Side 1/7

IMPORTANT SAFEGUARDS

This manual contains important safety instruction that should be followed during the

installation and maintenance of the UPS and its batteries. Please read this manual

thoroughly before attempting to install or operate in this UPS.

1. Read all instructions carefully.

2. This equipment is available for 220Va.c-240Va.c. supply voltage and loads.

3. This UPS is designed for normal use only. The manufacturer neither recommends

nor knowingly sells this product for use in critical life support application.

4. Connect only to main supply socket outlet with an earth connector. A means of

disconnection of the main supply should be within 2 meters of the UPS.

5. WARNING: Output sockets of the UPS are electrically live if the UPS is switched ON,

even if the UPS is not plugged in to the main supply. The ON/OFF button of the UPS

does not electrically isolate the internal parts. To isolate the UPS, switch OFF the

UPS rst, and then unplug it from the main supply.

 To reduce the risk of electric shock, do not remove the cover, as it has no user-

serviceable parts inside. Some components are live, even when the AC power is

disconnected. Bring the unit to Imarex Authorized Service Center to obtain

evaluation and repair.

SPECIFICATION

Model

UPS- 850G

Rated Power

850Va.c

Backup Power

450W

Input

90V-140V/165V-275V/175V-295V

AVR Range

100V 265V-124V/190V-246V-195V-

Output

120±10%/230±10%/240±10%

Frequency

50Hz/60Hz

Battery (double)

Type

Sealed, maintenance-free lead acid

Capacity

One 12V/9Ah

Two 12V/7Ah

Back-up time (half Load)

Over 12 minutes

Typical Recharge Time

8 hours

LCD indicators

Status

Normal, Fault, Battery, Over Load, Output

Voltage, Battery Level

Audible Alarm

Battery Mode

Beeping sound every four seconds, every

second if approaches nal discharge

Fault (overload)

Continuous beeping sound

Operating

Environment

Temperature

-5°C-40°C

Humidity

10-90% RH, non-condensing

Audible Noise

< 45dBA

Transfer time

< 10 ms

Net Weight

6.8 Kg

10.6 Kg

Dimension (WxDxH)

300x115x220 mm

335x140x230 mm
