Quick guide

PRODUCT DESCRIPTION

CONTROL PANEL

1. Control panel

2. Fan

3. Lamp

4. Shelf guides

(the level is indicated on the wall

of the cooking compartment)

5. Door

6. Upper heating element/grill

7. Identification plate

(do not remove)

8. Bottom heating element

(non-visible)

9. Embossing for drinking water

1. SELECTION KNOB

For switching the oven on by

selecting a function.

Turn to the position to switch the

oven off.

2. LIGHT

With the oven switched on, press

to turn the oven compartment

lamp on or off.

3. SETTING THE TIME

For accessing the cooking time

settings, delayed start and timer.

For displaying the time when the

oven is off.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time

settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions. For Turn&Go function

use , for Turn&Go Steam

function use .

Please note: All knobs are push-

activated knobs. Push down on the

centre of the knob to release it from its

seating.

THANK YOU FOR BUYING AN INDESIT PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

1 632 4 5

TURN&GO STEAM

The Turn&Go Steam function allows to obtain

excellent performances thanks to the presence

of steam in the cooking cycle. This function

automatically manages the ideal temperature for

cooking a wide range of recipes; the cooking times

of the main dishes are shown in the relative cooking

table. Always activate the steam function when the

oven is cold, and after pouring 200 ml of drinking

water into the bottom of the cavity.

CONVENTIONAL

For cooking any kind of dish on one shelf only.

MULTILEVEL

For cooking different foods that require the

same cooking temperature on several shelves

(maximum three) at the same time. This function

can be used to cook different foods without odours

being transferred from one food to another.

XL COOKING

For cooking large joints of meat (above 2.5

kg). We recommend turning the meat over during

cooking to ensure that both sides brown evenly. We

also recommend basting the joint every so often to

prevent it from drying out excessively.

PIZZA

For baking different types and sizes of pizza

and bread. It is a good idea to swap the position of

the baking trays halfway through cooking.

GRILL

For grilling steaks, kebabs and sausages,

cooking vegetables au gratin or toasting bread.

When grilling meat, we recommend using a Baking

tray to collect the cooking juices: position the pan on

any of the levels below the wire shelf and add 200 ml

of drinking water.

ACCESSORIES

Download the Use and Care Guide from

docs . indesit . eu for more information

WWW

WIRE SHELF DRIP TRAY BAKING TRAY

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

USING THE ACCESSORIES

• Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the raised

rear side (pointing upwards) down rst. Then slide it

horizontally along the shelf guide as far as possible. The

other accessories, such as the baking tray, are inserted

horizontally by sliding them along the shelf guides.

• The shelf guides can be removed to facilitate the

oven cleaning: pull it to remove from its seats.

GRATIN

For roasting large joints of meat (legs, roast

beef, chicken). We recommend using a Baking tray to

collect the cooking juices: position the pan on any

of the levels below the wire shelf and add 200 ml of

drinking water.

FREASY COOK

All the heating elements and the fan come on,

guaranteeing the distribution of heat consistently

and uniformly throughout the oven. Pre-heating is

not necessary for this cooking mode. This mode is

especially recommended for cookingpre-packed

food quickly (frozen or pre-cooked). The best results

are obtained if you use one cooking rack only.

ECO FORCED AIR

For cooking roasts and stuffed roasting joints

on a single shelf. Food is prevented from drying out

excessively by gentle, intermittent air circulation.

When this ECO function is in use, the light will remain

switched off during cooking but can be switched on

again by pressing .

HYDROCLEANING

The action of the steam released during this

special low-temperature cleaning cycle allows dirt

and food residues to be removed with ease. Pour

200ml of drinking water on the bottom of the oven

and use the function for 35’ at 90°C. Activate the

function when the oven is cold and let it cool down

for 15’ once the cycle ends.

TURN&GO

This function automatically selects an ideal

temperature and time for baking a wide range of

recipes including meat, fish, pasta, sweets and

vegetables. Activate the function when the oven is

cold.

FUNCTIONS Download the Use and Care Guide from

docs . indesit . eu for more information

WWW

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Ovn
Model:	KFWS 3844 H IX UK
Afrimningsfunktion:	Ingen
Vekselstrømsindgangsspænding:	220 - 240 V
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Vægt:	26900 g
Produktfarve:	Grå
Kontroltype:	Dreje
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1 m
Pakkevægt:	28200 g
Pakkedybde:	650 mm
Pakkebredde:	640 mm
Pakkehøjde:	670 mm
Pakketype:	Kasse
Indvendig belysning:	Ja
Integreret ur:	Ja
Tilsluttet belastning:	2900 W
Genopvarmningsfunktion:	Ingen
Energieffektivitetsskala:	A+++ til G
Selvrensende:	Ja
Kontrolposition:	Front
Nem at rengøre:	Ja
Energieffektivitetsklasse:	A+
Antal gitre:	2
Ovn - størrelse:	Medium
Samlet indvendig ovn kapacitet:	71 L
Antal ovne:	1
Holde varm funktion:	Ingen
Oprindelsesland:	Polen
Antal hylder:	2 hylder
Aftagelig dørglas:	Ja
Afkalkningsfunktion:	Ingen
