Side 1/2
This innovative LNB was specifically designed for installations that make use of several LNBs on a satellite dish antenna. It’s novel
slim feed technology incorporating advanced dielectric materials and optimum front end design ensure maximum energy transfer
from the dish to the LNB circuits also when the LNB position is off the focal point. Further more, it’s long neck allows placing the
LNBs closely next to each other and gain access to satellites typically too close in their orbital position to be received with standard
neck LNBs on a certain satellite dish antenna. This LNB enables the reception of signal from one satellite and its distribution to up-to
4 single tuner Set-top boxes (or 2 in the case of a twin-tuner STB).
Main Features:
• Novel slim feed technology
• Low Phase Noise, DVB-S2 (HDTV) compliant
• Low Noise Figure
• Low power consumption
• High Cross-Pole performance
• High Frequency stability
Click object to rotate
For purpose of brevity, some product descriptions in this sheet remain at platform level and may not be referred to as detailed
datasheets of the products. Inverto Digital Labs reserves the right to amend, omit or add products, product-lines, and / or features
without notice.
For further details contact: sales@inverto.tv
FTA Communication Technologies S.a r.l Tel. +352 264 367 1 Fax. +352 264 313 68
ww o.tvw.inver t
Low Band Input Frequency Range
Low Band Output Frequency Range
LO Frequency
High Band Input Frequency Range
High Band Output Frequency Range
LO Frequency
Noise Figure
LO Initial Accuracy
LO Temperature Drift
LO Phase Noise @ 10K Hz
Conversion Gain
Gain Ripple
Gain Variation
Image Rejection
1 dB Compression Point (O/P)
Cross talk
Control Signals Ca [ V ]
Control Signals Cb [ H ]
Control Signals Cc [Band switching]
Output VSWR
Radiated Interference
DC Power
Working Temperature
Output Impedance (connect to STB)
Output connector
Weight
10.7~11.7 GHz
950~1950 MHz
9.75 GHz
11.7~12.75 GHz
1100~2150 MHz
10.6 GHz
0.2dB typ. (0.7dB max.)
+/- 1.0 MHz max.
+/- 3.0 MHz max.
-90 dBc/Hz max.
60 dB min.
+/- 0.75 dB/27MHz
+/- 4 dB
40 dB min.
0.0 dBm min.
23dB min.
11.0~14.0 V
16.0~20.0 V
22KHz +/- 4KHz 0.4V – 0.8V pp
2.0 : 1
-60 dBm max.
200mA max. @ 11 – 20V
-30~+60 °C
75Ω
F-type (female)
344 g
Technical data
V010714
