N . S 充电散热架

产品说明书(PG-SW036)

产品特点:

产品外观图示

产品使用说明:

产品技术参数：

注意事项：

1.本产品适用于N-S游戏主机及Joycon & Pro游戏手柄，同时具备N-S主机散热，

Joycon与N-S原装Pro手柄充电，耳机、游戏卡、精灵球及腕带等配件收纳的功能。

2.带充电指示灯,在充电过程中，便于识别充电状态。

3.配备专用的触点式充电转接头,无线连线充电.随取随放,使用非常方便。

4.配备耳机支架,可放置耳机，方便拿取。

5.散热风扇能给主机降温与散热。

6.配备游戏碟架,可放置7张游戏卡。

1 .将N-S底座通过原装电源适配器接通电源，再将产品接入N-S主机底座的USB接口，

产品指示灯亮起：手柄充电时红色指示灯亮，充满转为蓝色指示灯亮；

2 .将Joycon或Pro手柄插入对应充电座口后，等待3秒左右，相对应的充电状态指示灯

会由蓝色转变为红色，此时手柄为充电状态；当手柄充饱后红色指示灯转变为蓝色指

示灯，此时手柄电池为饱和状态；

3：当N-S主机发热时，可按下侧边风扇按扭，打开风扇功能，为N-S主机散热；

4：产品侧边有2个USB母座接口，可提供USB外设产品接入；

5：本产品具有耳机和游戏卡收置功能。

1. 使用本产品时需配套使用N-S原装电源适配器，以防发生意外损坏产品及手柄；

2. Joycon或Pro手柄快充满电时，本产品充电指示灯存在与Switch主机或手柄提示不同

步现象，此为正常现象；（例如：Joycon或Pro手柄充电指示已经指示充满，但是进入

主机查看依然在充电）

3. Joycon或Pro手柄电池低压被保护后，插入本产品充电，指示灯会不同步，此为正常

现象；（例如：Joycon或Pro手柄电池低压被保护后，插入产品进行充电，充电指示灯

短时间内依然显示蓝色或者蓝色与红色之间闪烁，此为正常现象）

底座 x1 耳机支架 x1 连接与散热模块 x1

产品清单：

ipega官方微信公众号

售后客服QQ群： 783735068

客服电话： 8(0755) 2791 899

在线时间：周一至周五9:30-17:30

耳机支架

散热风扇

手柄充电槽2

手柄充电槽 1

充电转接头 x2

主机连接插头

Joycon

充电槽

1.工作电压：DC 4.8 - 5.5V；

2.充电电流：Joycon <230 mA p1-x4 Pro 手柄：<500mA x2；

3.Joycon充电时间：约3.5小时 Pro 手柄充电时间：约4小时；

说明书 x1

充电转接头 p1-x2

Cooling & Charging Stand for N-S

User Manual(PG-SW036)

Features

How to use

Product Overview

Notes:

1. This product is applicable to joycon or pro game controller for charging;

2. Product Notes:

① : The original power adapter shall be used when using the product,to

prevent accidental damage to the product and game controller ;

② : when joycon or pro controller is about to be fully charged, the charging

indicator light of this product is not synchronized with switch console or

controller, which is normal; (for example: joycon or pro controller charging

indication has indicated that it is full, but it is still charging after entering the

console to check)

③ : When the low voltage of joycon or pro controller battery is protected,

insert the product for charging, and the indicator light will be inaccurate,

which is a normal phenomenon;

(for example: after the low voltage of Joycon or Pro controller battery is

protected, insert the product to charge, the charging indicator still shows

blue or flashes between blue and red in a short time, this is normal.)

1. This product is suitable for N-S game consoles and Joycon & Pro game

controllers. It also has N-S console cooling, Joycon and N-S original Pro

controller charging, and storage of accessories such as headsets, game case,

wizard balls and wristbands.

2. With charging indicator, it is easy to identify the charging status during the

charging process.

3. With contact charging adapter for wireless connection charging. Put it on

your gamepads, easy to use.

4. With headset bracket, you can place the headset for easy access.

5. With Dual cooling fans can avoid overheating of the console.

6. With game card storage function, easy to storage 7 game cards.

1.Connect the N-S dock to the power supply through the original power

adapter, and connect the product to the USB interface at the side of N-S dock,

and the indicator will be on: when the game controller is charging, the red

indicator will be on, and when it is full, the blue indicator will be on;

2. Insert joycon or pro game controller into the corresponding charging socket,

wait for about 3 seconds, the corresponding charging state indicator will

change from blue to red, and the game controller is charging

when the game controller is full, the red indicator turns to the blue, and the

game controller is saturated;

3: When the switch console is hot, press the lower side fan button to turn on

the fan to dissipate heat for the switch console;

4: There are two USB sockets on the side , which can provide access to USB

peripheral products;

5: This product has the function of headphone and game card storage.

Headset

Bracket

Cooling Device

Console pulg

Charging

Indicator1/2

Type-C Adapter

Parameters:

Working Voltage: 4.8V-5.5V

Joycon Charging current: Joycon <230 mA p1-x4 Pro Controller：<500mA x2；

Joycon Charging time: about 3.5 H Pro Controller : about 4 H

Vertical Stand x1

Connection and cooling module x1

Included：

Charging adapter x2

User Manual p1-x1

Headset stand

USB接口

充电槽指示灯

N-S主机放置位

散热开关

游戏卡放置槽

精灵球放置槽

Joycon

Charging Slot p1-x4

Pro controller

Charging Slot 1

Pro controller

Charging Slot 1

N-S Console

Slot

Game card

Slot

Pokeball storage

USB2.0 Port

Cooling switch

Patent NO. : ZL202030290893.4

专利号：ZL202030290893.4
