Side 1/7

User Manual

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button and indicator light

3. TEMPERATURE button

4. DISPLAY

5. buttonCHILD LOCK

6. OPTION button

7. button DELAYED START

8. SPIN button

9. WASH CYCLE SELECTOR KNOB

10. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

2 3

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** The display will show the suggested spin speed as default value.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected. The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60

Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.

The most ecient programme in terms of energy and water consumption for washing

normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the

table.

For all testing institutes:

2) Long cotton cycle: set cycle 6 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, insert the partition

into slot .B

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the “max”

level indicated on the central pin.

! The detergent drawer is suitable only for Liquid

and Powder detergent. No Capsule Detergent allowed.

TheCapsule Detergent have to be placed into the drum before the load.

Make sure to use the correct Capsule Detergent dosage amount

recommended by Manufacturer.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever and pull the drawer outwards.C

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(***)

Energy con-

sumption kWh

Total water l

Laundry

temperature °C

Wash cycle

Temperature

Maxim spin

(r.p.m.)

Max.

load

(kg)

Duration

(h : m)

Wash

Fabric

softener

Powder

Liquid

Capsule

(4)

Setting Range

2 3

Cotton

40°C 1000 8 ** – 40°C

 

–

 

– – – –

Shirt

40°C 600 2 ** – 40°C

 

–

 

– – – –

3ARIEL PODS 30°C 30°C 1000 4.5 ** –



– –



– – – –

4 Wool 40°C

– 40°C 800 2 **

 

–



– – – – –

5 20°C

20°C

– 20°C

1400 8 1:50

 

–



– 55 0.138 78 22

6 Cotton (2) 40°C

– 60°C 1400 8 3:55

   



49 451.100 97

7 Synthetics (3) 40°C

– 60°C 1200 4 2:55

    

35 0.800 55 43

8 Mixed 40°C

– 40°C 1400 8 **

 

–

 

– – – –

9Eco 40-60 (1)

40 °C 40°C

1351 8 3:38

    

53 0.680 54 33

1351 4 2:48

    

53 0.430 53 28

1351 2 2:40

    

53 0.280 37.5 21

10 White 60°C

– 90°C 1400 8 2:35

    

55 1.790 89 55

Rapid 20min

20°C 800 1.5 ** – 20°C

 

–



– – – – –

11 Rapid 40°C

– 40°C 1200 4 **

 

–



– – – – –

11 Rapid 60°C

– 60°C 1000 8 **

    

– – – –

12 Rapid 45min Full Load 40°C

- 40°C 1200 8 **

 

–



– – – – –

13 Duvet 30°C

– 30°C 1000 3.5 **

 

–

 

– – – –

14 Delicates 30°C 30°C

– 30°C 600 (****) 1 **

 

–



– – – – –

Rinse + Spin – – 1400 8 ** –



– – – – – – –

Spin + Drain * – – 1400 8 ** – – – – – – – – –



Required dosage - Optional dosage - 4) Minimum 30°C recommended for usage of Capsule detergent.

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Cotton

Cycle designed to wash cotton garments. During the last phase of the

cycle garments will be treated with steam, that will relax the bres.

Shirt

Use the special wash cycle to wash shirts in dierent fabrics and colours

to guarantee they receive the best possible care. During the last phase of

the cycle garments will be treated with steam, that will relax the bres.

ARIEL PODS

A 30°C short cycle designed to wash a mixed load of cotton and

synthetics fabrics, recommended for the use of PODS detergent.

Wool - Wool Care

The wool wash cycle of this machine has been approved by

The Woolmark Company for the washing of machine washable

wool products provided that the products are washed

according to the instructions on the garment label and those

issued by the manufacturer of this washing machine. The

Woolmark symbol is a Certication mark in many countries.

(M2229)

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Specic for synthetic items. If the dirt is dicult to remove, the temperature

can be increased up to 60° and powder detergent can be used too.

Mixed

A 40°C cycle for washing cotton and synthetic garments together.

Suitable for lightly soiled underwear.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at 40 °C

or 60 °C, together in the same cycle. This is the standard cotton programme

and the most ecient in terms of water and energy consumption.

! As specied, this wash cycle only runs at 40 °C.

White

For heavily soiled whites and resistant colours.

Rapid 20min

Allows for varying the garment treatment duration from 20’ to 60’.

- 20’: this cycle refreshes your garments in just 20 minutes.

- 45’: a short cycle designed for washing mixed cotton-synthetic

garments.

- 60’: this cycle is designed to wash moderately soiled resistant cotton

garments at 60°C in an hour, with good washing performance. For

synthetic or mixed garments, the temperature should be lowered to 40°C.

Rapid 45min Full Load

Suitable for washing a full load of cotton clothes moderately soiled in 45

minutes.

Duvet

For washing clothing padded with goose down, such as double or single

duvets (weighing under 3.5 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it is

advisable to use liquid detergent to be poured into the detergent drawer.

Delicates 30°C

Suitable for washing very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed to spin and drain the water.

DISPLAY

The display is useful when programming the machine and provides a lot

of information.

C (see “Options”)

The duration of the available wash cycles and the remaining time of a

running cycle appear in section ; if the Delayed Start option has been A

set, the countdown to the start of the selected cycle will appear.

Pressing the corresponding button allows for viewing the maximum spin

speed and temperature values attained by the machine during the set

wash cycle, or the values selected most recently, if these are compatible

with the set wash cycle.

The hourglass ashes while the machine processes the data on the basis

of the selected cycle. After a maximum of 10 minutes, the icon remains

steady lit and the nal time remaining is displayed. The “hourglass” icon

will then switch o approximately 1 minute after the nal time remaining

has been displayed.

The “washing phases” relative to the selected cycle and the “washing

phase” of the running cycle appear in section :B

Wash

Rinse

Spin

Drain

When lit, the symbol indicates that the set “Delayed Start” value has

appeared on the display.

There are three levels in section relative to the washing options.C

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

Rapid programming

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

STARTING CYCLE

Press the PUSH & GO button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

Traditional programming

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

- Use the WASH CYCLE selector knob to select the desired wash cycle: it

will be associated with a specic temperature and spin speed that can be

modied. The duration of the cycle will appear on the display.

- Modify the temperature and/or spin speed: the machine automatically

displays the maximum temperature and spin speed values set for the

selected cycle, or the most recently-used settings if they are compatible

with the selected cycle. Pressing the button gradually reduces the

temperature down to the cold wash “OFF” setting. Pressing the button

gradually reduces the spin speed until it is completely excluded (“OFF”

setting). Pressing these buttons again restores the maximum values.

- Select the desired options.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened. Press the START/PAUSE button again to continue the cycle.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	BWE 81496X SV UK
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	605 mm
Højde:	850 mm
Vægt:	68300 g
Produktfarve:	Sølv
Kontroltype:	Buttons, Rotary
Motortype:	Børstefri
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1.2 m
Pakkevægt:	69800 g
Pakkedybde:	655 mm
Pakkebredde:	645 mm
Pakkehøjde:	890 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.5 W
Timer:	Ja
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Inverter-teknologi:	Ja
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	16
Støjniveau (centrifugering):	76 dB
Forsinket start-timer:	Ingen
Skyl hold:	Ingen
Børnesikring:	Ingen
Energiforbrug ved vask:	0.47 kWh
Understøttede scanningstilstande:	1067 mm
Tromlemateriale:	Rustfrit stål
Dør farve:	Sølv
Balance system:	Ja
Spin-tørre klasse:	B
Indikator for LED-programfase:	Ingen
Vandforbrug pr. cyklus:	48 L
Halv belastning:	Ingen
Selvrensende:	Ingen
Vandpåfyldning:	Kold
Rense plus funktion:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	A
Energiforbrug pr. 100 cyklusser:	47 kWh
Doseringsassistent:	Ingen
Strømforbrug (fortsat-tændt):	0 W
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Oprindelsesland:	Polen
Anti-krølle funktion:	Ja
Tromle indvendigt lys:	Ingen
Tilføj tøj (pause) -funktion:	Ingen
Bruttovægt:	69800 g
Strømstiktype:	Type G
Minimum centrifugeringshastighed:	600 rpm
Nem strygning funktion:	Ja
Stabelbar:	Ja
Sensor programvalg:	Ingen
Dybde med lukket låge:	618 mm
Pletfjerner indstilling:	Ingen
Vand Plus:	Ingen
Indesit-teknologier (tøjpleje):	8 Fast Cycles, Auto Clean, Delicates, Easy Iron, Energy Saver, Inverter motor, Push&Go, Rapid 30, Turn&Go, Water Balance Plus, Wool Care
