Contents
Safety information and specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
STEP 1 - Option 1 - Mounting to a drywall ceiling. . . . . . . . . . . . .6
STEP 1 - Option 2: Mounting to a concrete ceiling . . . . . . . . . . . .8
STEP 2 - Attaching the mount base to your projector . . . . . . . .10
STEP 3 - Mounting the projector . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Removing your projector from the mount . . . . . . . . . . . . . . . . . .13
Adjusting and maintaining your projector . . . . . . . . . . . . . . . . . .13
Maintaining your projector mount. . . . . . . . . . . . . . . . . . . . . . . . . .13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Safety information and specifications
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS
WARNINGS: To reduce the risk of product damage or personal injury, follow these
basic precautions when using your projector mount:
• Read all instructions before using the projector mount.
• Do not use this product for any purpose not explicitly specified by the
manufacturer. Improper installation may cause property damage or personal injury. If you
do not understand the directions, or have doubts about the safety of the installation,
contact the manufacturer or call a qualified contractor. The manufacturer is not liable for
damage or injury caused by incorrect mounting, assembly, or use.
• If you are unsure about any part of the installation process, contact a professional
contractor or installer for assistance. Improper installation can result in personal injury or
damage to the product or your equipment.
• The ceiling or mounting surface must be capable of supporting four times the combined
weight of the mount and the projector. If not, the structure must be reinforced.
• Relocate pipes, wires, or any other hazards away from the area where you wish to install
the mount before drilling.
• Safety gear and proper tools must be used for this installation. Failure to do so can result
in personal injury or damage to the product or your equipment.
• Follow all instructions and recommendations regarding adequate ventilation and suitable
locations for mounting your projector. Consult the owner‘s manual for your particular
display for more information.
• This mount is intended for use only with the maximum weight of 30 lbs. (13.6 kg). Use
with equipment that is heavier than the maximum weights indicated may result in
instability, causing possible personal injury or damage to the product or your equipment.
• This product contains small items that could be a choking hazard if swallowed. Keep these
items away from young children.
• Follow mounting instructions carefully.
