BPU 128DE- -SS

8 bay Slim 2.5” SSD Hard Drive Cage-

User’s Manual

Specicaon:

Order Informaon:

Hot Swap

8x2.5” Slim SSD (7mm or less)

Cooling Fan

1x40mm

Standard Drive Bays

5.25” Drive: 1

Dimension (W x H x D)

5.75 x 1.65 x 6.3 inches

HDD Interface

SATA I/II/III, SAS I/II

Weight

2 lbs

Model Number:

Color:

UPC Code:

BPU 128DE- -SS

Black

846813039116

Introducon:

The 2.5" Disk Array BPU 128DE SS, the Disk Array to be set up in various - -

configuraons: as RAID 0, RAID 1, RAID 5 or JBOD, as individual drive, or

whatever the mix that best ts the applicaon. The Disk Array can start with as

little as one hard drive and then expands as needed. Hard Drive can also be

removed or added to the system without turning off your system power or

restarng your computer.

Features:

• Point to point, free from master/slave seng

• Supports SSD/HDD thickness 7mm or less

• Built in 40mm cooling fan-

• LEDs for power and HDD accessing

• Supports Plug & Play, h Swappable ot-

• High performance transfer rate up to 6.0 Gb/s

• Supports 8x 2.5” SAS I/II & SATA I/II/III HDD/SSD

• Mechanical lock design

• Metal body with stainless HDD carrier

Hardware Informaon: Front View

D-1: Power LED, green when lid.

D -2: HDD acvity LED, amber blinking when lid.

D 3: -Mechanical lock

BPU 128DE- -SS

iStarUSA – Powered by iStarUSA Group

727 Phillips Drive

City of Industry, CA 91748

Tel: (888) 989-1189

Email: sales@istarusa.com

Hardware Informaon: Rear View

D 4: -15-pin power connector

D -5: 7 pin data connector-

Hardware Informaon: HDD Tray

HDD Cage to 5.25” Bay Installaon:

1. Install BPU 128DE SS HDD cage to an available 5.25” bay from a system.- -

2. Secure the HDD cage on both sides with provided screws.

3. Connect two SATA power connectors to the HDD cage from the power supply.

4. Connect data cables to the HDD cage.

Accessories:

• Screws

2.5” SSD/HDD to tray Installaon:

1. Insert slim 2.5” SSD/HDD into the tray.

2. Use provided screws to fasten SSD/HDD to the tray from boom

3. Slide the HDD tray back to the HDD cage.

4. Repeat step 1 to 3 to nish the rest of HDD/SSD installation.

iStarUSAcare:

We will help you navigate our website to nd the informaon that

you need. Go to www.istarusa.com, and click on live chat bubble

above the Search Bar

Our technicians are standing by to take your questions. Visit

http://istarusa.com/support/ , and you will receive a technical

support cket to help track your requests from the beginning to the

end. Or you can contact us @ 989 1189888- -

FCC and CE Radiation Norm

FCC

This equipment has been tested and found to comply with limits for Class B digital device pursuant to Part 15 of Federal Communications

Commission (FCC) rules.

This equipment has been tested and found to comply with the limits of the European Council Directive on the approximation of the law of the member

states relating to electromagnetic compatibility (89/336/EEC) according to EN 55022 Class B.

FCC and CE Compliance Statement

These limits are designed to provide reasonable protection against frequency interference in residential installation. This equipment generates uses

and can radiate radio frequency energy, and if not installed or used in accordance with the instructions may cause harmful interference to radio

communication. However, there is no guarantee that interference will not occur in television reception, which can be determined by turning the

equipment off and on. The user is encouraged to try and correct the interference by one or more of the following measures: Reorient or relocate the

receiving antenna, Increase the separation between the equipment and the receiver, connect the equipment into an outlet on a circuit different from

that to which the receiver is connected to.

CAUTION!

The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible

for the compliance could void the user’s authority to operate the equipment.

BPU 128DE- -SS
