Pivot Arm 20˝ with Locking Lever
INSTRUCTIONS
One-Year Limited Warranty
This IMPACT product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer use
for a period of one (1) year from the original purchase date or thirty (30)
days after replacement, whichever occurs later. The warranty provider’s
responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at the provider’s discretion, of any product that fails
during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by
the warranty provider. If the product has been discontinued, the warranty
provider reserves the right to replace it with a model of equivalent quality
and function.
This warranty does not cover damage or defect caused by misuse, neglect,
accident, alteration, abuse, improper installation or maintenance. EXCEPT
AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY
EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING
BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you
with specic legal rights, and you may also have additional rights that vary
from state to state.
To obtain warranty coverage, contact the Impact Customer Service
Department to obtain a return merchandise authorization (“RMA”) number,
and return the defective product to Impact along with the RMA number and
proof of purchase. Shipment of the defective product is at the purchaser’s
own risk and expense.
For more information or to arrange service,
visit www.impactstudiolighting.com
or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
IMPACT is a registered trademark of the Gradus Group.
© 2015 Gradus Group LLC. All Rights Reserved.
GG1
Specifications
Construction: Aluminum alloy
Extended length: 20˝ (50.8 cm)
Folded length: 10˝ (25.4 cm)
Pivot arm diameter: .78˝ (20 mm)
Weight: 2 lb. (.91 kg)
Maximum load capacity: 8 lb. (3.6 kg)
Attachment: 5/8˝ (16 mm) stud with 1/4˝-20 female thread
5/8˝ (16 mm) stud with 3/8˝ female thread
Allen keys: 1× 6 mm
1× 5 mm
Precautions ⚠
• Please read and follow these instructions, and keep this manual in a safe place.
• Handle the unit with care.
• Do not force locking lever in opposite direction.
• Clean the unit with a soft, dry cloth.
• Keep this unit away from children.
• Make sure everything is secure before proceeding.
• Make sure the item is intact and that there are no missing parts.
• Do not exceed the maximum load capacity.
• All photos are for illustrative purposes only.
Thank you for choosing Impact.
The Impact Pivot Arm 20˝ with Locking Lever is a strong mounting
arm with an elbow pivot joint that securely attaches cameras,
lighting gear, or brackets while being attached to any baby receiver
adapters or super clamps. With its single stroke quick-action control
lever, the pivot arm can quickly and securely be locked into place.
Whether needing a unique angle or in a space where conventional
tripods cannot be used, this 360° pivot arm with ball and socket
positioning baby pins is a great addition to your grip kit.
The intra-locking lever easily freezes the position of the pivot arm,
after you’ve determined the ideal connections and placements. You
can use the Impact Pivot Arm 20˝ with locking lever in the studio or
on location to put your equipment just about anywhere.
There is further control of the pivot locking mechanism and rotatable
baby pins with the lever set screws for micro adjustment of the
tension throughout the unit. Either of the two female threaded baby
pins enable the connection to a variety of devices with 1/4˝-20 and
3/8ʺ threads while offering the ability to attach the arms to super
clamps or other mounting gear with baby 5/8˝ receivers.
Introduction
Overview
1
3
2
1
Intra-locking Lever
Internally locks pivot arms and baby pins
in position with quick-locking mechanism.
2
Rotary pivot joint
Rotates 360° for all-around positioning.
3
Lever set screws
Adjust tension of the intra-locking lever when
used with included Allen keys.
Warning!
Do not force lever in
opposite direction.
4
Threaded Baby Pins
Each baby pin is affixed to a ball and socket, allowing for flexible
movement and accurate positioning of the gear attached.
Connect many types of lighting and camera equipment
with 1/4˝-20 or 3/8˝ female threads.
Ideal for use with super clamps.
Flat-sided baby pins help to prevent the pivot
arms from rotating in any baby receiver.
4 3
4
