Libertyville, Illinois 60048

www.intermatic.com

Digital Landscape Timer

MODEL DT200LT

for use in Low Voltage Transformers up to 1200 W

SET

PROG

ON/OFF

SAFETY SECTION

WARNING

Risk of Fire or Electrical Shock

• Do Not use the timer to control devices that could have dangerous consequences due to inaccurate timing, such as sun lamps, saunas, heaters, crock pots, etc.

• Unplug the timer before replacing batteries.

• Do Not use to control receptacles.

• Installation should be in accordance with national and local electrical code requirements.

NOTICE

• Dispose of product per local regulations for disposal of used batteries.

WARNING

• Ingestion Warning: This product contains a button cell or coin battery.

• DEATH or serious injury can occur if ingested.

• A swallowed button cell or coin battery can cause in as little as .Internal Chemical Burns 2 hours

• KEEP OUT OF REACH CHILDREN new and used batteries of

• Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body.

• Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash

or incinerate.

• Even used batteries may cause severe injury or death.

• Replace only with LR44 (1.5 V) Batteries.

• Call a local poison control center for treatment information.

• Non-rechargeable batteries are not to be recharged.

• Do not force discharge, recharge, disassemble, heat above (manufacturer’s speciﬁed temperature rating) or incinerate. Doing so may result in injury due to venting, leakage or explosion resulting in

chemical burns.

• Ensure the batteries are installed correctly according to polarity (+ and -).”

• Do not mix old and new batteries, different brands or types of batteries, such as alkaline, carbon-zinc, or rechargeable batteries.

• Remove and immediately recycle or dispose of batteries from equipment not used for an extended period of time according to local regulations.

• Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep them away from children.

PRODUCT DESCRIPTION

The Intermatic DT200LT Digital Landscape Timer is a simple-to-use landscape timer to be used with low voltage transformers

up to 1200 W in order to control landscape lighting. This timer supports pre-programmed dawn/dusk times or one set of

custom ON/OFF times.

Speciﬁcations

Output

• 15 A Resistive, 120 VAC

• 12 A Inductive, 120 VAC

• 1000 W, 120 VAC

• 1/2 HP, 120 VAC

Input

• 120 VAC, 60 Hz, 2.5W max

Operating Temperature

• -40°F to 122°F (-40°C to 50°C), for 1200 W, 120 VAC

Batteries

• Two LR44 batteries that keep time and settings for up

to three months without power

TIMER OVERVIEW

Item Description Item Description

A Battery Holder H Selector Knob

B Low Battery Indicator I Reset Button

C Time of Day Display J Day of the Week Display

D SET Button K Mode Display

E PROG Button L ON/OFF Indicator Light

F ON/OFF Button M Battery Pull Tab

G Grounded Outlet (2)

DAYSAV AUTO CLOCK

YEARDATE

MONTH

SKIP

EVENT

MO TU WE TH FR SA SU AM PM

OFF LOC DUSK DAWN

SET PROG ON/OFF

Digital Landscape Timer

INITIAL SETUP

Overview

Upon ﬁrst use, you must enable the battery and then set the Time, Date, and Location.

Enabling the Battery

1. Remove the pull tab (M) from the battery holder, if

present. See FIG. 1.

2. When the display shows 12:00 AM, the timer is

ready for initial set up. See FIG. 2. If 12:00 AM does

not display, perform a Factory Reset or see the

Troubleshooting section.

Note: The timer may be set while unplugged. The display

turns OFF after 1 minute of inactivity to save battery.

Press any button to turn the display back ON.

Setting the Time, Date, and Location

Upon initial use, you can easily program these timer settings

in succession by completing the steps in this section.

1. Turn the selector knob (H) to select the correct hour of

the day. Press (D). Repeat to select the minute of SET

the day. See FIG. 2.

2. Turn the selector knob (H) to select the correct YEAR.

Press SET (D). See FIG. 3.

3. Turn the selector knob (H) to select the correct MONTH.

Press SET (D). See FIG. 3.

4. Turn the selector knob (H) to select the correct DATE.

Press SET (D). See FIG. 3.

5. Turn the selector knob (H) to select the correct Daylight

Savings Time setting. The options are OFF, US/CAN,

and Mex.

a. If in Hawaii or Arizona, select OFF. Press (D).SET

b. If you live in a part of Mexico that observes

US/Canada Daylight Savings Time, select US/CAN.

Press (D).SET

6. Turn the selector knob (H) to select the state you are in.

Press SET (D). See FIG. 4.

7. Turn the selector knob (H) to select the section of the

state you are in. Press (D). See FIG. 4.SET

8. Turn the selector knob (H) to select the time zone you

are in. Press (D). See FIG. 5.SET

9. Turn the selector knob (H) to adjust the DAWN offset

time (+/- 15, 30, 45 or 60 minute increments). Press

SET (D). Offset is the amount of minutes you want the

lights to come on before (-) or after (+) DAWN or DUSK.

Repeat for the DUSK offset time. See FIG. 6.

10. Press (D) to ﬁnish setting up the timer.SET

FIG 1. Removing the Pull Tab

CLOCK

SET PROG ON/OFF

FIG 2. Setting the Time

YEARDATE

MONTH

SET PROG ON/OFF

FIG 3. Setting the Date

FIG 4. Setting the State

LOC

SET PROG ON/OFF

FIG 5. Setting the Time Zone

SET PROG ON/OFF

FIG 6. Setting the DAWN/DUSK Offset Time

DAWN

SET PROG ON/OFF
