Side 1/12
8-Port
rackmount
PoE midsPan
usEr manual
Model 502931
INT-502931-UM-ML1-0710-01-0
English
DEutsch
Español
FRançais
polsKi
italiano
2 English
8-Port Rackmount PoE Midspan • User Manual English
Thank you for purchasing the INTELLINET NETWORK SOLUTIONS
™
8-port
Rackmount PoE Midspan, Model 502931. For a full list of specications, refer
to the datasheet available at www.intellinet-network.com.
CONNECTIONS & INDICATORS
Ports
The lower row of RJ45 ports — Data (In) — on the front panel delivers data
to the Midspan from existing network devices. The upper row of RJ45 ports
— Power + Data (Out) — delivers data while also powering added devices
(up to 15.4 Watts per port). Use standard Cat5 or better Ethernet cables for
connections to PoE-supported IP cameras, wireless access points, other
switches, etc. NOTE: Powered devices should also comply with IEEE 802.3af.
LEDs
If an LED doesn’t light to
indicate a link or activity,
check the corresponding
device for proper setup and
operation.
Power
On the rear panel, plug in the included power
cord and connect the switch to an AC outlet.
Toggle the Power switch to On and conrm that
the Power LED is lit.
RACK MOUNTING
Simply align the two brackets with the holes on each side panel and secure
them with the included screws. Use the remaining screws to mount the
device in a rack.
LED Status Operation
POWER On Power on
O Check the AC connection; power on
PD Link On Port is linked and providing 48 V to a
(1-8) powered device
O No link is established
OFF
ON
RJ45 10/100 Mbps ports
1 2 3 4 5 6 7 8
POWER
1 2 3 4 5 6 7 8
PD LINK
POWER + DATA (OUT)
DATA (IN)
