PACKAGE CONTENTS

• Microphone

• Desk stand

• USB cable

• Quick Setup Guide

SYSTEM REQUIREMENTS

Windows 10®, Windows 8®, Windows 7®, or Mac OS X 10.4.11 or later

Before using your new product, please read these instructions to prevent any damage.

QUICK SETUP GUIDE

USB Recording

Microphone

NS-CBM19

FEATURES

Front

Side

USING YOUR MICROPHONE

Position yourself 1.5 ft. (0.46 m) in front of the microphone with the Insignia

logo and mute button facing you.

Your microphone’s cardioid recording pattern captures audio primarily from the

front of the microphone. This is ideal for recording podcasts, livestreams,

voiceovers, or a single instrument or voice.

Adjusting your microphone’s angle

Loosen the adjustment knobs to move the microphone to the position you

want, then retighten the knobs to secure.

Attaching to a microphone stand

1 Unscrew the desk stand’s adjustment knob to remove the microphone.

2 Screw the microphone onto a stand that has a 1/4" threaded adapter.

Microphone

Micro USB port:

Connect your USB cable (included)

from this port to your computer.

Microphone:

Captures audio.

Mute button/Status LED:

Lights blue when connected to power.

Lights red when muted.

Tilt adjustment knobs:

Adjust your microphone’s tilt angle.

Desk stand:

Holds your microphone.

Desk stand adjustment knob

Attaches the microphone

to the stand.

Mounting hole

Adjustment knob

Desk stand

adjustment knob

Cardioid

recording pattern

1.5 ft. (0.46 m)

Mounting hole:

Remove the desktop stand to screw

onto any ¼" threaded stand.

V2 ENGLISH 19-0175

SETTING UP YOUR MICROPHONE

Connecting to your computer

Connect the USB cable (included) from your microphone to your computer.

For the best performance, do not connect it to a USB hub.

Windows:

1 Open the Control Panel.

2 In the upper-right corner, change “View by” to Small icons.

3 Click Sound, then click Recording.

4 Select Insignia NS-CBM19, then click Set Default. Make sure that there is

a green check mark next to Insignia NS-CBM19.

5 Click Congure.

6 Click Set up Microphone, then follow the on-screen instructions.

7 (Optional) To adjust the computer’s microphone volume, click Properties.

8 When nished, close the Control Panel.

Mac:

1 Open the Finder, then select Applications.

2 Open System Preferences, then click Sound.

3 Select the Input tab, then select Insignia NS-CBM19. Make sure that the

mute button isn’t selected.

4 When nished, close System Preferences.

SETTING THE VOLUME

Use your computer’s system settings or recording software to adjust the

microphone volume level.

TROUBLESHOOTING

Low or no audio recorded by the microphone

• Make sure that the USB cable is connected securely to your microphone and

computer and that it is not damaged.

• If your computer is not recognizing your microphone, switch to a dierent USB

port. For the best results, do not connect the microphone to a USB hub.

• Make sure that your microphone is not muted. The LED should be blue.

• Make sure that you’ve selected your Insignia microphone as the input device.

See “Setting up your microphone.”

• This cardioid microphone picks up audio from the front and minimizes noise

from the sides or back. Make sure that you record from the front of the

microphone.

• Increase the microphone’s volume or sensitivity with your computer’s system

settings or recording software.

• Move closer to the microphone.

The microphone’s audio is too loud

• Move away from the microphone.

• Reduce the microphone’s volume or sensitivity with your computer’s system

settings or recording software.

The microphone is picking up background noise

• This cardioid microphone picks up audio from the front and minimizes noise

from the sides and back. Adjust your microphone’s position so there is less

noise coming from the front of the microphone.

• Reduce the microphone’s volume or sensitivity with your computer’s system

settings or recording software.

Poor audio quality

• Make sure that the USB cable is connected securely to your microphone and

computer and that it is not damaged.

• Replace the USB cable.

• Make sure that the microphone is not too close to your mouth.

SPECIFICATIONS

• Frequency: 20 Hz – 20 KHz

• Sampling rate: 48 KHz / 24 bit

• Stand mount ready: Threaded for 1/4"

• Recording pattern: Cardioid (directional)

LEGAL NOTICES

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Changes or modications not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

Canada ICES-003 This Class B digital apparatus complies with Canadian ICES-003.

ONEYEAR LIMITED WARRANTY

For complete warranty, visit www.insigniaproducts.com.

CONTACT INSIGNIA

1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)

www.insigniaproducts.com

INSIGNIA is a trademark of Best Buy and its aliated companies

Distributed by Best Buy Purchasing, LLC

7601 Penn Ave South, Richeld, MN 55423 U.S.A.

Made in China

• Connection type: USB

• Cable Length: 4.9 ft. (1.5 m)

• Max SPL: 118 dB
