Side 1/7
GB
CONTROL PANEL
1. ON/OFF button
2. START/PAUSE button and indicator light
3. WASH CYCLE PHASE indicator lights
4. DOOR LOCKED indicator light
5. OPTION buttons and indicator lights
6. CHILD LOCK button and indicator light
8. SPIN button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
11. PUSH & GO button
WASH CYCLE TABLE
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
1
10
2 3
6
9
11
4
8
7
5
User Manual
Maximum load 8 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(**)
Energy con-
sumption kWh
Total water l
Laundry
temperature °C
Wash cycle
Temperature
Maxim spin
(r.p.m.)
Max.
load
(kg)
Duration
(h : m)
Wash
Fabric
softener
Powder
Liquid
Capsule
(4)
Setting Range
2 3
1
Cotton
40°C 1000 8 1:30 – 40°C
–
– – – –
2
Shirt
40°C 600 2 1:35 – 40°C
–
– – – –
3ARIEL PODS 30°C 30°C 1000 4.5 0:59 –
– –
– – – –
4 Wool 40°C
– 40°C 800 2 1:10
–
– – – – –
5 20°C
20°C
– 20°C
1400 8 1:50
–
– 55 0.138 78 22
6 Cotton (2) 40°C
– 60°C 1400 8 3:55
49 451.100 97
7 Synthetics (3) 40°C
– 60°C 1400 4 2:55
35 0.800 55 43
8 Mixed 40°C
– 40°C 1400 8 1:45
–
– – – –
9Eco 40-60 (1)
40 °C 40°C
1351 8 3:38
53 0.680 54 33
1351 4 2:48
53 0.430 53 28
1351 2 2:40
53 0.280 37.5 21
10 White 60°C
– 90°C 1400 8 2:35
55 1.790 89 55
11 Rapid 20min 20°C
– 20°C 800 1.5 0:20
–
– – – – –
12 Rapid 45min Full Load 40°C
- 40°C 1000 8 0:45
–
– – – – –
13 Duvet 30°C
– 30°C 1000 3.5 1:40
–
– – – –
14 Delicates 30°C 30°C
– 30°C 600 (***) 1 1:10
–
– – – – –
Rinse + Spin – – 1400 8 0:55 –
– – – – – – –
Spin + Drain * – – 1400 8 0:10 – – – – – – – – –
Required dosage - Optional dosage - 4) Minimum 30°C recommended for usage of Capsule detergent.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
For all testing institutes:
2) Long cotton cycle: set cycle 6 at a temperature of 40°C.
3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.
* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.
** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
*** The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60
-
Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.
The most ecient programme in terms of energy and water consumption for washing
normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in the
table.
DETERGENT DISPENSER DRAWER
Compartment 1:
Do not insert detergent in this compartment.
Compartment 2: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, insert the partition
into slot .B
Compartment 3: Additives (fabric softener, etc.)
The fabric softener must never exceed the “max”
level indicated on the central pin.
! The detergent drawer is suitable only for Liquid
and Powder detergent. No Capsule Detergent allowed.
TheCapsule Detergent have to be placed into the drum before the load.
Make sure to use the correct Capsule Detergent dosage amount
recommended by Manufacturer.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
! To remove the drawer, press lever and pull the drawer outwards.C
C
WASH CYCLES
Follow the instructions on the symbols of the garment’s wash
care label. The value indicated in the symbol is the maximum
recommended temperature for washing the garment.
Cotton
Cycle designed to wash cotton garments. During the last phase of the
cycle garments will be treated with steam, that will relax the bres.
Shirt
Use the special wash cycle to wash shirts in dierent fabrics and colours
to guarantee they receive the best possible care. During the last phase of
the cycle garments will be treated with steam, that will relax the bres.
ARIEL PODS
A 30°C short cycle designed to wash a mixed load of cotton and
synthetics fabrics, recommended for the use of PODS detergent.
The wool wash cycle of this machine has been approved by
The Woolmark Company for the washing of machine washable
wool products provided that the products are washed
according to the instructions on the garment label and those
issued by the manufacturer of this washing machine. The
Woolmark symbol is a Certication mark in many countries.
(M2229)
20°C
For washing lightly soiled cotton garments, at a temperature of 20 °C.
Cotton
Suitable for washing towels, underwear, table cloths, etc. made of
resistant linen and cotton that are moderately to heavily soiled.
Synthetics
Specic for synthetic items. If the dirt is dicult to remove, the temperature
can be increased up to 60° and powder detergent can be used too.
Mixed
A 40°C cycle for washing cotton and synthetic garments together.
Suitable for lightly soiled underwear.
Eco 40-60
For washing normally soiled cotton garments declared to be washable at
40 °C or 60 °C, together in the same cycle. This is the standard cotton
programme and the most ecient in terms of water and energy
consumption.
! As specied, this wash cycle only runs at 40 °C.
White
For heavily soiled whites and resistant colours.
Rapid 20min
This cycle refreshes your garments in just 20 minutes.
Rapid 45min Full Load
Suitable for washing a full load of cotton clothes moderately soiled in 45
minutes.
Duvet
For washing clothing padded with goose down, such as double or single
duvets (weighing under 3.5 kg), cushions or down jackets. Duvets should
be loaded into the drum with their edges folded inwards and no more
than ¾ of the total drum volume should be used up. For best results, it is
advisable to use liquid detergent to be poured into the detergent drawer.
Delicates 30°C
Suitable for washing very delicate garments. It is advisable to turn the
garments inside out before washing them. For best results, use liquid
detergent on delicate garments.
Rinse + Spin
Designed for rinsing and spinning.
Spin + Drain
Designed to spin and drain the water.
WASH CYCLE PHASE INDICATOR LIGHTS
Once the desired wash cycle has been selected and has begun, the
indicator lights switch on one-by-one to indicate which phase of the cycle
is currently in progress.
Wash
Rinse
Spin
Drain
End of Wash Cycle
DOOR LOCKED INDICATOR
When lit, the symbol indicates that the door is locked. To prevent any
damage, wait until the symbol turns o before opening the door.
To open the door while a cycle is in progress, press the START/PAUSE
button; if the indicator light is o, the door can be opened.
FIRSTTIME USE
Once the appliance has been installed, and before it is used for the rst
time, run a wash cycle with detergent and no laundry, by setting the
“Auto-Clean” cycle.
DAILY USE
Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.
Rapid programming
- Turn the washing machine on by pressing the ON/OFF button. All the
indicator lights will light up for a few seconds, then only the lights
corresponding to the settings for the selected wash cycle will remain lit;
the START/PAUSE indicator light will also ash.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the cycle table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments as described in “DETERGENT DISPENSER DRAWER
section”.
- Close the door.
STARTING CYCLE
Press the “PUSH & GO” button.
The machine will lock the door ( symbol on) and the drum will start to
rotate; the door will be unlocked ( symbol OFF) and then locked again (
symbol on) as preparation phase of each washing cycle. The “Clicking” noise
is part of the door locking mechanism. Water will enter the drum and start
the washing phase once the door is locked.
Traditional programming
- Turn the washing machine on by pressing the ON/OFF button. All the
indicator lights will light up for a few seconds, then only the lights
corresponding to the settings for the selected wash cycle will remain lit;
the START/PAUSE indicator light will also ash.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the Wash Cycle Table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments as described in “DETERGENT DISPENSER
DRAWER” section.
- Close the door.
- Set the WASH CYCLE knob to the desired cycle.
- Modify the temperature and/or spin: pressing the button allows for
gradually reducing the temperature down to the cold wash level (20°C).
The spin speed may be progressively reduced by pressing the button,
until it is completely excluded (the setting). If these buttons are
pressed again, the maximum values are restored.
- Select the desired options.
STARTING CYCLE
Press the START/PAUSE button.
The machine will lock the door ( symbol on) and the drum will start to
rotate; the door will be unlocked ( symbol OFF) and then locked again (
symbol on) as preparation phase of each washing cycle. The “Clicking”
noise is part of the door locking mechanism. Water will enter the drum
and start the washing phase once the door is locked.
PAUSING A CYCLE
To pause the wash cycle, press the START/PAUSE button again; the
indicator light will ash amber. If the indicator light is not lit, the door
may be opened. To start the wash cycle from the point at which it was
interrupted, press the START/PAUSE button again.
OPENING THE DOOR, IF NECESSARY
Once a cycle starts, the indicator light turns on to signal that the door
cannot be opened. While a wash cycle is running, the door remains
locked. To open the door while a cycle is under way, for example, to add
or remove garments, press the START/PAUSE button to pause the
cycle; the indicator light will ash amber. If the indicator light is not lit,
the door may be opened. Press the START/PAUSE button again to
continue the cycle.
CHANGING A RUNNING WASH CYCLE
To change a wash cycle while it is in progress, pause the washing machine
using the START/PAUSE button (the relative indicator light will ash
amber), then select the desired cycle and press the START/PAUSE
button again.
! To cancel a cycle that has already begun, press and hold the ON/OFF
button. The cycle will be stopped and the machine will switch o.
END OF THE CYCLE
Once the cycle terminates the indicator light will light up; when the
indicator light switches o, the door may be opened. Open the door and
switch o the machine. If you do not press ON/OFF button, the
washing machine will switch o automatically after about a 10 minutes.
Close the water tap, open the door and unload the washing machine.
Leave the door ajar to allow the drum to dry.
OPTIONS
- If the selected option is not compatible with the set wash cycle, the
indicator light will ash and the option will not be activated.
- If the selected option is not compatible with another previously
selected option, the indicator light will ash accompanied by a buzzer
(3 beeps), and only the latter option will be activated; the indicator
light corresponding to the activated option will turn on.
Stain removal
This option allows for selecting the type of dirt so as to optimally adjust the
cycle for removing the stains. The following types of dirt can be selected:
- Food: for stains caused by foodstus and beverages, for example.
- : for grease and ink stains, for example.Work
- : for mud and grass stains, for example.Outdoor
! The wash cycle duration varies according to the type of selected dirt.

Produkt Specifikationer

Mærke: Indesit
Kategori: Vaskemaskine
Model: BWA 81496X WV UK

Har du brug for hjælp?

Hvis du har brug for hjælp til Indesit BWA 81496X WV UK stil et spørgsmål nedenfor, og andre brugere vil svare dig


Vaskemaskine Indesit Manualer

Indesit

Indesit BWA 81496X WV UK Manual

21 August 2025
Indesit

Indesit BWE 71496X WV UK Manual

21 August 2025
Indesit

Indesit BWE 81496X SV UK Manual

21 August 2025
Indesit

Indesit BWE 111496X WV UK Manual

21 August 2025
Indesit

Indesit MyTime IMA 762 Manual

19 August 2025
Indesit

Indesit IM 864 MY TIME EE Manual

18 August 2025
Indesit

Indesit IM 964 MY TIME UK Manual

17 August 2025
Indesit

Indesit WN 1066 XWO Manual

5 August 2025
Indesit

Indesit BDE 86436 WSV EE Manual

4 August 2025
Indesit

Indesit MTWSA 61053 W EE Manual

4 August 2025

Vaskemaskine Manualer

Nyeste Vaskemaskine Manualer

Hisense

Hisense WF3S1243BB3 Manual

22 August 2025
Saivod

Saivod LST 1261 Manual

22 August 2025
Saivod

Saivod LST 1055 Manual

22 August 2025
Electrolux

Electrolux EWF1080 Manual

22 August 2025
Candy

Candy CS 1412TME/S Manual

22 August 2025
Candy

Candy TCA264TM5-S Manual

21 August 2025
Electrolux

Electrolux EFI743SX4Q Manual

21 August 2025
Haier

Haier HW100-B14959NEU1 Manual

21 August 2025
Hisense

Hisense WF3S1043BB3 Manual

21 August 2025
Hisense

Hisense WF3S1043BW Manual

21 August 2025
