Indesit IWC 6105 Manual

Indesit Vaskemaskine IWC 6105

Læs gratis den danske manual til Indesit IWC 6105 (36 sider) i kategorien Vaskemaskine. Denne vejledning er vurderet som hjælpsom af 43 personer og har en gennemsnitlig bedømmelse på 3.9 stjerner ud af 22 anmeldelser. Har du et spørgsmål om Indesit IWC 6105, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/36

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine

and starting a wash cycle, 4-5

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 6

Table of wash cycles

Personalisation, 7

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 8

Detergent dispenser drawer

Bleach cycle

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

IWC 6105

Instructions for use

WASHING MACHINE

English,1

Español,13

Polski,25

Installation

 This instruction manual should be kept in a safe

place for future reference. If the washing machine is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so that

the new owner is able to familiarise himself/herself

with its operation and features.

 Read these instructions carefully: they contain vital

information relating to the safe installation and

operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has

been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4

protective screws (used

during transportation) and

the rubber washer with

the corresponding

spacer, located on the

rear part of the appliance

(see figure).

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need

them again if the washing machine needs to be

moved to another location.

 Packaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or anything else.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or loosening

the adjustable front feet

(see figure); the angle of

inclination, measured in

relation to the worktop,

must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive noise

and prevent it from shifting while it is operating. If it is

placed on carpet or a rug, adjust the feet in such a

way as to allow a sufficient ventilation space

underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to a

cold water tab using a ¾

gas threaded connection

(see figure).

Before performing the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the inlet hose

to the washing machine

by screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical details table (see

next page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand hoses.

 Use the ones supplied with the machine.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	IWC 6105
Bredde:	595 mm
Dybde:	535 mm
Højde:	850 mm
Vægt:	67000 g
Produktfarve:	Hvid
Kontroltype:	Buttons,Rotary
Indbygget skærm:	Ingen
Pakkedybde:	585 mm
Pakkebredde:	640 mm
Pakkehøjde:	890 mm
Energieffektivitetsklasse (gammel):	A+
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	6 kg
Maksimal centrifugeringshastighed:	1000 rpm
Antal vaskeprogrammer:	16
Støjniveau (centrifugering):	74 dB
Støjniveau (vask):	60 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy,Black,Hand/wool,Intensive/outdoor,Jeans/denim,Quick,Shoes,Sport,Delicate/silk
Energiforbrug ved vask:	1.03 kWh
Årligt energiforbrug vask:	193 kWh
Tromle volumen:	52 L
Dør farve:	Hvid
Spin-tørre klasse:	C
Cyklustid (maks.):	190 min.
Restfugtighed:	62 %
Vaskeklasse:	A
Årligt vandforbrug vask:	8643 L
Vandforbrug pr. cyklus:	- L
Forsinket start (maks.):	24 t
Indikator for resterende tid:	Ja
Overløbsbeskyttelse:	Ja
