AND MAINTENANCE

1. Before moving or cleaning, make sure to unplug and allow the unit to cool.

2. Use a wet damp cloth in cleaning the unit.

3. Wash Crumb Tray, Rack, Tray Handle and Skewer with soap and water,

let it dry.

4. Do not immerse the unit in water.

5. Do not use abrasive materials to avoid scratches.

REMINDER: Please do not forget to ll up and send the warranty card

-3-

SPECIFICATION

MODEL NO. -280CRS : IT

RATED VOLTAGE Va.c. ~ 60Hz : 230

POWER CONSUMPTION : 1500 watts

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instruction carefully.

2. Before using the unit, check if the voltage indicated corresponds with the

convenience outlet (230Va.c.).

3. Do not use two-way socket with other appliance.

4. Do not use any appliance with a damaged cord or plug, it should be replaced with

the same type and size or bring the unit to the nearest Imarex Authorized Service

Center.

5. Do not allow cord to touch hot surface of the unit.

6. Avoid touching the unit while cooking is in progress and use the tray handle when

taking the food in/out to avoid burns.

7. While the unit is in use avoid the glass from getting wet to avoid breakage.

8. Children should be supervised to ensure that they do not play with the appliance.

9. This appliance is not intended to use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning the use of the

appliances by a person responsible for their safety.

10. Minor metal contraction sound may occur during operation but this is normal.

11. Do not immerse the unit in water.

12. Do not use this unit other than its intended use.

13. For household use only not intended for any business purposes..

14. Save this instruction manual for future reference.

DESCRIPTION OF PARTS

1. Outer Case 10. Door

2. Rack Support 11. Door Handle

3. Stainless Steel Rack 12. Tempered Glass

4. Power Light Indicator 13. Oil Drip Tray

5. Thermostat Control 14. Tray Holder

6. Heat Selector Switch 15. Foot

7. Timer Switch 16. Convection/Rotisserie Switch

8. Plug 17. Skewer Holder

9. Heater 18. Skewer

-1-

HOW TO USE

For the rst use, preheat the unit for at least 3-5 minutes.

1. Place the unit on a at surface.

2. The Timer should be at OFF position before plugging the unit to the in

convenience outlet.

3. Prepare the food.

4. Set the Thermostat Control to desired temperature.

5. Set the Heat Selector Switch (up, down or all).

6. For baking, use edible oil or butter to keep the food from sticking to the pan.

Switch ON the Convection Control Switch.

7. Preheat the unit as required of the cooking recipe.

8. Place the food on the grill and close the door. Be careful when putting food, the

unit is hot.

9. A beep sound will be heard and the unit will stop cooking once the set time is

nished.

10. To interrupt the cooking process, turn the Timer to OFF position then open the

door.

11. Unplug the unit after use.

COOKING GUIDE

ICON

TEMP./TIME

muins

150ºC/35 min.

bread

170ºC/50 min.

grill

177ºC/30 min.

cake

220ºC/35 min.

broil

200ºC/40 min.

sh

250ºC/20 min.

chicken

200ºC/35 min

NOTE: Cooking time may vary on type and the amount of food to be cooked.

-2-
