Iogear GUD300 Manual

Iogear Computertilbehør GUD300

Læs gratis den danske manual til Iogear GUD300 (8 sider) i kategorien Computertilbehør. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om Iogear GUD300, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/8
USB 3.0 Universal Docking Station
with Power Adapter
Quick Start Guide
GUD300
PART NO. Q11247-b
www.iogear.com
Windows:
Current Windows 10 builds and Windows 11 builds are plug and play,
no software needed to install.
However, older builds of Windows 10 and legacy Windows versions
may need to install Silicon Motion drivers.
For more information, please visit: www.iogear.com
macOS:
Please download the latest version of Silicon Motion drivers at:
https://www.iogear.com/support/dm/driver/GUD300
To install on a Mac OS product please follow these steps:
STEP 1
Locate the Silicon Motion .dmg driver in your
computer and double click the file.
STEP 2
A window will open up. Follow the instructions by
dragging the macOS InstantView application into
the Applications folder.
STEP 3
Open up your Applications Folder, locate the “macOS InstantView”
application and double click it.
STEP 4
A window will open up and display a message saying the driver would
like to “record this computer’s screen.”
Click on “Open System Preferences”
STEP 5
A window will open up and display your “Security and Privacy” page.
Click on the Lock icon on the bottom left to unlock the “Privacy”
section. Click on the unchecked box that shows the “macOS
Instantview” selection.
STEP 6
A window will open up. Click on the “Quit and Reopen” option.
STEP 7
If successful, the InstantView icon will appear in your top right corner.
Clicking on this icon will open up the InstantView window. If your
Monitor(s) are not connected, a small “Connect” button will appear in
the middle of the window. Please ensure your monitor(s) are
connected, powered on, and set to the right port. If the Monitors are
already configured properly, the InstantView application will instead
show a “Disconnect” button in the middle of the application.
Connect your monitor
Successful connection
Package Contents
1 x GUD300 Universal Docking Station
1 x SuperSpeed USB 3.0 Cable
1 x HDMI to DVI Adapter
1 x DVI to VGA Adapter
Overview
1. DC12V
2. USB 3.0 IN
3. USB 3.0 Ports
4. USB 2.0 Ports
5. HDMI Out
6. DVI Out
7. Gigabit LAN
1
8. Microphone Input
9. Headphone Output
1 x AC Adapter
1 x Quick Start Guide
1 x Warranty Card
System Requirements
Hardware
• Computer or tablet* with USB 3.0 or USB 2.0 port**
*
Select Windows 8 tablets. See IOGEAR.com for more details.
**
USB 3.0 speeds are not available when connected to a USB 2.0 port
Operation System
• Windows
®
10 and above
• macOS
®
High Sierra 10.13 or later
1
Windows:
Current Windows 10 builds and Windows 11 builds are plug and play,
no software needed to install.
However, older builds of Windows 10 and legacy Windows versions
may need to install Silicon Motion drivers.
For more information, please visit: www.iogear.com
macOS:
Please download the latest version of Silicon Motion drivers at:
https://www.iogear.com/support/dm/driver/GUD300
To install on a Mac OS product please follow these steps:
STEP 1
Locate the Silicon Motion .dmg driver in your
computer and double click the file.
STEP 2
A window will open up. Follow the instructions by
dragging the macOS InstantView application into
the Applications folder.
STEP 3
Open up your Applications Folder, locate the “macOS InstantView”
application and double click it.
STEP 4
A window will open up and display a message saying the driver would
like to “record this computer’s screen.”
Click on “Open System Preferences”
STEP 5
A window will open up and display your “Security and Privacy” page.
Click on the Lock icon on the bottom left to unlock the “Privacy”
section. Click on the unchecked box that shows the “macOS
Instantview” selection.
STEP 6
A window will open up. Click on the “Quit and Reopen” option.
STEP 7
If successful, the InstantView icon will appear in your top right corner.
Clicking on this icon will open up the InstantView window. If your
Monitor(s) are not connected, a small “Connect” button will appear in
the middle of the window. Please ensure your monitor(s) are
connected, powered on, and set to the right port. If the Monitors are
already configured properly, the InstantView application will instead
show a “Disconnect” button in the middle of the application.
Connect your monitor
Successful connection
5
6
7
8
9
2
3
4
The Adopted Trademarks HDMI, HDMI High Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

Produkt Specifikationer

Mærke: Iogear
Kategori: Computertilbehør
Model: GUD300
Bredde: 222 mm
Dybde: 87 mm
Højde: 35 mm
Vægt: 280 g
Produktfarve: Sort
Pakkevægt: 700 g
Pakkedybde: 89 mm
Pakkebredde: 235 mm
Pakkehøjde: 137 mm
Antal HDMI-porte: 1
Ethernet LAN-porte (RJ-45): 1
Antal USB 2.0-porte: 4
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: 3
Udgange til hovedtelefoner: 1
Ethernet LAN: Ja
Ethernet LAN-datahastigheder: 10,100,1000 Mbit/s
Hurtig start guide: Ja
Kabler inkluderet: USB
Fjernbetjening inkluderet: Ingen
Forbindelsesteknologi: Docking
DC-in-stik: Ja
AC-adapter inkluderet: Ja
Indbygget kortlæser: Ingen
Indbygget HDD: Ingen
Mikrofonindgang: Ja
Tilslutning af hovedtelefoner: 3,5 mm
USB-stik type: USB Type-A, USB Type-B
Mærke kompatibilitet: Alle mærker
Kobber ethernet kabelteknologi: 1000BASE-T, 100BASE-T, 10BASE-T
Antal DVI-I-porte: 1
Optisk drev inkluderet: Ingen
