Quick Start Guide

HAE Strain Wave Gear AZ/EQ GoTo Mount with iMateTM

Models: HAE29B/ , HAE43B/ , and HAE B/

EC EC 69 EC

PACKAGE CONTENTS1

 Dual strain wave gear altazi/equatorial mount with built-in iMate computer

 High precision opcal encoder on RA axle (for version)

 AC adapter -240V, 12V DC output for mount (for indoor use only) –100 6A

 Carrying case

OPTIONAL PARTS (not included)

 #8411 handset with OLED display

 iPolarTM electronics polar scope (#3339)

 Tripod/Tri-pier

 External iGuider for autoguiding (#3360)

 Counterweight sha P-SGP-CWS and counterweight (#3006-10) (# )

ONLINE RESOURCES www.iOptron.com ( )

 User’s Manual

 Hand controller and mount rmware upgrades (check online for the latest version)

 Computer control

1Contents and design may change from me to me without noce. An HAE69C mount is used here for illustraon.

HAE is operated under unbalanced condion and could be pped o if tripod is not secured.

1. Remove mount head from package.

2. Set up tripod: HAE69, as shown here, has a An

150mm base. An oponal LiteRoc tripod #8023ACC or

a tri-pier #8034 may be used. Setup and level the

tripod. Adjust the tripod height. Tighten tripod

locking knob to secure the tripod. Remove the

Alignment Peg from the mount base and thread it

onto the tripod head, on top of a tripod leg or

between two legs depending on the latude. Use two

outside threaded holes to secure the mount head.

3. Aach mount head: Retract the 2X Azimuth (Azi)

Adjustment Screws from both sides to leave ample

space for the alignment peg to be ed in between

the 2 Azi Adjustment Screws X .

Remove Azi Locking Screws from the mount altude

arm. Secure the mount head by ghtening the Azi

Locking Screws into the M8 holes on the tripod There .

is an Allen wrench stored on the mount base for

ghtening the screws.

Level the mount by adjusng the tripod legs Use the .

built-in Bubble Level Indicator on the mount base or

an external leveler for this purpose.

4. Adjust latude: The HAE69 has three latude range

sengs: 0°~34°, 28°~62° and 56°~90°. To adjust the

latude, loosen both the Primary and Auxiliary Alt.

Locking Lever on the RA base. An HAE29B or HAE43B

does not have the auxiliary locking lever.

Azi. Locking Screw

Allen wrench

Center Post

Azi. Adj. Screw

For HAE69

Alignment peg

Azi. Locking Screw
